| Ref | Part Number | Description |
|---|
| 1 |
120-8056 |
TUBE ASM Price: $144.29 |
| 1 |
872050411 |
Bolt Rdhd. Sht. Nk 1/4-20 x 1-3/8 Price: $3.99 |
| 2 |
120-8055 |
TUBE ASM Price: $137.84 |
| 2 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532127398. Price: $149.99 |
| 3 |
115-4412 |
TUBE ASM Price: $132.35 |
| 4 |
115-4408 |
TUBE ASM Price: $126.40 |
| 4 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 5 |
115-4406 |
TUBE ASM Price: $119.83 |
| 5 |
532139888 |
BOLT.SHOULDER.5/16-18 Price: $3.99 |
| 6 |
115-4409 |
TUBE ASM Price: $115.75 |
| 6 |
532140407 |
INSULATED CLIP Price: $3.99 |
| 7 |
115-4405 |
TUBE ASM Price: $119.61 |
| 8 |
136-3414 |
HYDRAULIC TUBE ASM This part replaces 125-4581. Price: $81.81 |
| 8 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 9 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 9 |
92-7606-03 |
BRACKET-BULKHEAD Price: $13.64 |
| 10 |
125-4560 |
HOSE ASM Price: $96.58 |
| 11 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 11 |
92-7539 |
HOSE-HYD Price: $134.23 |
| 12 |
105-3873-03 |
BRACKET-MOUNT, CLAMP Price: $33.52 |
| 12 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 13 |
120-8057 |
TUBE ASM Price: $94.49 |
| 13 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT This part replaces 532120068. Price: $6.99 |
| 14 |
340-70 |
NUT-LOCK Price: $2.10 |
| 15 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 15 |
819171912 |
WASHER Price: $3.99 |
| 16 |
115-1794 |
SCREW-HHF Price: $1.73 |
| 16 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 17 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 18 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 19 |
105-3993-0P |
BRACKET-TUBE SUPPORT This part replaces 105-3993-03. Price: $40.13 |
| 19 |
532121248 |
BUSHING Price: $4.99 |
| 20 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 20 |
532121250 |
SPRING Price: $3.99 |
| 21 |
2412-81 |
CLAMP-R Price: $3.39 |
| 21 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 22 |
119-4036 |
SCREW-HHF Price: $0.53 |
| 23 |
125-4570 |
TUBE ASM Price: $80.61 |
| 23 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532140552. Price: $17.99 |
| 24 |
121-3064 |
TUBE ASM Price: $100.05 |
| 25 |
121-3063 |
TUBE ASM Price: $64.29 |
| 32 |
69-9761 |
PLATE-COVER Price: $6.26 |
| 33 |
94-8105 |
CLAMP-TUBE Price: $3.17 |
| 34 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 35 |
104-8300 |
NUT-HF, NI Price: $0.39 |
