| Ref | Part Number | Description |
|---|
| 1 |
5-1824 |
DISCONTINUED Price: Call Us |
| 1 |
530029954 |
Ignition Switch Price: $4.99 |
| 2 |
5-1823 |
DISCONTINUED Price: Call Us |
| 2 |
545172901 |
WIRE HARNESS ASSY This part replaces 530036443. Price: $11.99 |
| 3 |
3220-6 |
NUT-JAM Price: $1.25 |
| 3 |
530015775 |
Screw-Handle Cov. Price: $1.99 |
| 4 |
5-1834 |
DISCONTINUED Price: Call Us |
| 4 |
530029958 |
Trigger Lever Price: $1.99 |
| 5 |
32546 |
S.P. Washer Price: Call Us |
| 5 |
530015940 |
Screw-Handle Cov. Price: $1.99 |
| 6 |
3234 |
Capscrew Price: Call Us |
| 6 |
530015770 |
Screw-Handle Cov. Price: Call Us |
| 7 |
5-1822 |
DISCONTINUED Price: Call Us |
| 7 |
530038305 |
Handle Cover Price: $2.99 |
| 8 |
5-1816 |
DISCONTINUED Price: Call Us |
| 8 |
530053884 |
Throttle Trigger This part replaces 530029956. Price: $1.99 |
| 9 |
5-1784 |
DISCONTINUED Price: Call Us |
| 9 |
530036122 |
Throttle Lockout Price: Call Us |
| 10 |
5-1815 |
DISCONTINUED Price: Call Us |
| 10 |
530036123 |
Trigger Spring Price: $1.99 |
| 11 |
252-6 |
BEARING-NEEDLE Price: $10.72 |
| 11 |
530015934 |
Screw-Handle Cov. Price: $1.99 |
| 12 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 12 |
530047879 |
Rear Handle/Tank Ass'y. This part replaces 530047494. Price: $42.81 |
| 13 |
3-8119 |
DISCONTINUED Price: Call Us |
| 13 |
530094992 |
Front Handle Price: $6.99 |
| 14 |
283-14 |
PIN-CLEVIS Price: $2.92 |
| 14 |
530029946 |
Isolator Spring Price: $1.99 |
| 15 |
282-4 |
SHACKLE Price: $32.98 |
| 15 |
530056069 |
Assy-Drum This part replaces 530048113. Price: $24.99 |
| 16 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 16 |
530015814 |
Screw Price: $1.99 |
| 17 |
530029916 |
Gear Box Plate Price: $2.99 |
| 18 |
530032121 |
Bushing Blade Price: $2.99 |
| 19 |
530403228 |
Assy-Blade 19" This part replaces 530094991. Price: $29.99 |
| 20 |
530029948 |
Blade Seal Price: $1.99 |
| 21 |
530036228 |
Pinion Ass'y. Price: $19.99 |
| 22 |
530016013 |
Drive Gear Bearings Price: $2.99 |
| 23 |
530069355 |
Drive Gear Kit Price: $11.99 |
| 24 |
530036046 |
Isolator Plate Price: $4.99 |
| 25 |
577858601 |
FUEL CAP ASSY W/RET LW PRM This part replaces 530036965. Price: $3.99 |
| 26 |
530015955 |
Screw-Front Handle Price: $1.99 |
| 27 |
530015805 |
Screw-Gear Price: $1.99 |
| 28 |
530071931 |
Assy-Gear Box This part replaces 530014399. Price: $24.99 |
| 29 |
503896701 |
DIAPHRAGM This part replaces 530035014. Price: $4.99 |
| 30 |
530035320 |
Metering Diaphragm Gasket Type 1 Only Price: $2.99 |
| 31 |
530035016 |
Pump Gasket Type 1 Only Price: $2.99 |
| 32 |
530035017 |
Pump Diaphragm Type 1 Only Price: $0.99 |
| 33 |
505520125 |
Pin This part replaces 530035250. Price: $1.99 |
| 34 |
505520127 |
Metering Lever This part replaces 530035031. Price: $3.99 |
| 35 |
530035178 |
Fuel Inlet Screen Type 1 Only Price: $1.99 |
| 36 |
503563401 |
Needle This part replaces 530035223. Price: $2.99 |
| 37 |
530035188 |
WT-141 - T1 This part replaces 530035139. Price: $1.99 |
| 38 |
505316717 |
Screw This part replaces 530035236. Price: $1.99 |
| 39 |
530035319 |
Welch Plug Type 1 Only Price: Call Us |
| 40 |
530069844 |
Gasket Diaphragm Kit This part replaces 530035213. Price: $11.99 |
| 41 |
530035312 |
Carb. Repair Kit-, (WT-221) (Incl. 33-38,& 40) Type 1 Price: $22.99 |
| 41 |
530069656 |
Carb. Repair Kit-, (WT-379) ( . Indicates Contents) Type 2 Price: $19.99 |
| 43 |
530038317 |
Limiter Cap-Low Type 2 Only Price: $1.99 |
| 44 |
530038318 |
Limiter Cap-High Type 2 Only Price: $1.99 |
