| Ref | Part Number | Description |
|---|
| 1 |
36-3880 |
DISCONTINUED This part replaces 5-4495. Price: Call Us |
| 1 |
532181098 |
TRANSMISSON.SERV.TILLER This part replaces 532188554. Price: $649.99 |
| 2 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 3 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 3 |
532431022 |
GASKET.GEARCASE.CRT/DRT.TILLER Price: $17.99 |
| 4 |
282-2 |
YOKE Price: $30.04 |
| 4 |
532005020 |
NEEDLE BRNG LT Price: $9.99 |
| 5 |
3220-2 |
NUT-JAM Price: $0.50 |
| 5 |
532001370 |
THRUST WASHER Price: $2.99 |
| 6 |
5-4016 |
DISCONTINUED Price: Call Us |
| 6 |
586196301 |
PINION INPUT CRT TILLER This part replaces 532137335. Price: $19.99 |
| 7 |
5-0743-03 |
SPRING-MOWER This part replaces 5-0743. Price: $188.53 |
| 8 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 8 |
532004895 |
BEARING Price: $9.99 |
| 9 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 10 |
323-7 |
SCREW-HH Price: $0.65 |
| 10 |
532100482 |
STEEL.BALL.KIT(12 BALLS) This part replaces 532007392. Price: $3.99 |
| 11 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 11 |
532100371 |
SPRING-SHIFT CRT Price: $3.99 |
| 12 |
282-4 |
SHACKLE Price: $32.98 |
| 12 |
532106160 |
O-RING TI Price: $3.99 |
| 13 |
3220-1 |
NUT-JAM Price: $0.99 |
| 13 |
532142145 |
SHIFTING ARM Price: $14.99 |
| 14 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 14 |
532008353 |
SHIFT FORK TI Price: $19.99 |
| 15 |
3217-7 |
NUT-HEX Price: $0.28 |
| 15 |
812000039 |
KLIP RING Price: $3.99 |
| 16 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 16 |
532154466 |
SHAFT.SHIFTER.TILLER Price: $4.99 |
| 17 |
321-6 |
SCREW-HH Price: $0.25 |
| 18 |
3217-5 |
NUT-HEX Price: $0.25 |
| 18 |
532004358 |
WASHER Price: $3.99 |
| 19 |
3-7878 |
THROTTLE CONTROL Price: $96.26 |
| 19 |
812000040 |
KLIP RING Price: $3.99 |
| 20 |
532102114 |
GEAR ASSY CRT Price: $17.99 |
| 21 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 21 |
532102115 |
GEAR-REV IDLR CRT Price: $9.99 |
| 22 |
3-7877 |
GRIP-HANDLE Price: $10.69 |
| 22 |
532006803 |
NEEDLE BEARING TI Price: $6.99 |
| 23 |
36-8490 |
DISCONTINUED This part replaces 3-7921. Price: Call Us |
| 23 |
532102111 |
SHAFT CRT Price: $17.99 |
| 24 |
3-6718 |
DISCONTINUED Price: Call Us |
| 24 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 25 |
3-7913 |
DISCONTINUED Price: Call Us |
| 25 |
873610700 |
NUT.ASF.HEX.7/16 Price: $3.99 |
| 26 |
5-1990 |
DISCONTINUED Price: Call Us |
| 27 |
3290-244 |
WASHER-LOCK Price: $0.85 |
| 27 |
532431219 |
BEARING.GROUND.DRIVE This part replaces 532143009. Price: $6.99 |
| 28 |
3-7168 |
DISCONTINUED Price: Call Us |
| 28 |
532106390 |
SPACER Price: $3.99 |
| 29 |
321-6 |
SCREW-HH This part replaces 322-22. Price: $0.25 |
| 30 |
3296-41 |
NUT-LOCK NI This part replaces 32146-19. Price: $5.49 |
| 30 |
532150737 |
GROUND SHAFT ASS'Y Price: $49.99 |
| 31 |
5-3638 |
DISCONTINUED Price: Call Us |
| 31 |
532143008 |
BEARING, SHAFT RH CRT Price: $4.99 |
| 32 |
532106388 |
SPACER TI Price: $3.99 |
| 32 |
603773 |
LOCKNUT This part replaces 32146-2. Price: $2.09 |
| 33 |
46-9670 |
DISCONTINUED This part replaces 8-6660. Price: Call Us |
| 34 |
5-3318 |
REAR BALL JOINT ASM Price: $537.89 |
| 34 |
532102112 |
SHAFT.SECONDARY.REDUCTION.CRT Price: $17.99 |
| 35 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 35 |
532102101 |
SCRW WHIZ LOK CRT Price: $2.99 |
| 36 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 36 |
532154355 |
SPROCKET.ASM.W/BEARING.TILLER Price: $74.99 |
