| Ref | Part Number | Description |
|---|
| 1 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 2 |
26-1840 |
PULLEY-IDLER Price: $42.68 |
| 2 |
530042088 |
Spring-Muffler Price: $1.99 |
| 3 |
26-1760 |
PULLEY AND HUB ASM Price: $214.86 |
| 3 |
530071391 |
Kit-Spark Arrestor Price: $7.99 |
| 4 |
26-1130 |
DISCONTINUED Price: Call Us |
| 4 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 5 |
26-1860 |
SPACER-IDLER PULLEY Price: $4.75 |
| 5 |
952030249 |
Spark Plug (RCJ 6Y) Price: $3.99 |
| 6 |
32128-21 |
NUT-HF Price: $0.39 |
| 6 |
530012416 |
Cylinder This part replaces 530071359. Price: $17.99 |
| 7 |
3231-27 |
SCREW-CARR Price: $0.54 |
| 7 |
530071363 |
Gasket-Cylind./Carb. Price: $5.99 |
| 8 |
26-1870-03 |
MOUNT-IDLER This part replaces 26-1870. Price: $74.13 |
| 8 |
545030402 |
CARBURETOR ADAPTOR This part replaces 530056403. Price: $8.99 |
| 9 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 9 |
530016014 |
Screw Price: $1.99 |
| 10 |
3217-7 |
NUT-HEX Price: $0.28 |
| 10 |
530071363 |
Gasket-Carb. Price: $5.99 |
| 11 |
26-1850 |
STUD-IDLER Price: $32.97 |
| 11 |
530071635 |
Kit-Carb.(WT-631) Price: $54.99 |
| 12 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 12 |
530038747 |
Choke Plate Mounting Price: $1.99 |
| 13 |
49-8320 |
BEARING ASM This part replaces 26-1730. Price: $104.42 |
| 13 |
530038686 |
Shutter-Choke Price: $1.99 |
| 14 |
21-0890 |
V-BELT Price: $32.90 |
| 14 |
530052431 |
Air Box Price: $1.99 |
| 15 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 15 |
530016353 |
Screw Price: $1.99 |
| 16 |
3-8514 |
WASHER-THRUST Price: $1.58 |
| 16 |
530036569 |
Plate - Filter Support Price: $1.99 |
| 17 |
530036575 |
Foam-Air Filter Price: $1.99 |
| 17 |
84-2060 |
PULLEY AND HUB ASM This part replaces 26-9100. Price: $276.94 |
| 18 |
253-138 |
SEAL-OIL Price: $10.33 |
| 18 |
530036568 |
Cover-Air Filter Price: $1.99 |
| 19 |
110-8297 |
BEARING ASM This part replaces 26-1830. Price: $45.97 |
| 19 |
530016349 |
Screw Price: $1.99 |
| 20 |
26-1950 |
DISCONTINUED Price: Call Us |
| 20 |
530015852 |
Spacer-Choke Price: $1.99 |
| 21 |
32146-13 |
NUT-HEX Price: $3.49 |
| 21 |
530015254 |
Washer Price: $1.99 |
| 22 |
26-7120 |
DISCONTINUED Price: Call Us |
| 23 |
26-7980 |
DISCONTINUED Price: Call Us |
| 23 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 24 |
51-2700 |
DISCONTINUED This part replaces 26-1910. Price: Call Us |
| 24 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 25 |
302-52 |
FITTING-GREASE Price: $1.49 |
| 25 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 26 |
26-1820 |
CAPSCREW Price: $37.35 |
| 26 |
530071363 |
Gasket-Cylinder Price: $5.99 |
| 27 |
26-1990 |
WASHER-BELLEVILLE Price: $16.49 |
| 27 |
530055160 |
Ignition Module Price: $34.99 |
| 28 |
29-5530-03 |
BLADE-STANDARD, 25 INCH, LH This part replaces 29-5530. Price: $40.07 |
| 28 |
530016357 |
Screw Price: $1.99 |
| 29 |
26-1690 |
DISCONTINUED Price: Call Us |
| 29 |
581425901 |
SWITCH, GROUND WIRE This part replaces 530014662. Price: $1.99 |
| 30 |
530014663 |
Assy-Leadwire Price: $5.99 |
| 30 |
84-2020 |
HOUSING-SPINDLE This part replaces 26-1630. Price: $297.31 |
| 31 |
325-17 |
SCREW-HH Price: $2.90 |
| 32 |
26-1880 |
SPACER-IDLER MOUNT Price: $13.91 |
| 32 |
530016381 |
Screw-Nose Cone Price: $2.99 |
| 33 |
323-12 |
SCREW-HH Price: $1.14 |
| 33 |
530016382 |
Nut-Nose Cone Price: $2.99 |
| 34 |
3231-29 |
SCREW-CARR Price: $0.68 |
| 34 |
530071356 |
Kit-Switch Price: $4.99 |
| 35 |
26-7970 |
CAUTION DECAL (BLADE) Price: $14.83 |
| 35 |
530027569 |
Handle-Starter Price: $1.99 |
| 36 |
530069232 |
Kit - Rope Price: $3.99 |
| 36 |
84-5370 |
SPINDLE This part replaces 26-1680. Price: $259.86 |
| 37 |
530016080 |
Screw Price: $1.99 |
| 37 |
68-7280 |
DECAL - BLD BOLT TORQUE This part replaces 26-7960. Price: $11.26 |
| 38 |
530038604 |
Coupling-Drive Price: $1.99 |
| 38 |
84-2090 |
SPACER-SPINDLE, RH This part replaces 26-1790. Price: $32.37 |
| 39 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 40 |
530055728 |
Outer Bearing Price: $6.99 |
| 41 |
530019264 |
Seal-C'case Price: $2.99 |
| 42 |
530032125 |
Inner Bearing Price: $11.99 |
| 43 |
530056547 |
Shroud-Rear Price: $8.99 |
| 44 |
530015934 |
Screw Price: $1.99 |
| 45 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 46 |
530054536 |
Guard-Muffler Price: $1.99 |
| 47 |
530071363 |
O-Ring-C'case/Shrd Price: $5.99 |
| 48 |
530054753 |
Assy-Crankshaft Price: $27.99 |
| 51 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 52 |
530015828 |
Washer-Flat Price: $1.99 |
| 53 |
530015775 |
Screw Price: $1.99 |
| 54 |
530027523 |
Retainer-Can Price: $2.99 |
| 56 |
545008010 |
STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 57 |
530071667 |
Assy.-Fan Hsg Price: $5.44 |
| 58 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 60 |
530016379 |
Screw Price: $2.99 |
| 61 |
530014347 |
Assy-Fuel Cap Price: $4.99 |
| 62 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
| 63 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 64 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
