| Ref | Part Number | Description |
|---|
| 0 |
632671C |
CARBURETOR Price: $78.00 |
| 1 |
580806502 |
SUPPORT.FRONT.TRANS.PNTX431 This part replaces 522460702. Price: $5.99 |
| 1 |
632539 |
SHAFT & LEV Price: $12.00 |
| 2 |
539101721 |
HCS 5/16C X 2-3/4 Price: $3.99 |
| 3 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 4 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 5 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 5 |
632593 |
WASHER Price: $1.20 |
| 6 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 6 |
632541 |
SHUTTER Price: $1.20 |
| 7 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
539976938 |
CAPSCREW Price: $3.99 |
| 9 |
596584101 |
Nuts This part replaces 539991073. Price: $2.99 |
| 10 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 11 |
522706002 |
ROD, BYPASS, RT Price: $7.99 |
| 12 |
522706001 |
ROD, BYPASS, LT Price: $7.99 |
| 13 |
522447402 |
HG_TRANS, ZT-2800 RT Price: $749.99 |
| 14 |
522447401 |
HG_TRANS, ZT-2800 LEFT Price: $749.99 |
| 14A |
632773 |
VENTURI Price: $1.25 |
| 15 |
510185102 |
EZT MOUNT, REAR, BLACK Price: $32.99 |
| 16 |
510184103 |
SPACER TUBE, EZT, 11.08 Price: $32.99 |
| 17 |
539112318 |
HG_EXPANSION TANK W/CAP 71354 Price: $49.99 |
| 18 |
522439801 |
HOSE ASSY Price: $34.99 |
| 19 |
596238401 |
BOLT CUP HEAD SQUARE NECK BOLT This part replaces 539990074. Price: $2.99 |
| 20 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 21 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 22 |
539112308 |
BRAKE SWIVEL Price: $8.99 |
| 23 |
539101224 |
SPRING Price: $19.99 |
| 24 |
596580601 |
Pins This part replaces 539976988. Price: $3.99 |
| 25 |
596930401 |
Links This part replaces 574030501. Price: $6.99 |
| 25 |
632675B |
FLOAT BOWL Price: $16.56 |
| 25A |
730235B |
BOWL KIT This part replaces 730235A. Price: $20.46 |
| 26 |
596930701 |
Links This part replaces 574030502. Price: $5.99 |
| 27 |
522656101 |
ROD, MOTION CONTROL Price: $27.99 |
| 27 |
632544A |
FLOAT SHAFT This part replaces 632544. Price: $2.61 |
| 28 |
579764601 |
JOINT.HEIM.FEML.5/16.RH.THREAD This part replaces 539115729. Price: $7.99 |
| 28 |
632543 |
FLOAT Price: $6.73 |
| 29 |
596718601 |
Coupling This part replaces 539116689. Price: $2.99 |
| 29 |
632548 |
GASKET Price: $4.91 |
| 30 |
588692502 |
ROD.END.MALE.LH.THREAD This part replaces 539116690. Price: $8.99 |
| 30 |
632709 |
INLET NEEDLE Price: $4.91 |
| 31 |
596040901 |
Hardware This part replaces 539990223. Price: $2.99 |
| 32 |
539113466 |
HG_FILTER, ZT4800 52114 Price: $32.99 |
| 32 |
640041 |
SCREW Price: $1.25 |
| 33 |
27110A |
GASKET Price: $1.45 |
| 33 |
596433601 |
Nuts This part replaces 539115617. Price: $2.99 |
| 34 |
539108535 |
SCR #10-24 X 3/4 Price: $2.99 |
| 35 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 36 |
632674 |
NOZZLE Price: $1.17 |
| 37 |
632547 |
O RING Price: $1.49 |
| 38 |
36918 |
SPRING Price: $1.18 |
| 39 |
632549 |
RETAINER Price: $1.25 |
| 40 |
632676 |
FUEL JET Price: $1.25 |