| 37 |
3-7166 |
DISCONTINUED Price: Call Us |
| 37 |
585695502 |
BEARING NEEDLE .875X.687 OE.50 This part replaces 532004422. Price: $2.99 |
| 38 |
3-6685 |
SPRING Price: $10.99 |
| 38 |
532154355 |
SPROCKET.ASM.W/BEARING.TILLER This part replaces 532154356. Price: $74.99 |
| 39 |
3-6725 |
DISCONTINUED Price: Call Us |
| 39 |
532105345 |
GEAR TI Price: $22.99 |
| 40 |
32121-7 |
PIN-ROLL, SLOTTED Price: $0.31 |
| 40 |
532105346 |
GEAR TI Price: $17.99 |
| 41 |
5-3667 |
DISCONTINUED Price: Call Us |
| 41 |
532008358 |
SHAFT.REDUCTION.TILLER Price: $12.99 |
| 42 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 42 |
532004220 |
BRNG RACE T Price: $3.99 |
| 43 |
323-6 |
SCREW-HH Price: $0.66 |
| 43 |
532106146 |
SPACER TI Price: $3.99 |
| 44 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 45 |
5-4018 |
DISCONTINUED Price: Call Us |
| 46 |
5-4015 |
SHOULDER BOLT Price: $33.99 |
| 47 |
323-9 |
SCREW-HH Price: $1.29 |
| 48 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 48 |
532181098 |
TRANSMISSON.SERV.TILLER This part replaces 532188485. Price: $649.99 |
| 49 |
5-2580 |
DISCONTINUED Price: Call Us |
| 49 |
532431485 |
SHAFT.ASM.TINE Price: $64.99 |
| 50 |
3-7157 |
SHOULDER BOLT Price: $47.07 |
| 50 |
532106147 |
CHAIN.TILLER Price: $39.99 |
| 51 |
3296-6 |
NUT-LOCK This part replaces 32146-12. Price: $1.49 |
| 51 |
539990071 |
HCS 1/4-20. This part replaces 817720408. Price: $1.99 |
| 52 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 52 |
873220500 |
NUT Price: $3.99 |
| 53 |
5-3631 |
DISCONTINUED Price: Call Us |
| 53 |
532165140 |
BEARING KIT Price: $59.99 |
| 54 |
5-3642 |
DISCONTINUED Price: Call Us |
| 55 |
5-3320 |
FRONT BALL JOINT ASM Price: $269.13 |
| 56 |
5-3637 |
SPACER Price: $2.23 |
| 58 |
5-2945 |
DISCONTINUED Price: Call Us |
| 58 |
532179520 |
BOLT SHOULDER 1/4-20 UNC X.875 Price: $2.99 |
| 59 |
5-3661 |
BALL JOINT Price: $126.61 |
| 60 |
323-25 |
SCREW-HH Price: $3.60 |
| 60 |
532183226 |
FITTING.GREASE.TAPERED Price: $3.99 |
| 61 |
3-6705 |
DISCONTINUED Price: Call Us |
| 62 |
256-155 |
BUSHING-FLANGE Price: $1.76 |
| 62 |
532431015 |
SPACER.1.015X1.50X.650 Price: $2.99 |
| 63 |
3-7368 |
DISCONTINUED Price: Call Us |
| 64 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 65 |
3-7867 |
DISCONTINUED Price: Call Us |
| 66 |
3-7854 |
DISCONTINUED Price: Call Us |
| 67 |
5-3628 |
DISCONTINUED Price: Call Us |
| 68 |
5-3630 |
DISCONTINUED Price: Call Us |
| 70 |
3-6692 |
COMPRESSION SPRING Price: $16.89 |
| 71 |
5-2816 |
DISCONTINUED Price: Call Us |
| 72 |
3-6715 |
DISCONTINUED Price: Call Us |
| 73 |
39-5200 |
DISCONTINUED This part replaces 3-7145. Price: Call Us |
| 74 |
3-6708 |
DISCONTINUED Price: Call Us |
| 75 |
3220-7 |
NUT-JAM Price: $4.09 |
| 76 |
5-3644 |
DISCONTINUED Price: Call Us |
| 77 |
3296-15 |
NUT-LOCK, NI Price: $1.75 |
| 78 |
3296-19 |
NUT-HEX This part replaces 32146-11. Price: $0.65 |
| 79 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 80 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 81 |
5-2575 |
DISCONTINUED Price: Call Us |
| 82 |
256-188 |
BUSHING Price: $5.70 |
| 83 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 84 |
3272-23 |
PIN-COTTER Price: $0.28 |
| 85 |
5-4017 |
DISCONTINUED Price: Call Us |
| 86 |
5-2582 |
ARM & BSHG ASM Price: $182.19 |
| 87 |
5-1404 |
DISCONTINUED Price: Call Us |
| 88 |
5-2620 |
DISCONTINUED Price: Call Us |
| 89 |
323-8 |
SCREW-HH Price: $1.20 |
| 90 |
32104-71 |
SCREW-HWH Price: $3.04 |
