| Ref | Part Number | Description |
|---|
| 1 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 1 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 2 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 2 |
539120152 |
HG_HYDRO RH Price: $949.99 |
| 3 |
539120153 |
HG_HYDRO LH Price: $1,099.99 |
| 3 |
63-7640 |
SENDER-FUEL Price: $94.22 |
| 4 |
110-3257 |
HOSE-FUEL This part replaces 63-7630. Price: $17.26 |
| 4 |
596564404 |
Bolts This part replaces 539990629. Price: $2.99 |
| 5 |
574356501 |
SPACER, HYDRO Price: $14.99 |
| 5 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 6 |
2412-96 |
CLAMP-R Price: $3.46 |
| 6 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 7 |
32128-20 |
NUT-HF Price: $0.99 |
| 7 |
579764601 |
JOINT.HEIM.FEML.5/16.RH.THREAD This part replaces 539115729. Price: $7.99 |
| 8 |
588692502 |
ROD.END.MALE.LH.THREAD This part replaces 539116690. Price: $8.99 |
| 8 |
70-8630 |
GAS CAP Price: $44.42 |
| 9 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 9 |
539115502 |
NUT 5/16-24 UNF HEX JAM Price: $2.99 |
| 10 |
353-536 |
DISCONTINUED Price: Call Us |
| 10 |
539120169 |
CONTROL ROD Price: $11.99 |
| 11 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 11 |
596718601 |
Coupling This part replaces 539116689. Price: $2.99 |
| 12 |
3256-67 |
WASHER Price: $0.49 |
| 12 |
596584101 |
Nuts This part replaces 539991073. Price: $2.99 |
| 13 |
237-136 |
GROMMET Price: $3.52 |
| 13 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 14 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 14 |
539101721 |
HCS 5/16C X 2-3/4 Price: $3.99 |
| 15 |
321-5 |
SCREW-HH Price: $0.22 |
| 15 |
539111445 |
IZT BELT Price: $27.99 |
| 16 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 16 |
539120156 |
RELEASE LEVER LH Price: $24.99 |
| 17 |
539120157 |
RELEASE LEVER RH Price: $12.99 |
| 18 |
231-101 |
TIRE (23X8.5-12) 4-PLY TURF SAVER Price: $147.85 |
| 18 |
596580601 |
Pins This part replaces 539976988. Price: $3.99 |
| 19 |
217-117 |
WHEEL Price: $164.56 |
| 19 |
539976938 |
CAPSCREW Price: $3.99 |
| 20 |
23-7270 |
NUT-LUG Price: $10.37 |
| 21 |
5108 |
VALVE This part replaces 232-31. Price: $6.29 |
| 22 |
321-2 |
SCREW-HH Price: $2.79 |
| 24 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 25 |
27-4310-01 |
MASKED PIVOT PIN This part replaces 27-4310. Price: $31.42 |
| 26 |
324-5 |
SCREW-HH Price: $0.54 |
| 27 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 29 |
302-62 |
FITTING-GREASE Price: $1.34 |
| 30 |
76-3090 |
LH LIFT ARM ASM Price: $637.79 |
| 31 |
99-5682 |
CARRIER BRACKET ASM This part replaces 67-1830. Price: $164.13 |
| 32 |
3296-41 |
NUT-LOCK NI Price: $5.49 |
| 33 |
3272-17 |
PIN-COTTER Price: $1.79 |
| 34 |
86-9640-03 |
FRONT AXLE ASM This part replaces 70-2740. Price: $2,641.21 |
| 35 |
3214-5 |
SCREW-HH Price: Call Us |
| 36 |
66-3060 |
DISCONTINUED Price: Call Us |
| 37 |
110-6187 |
HOSE-FUEL This part replaces 71-3380. Price: $14.65 |
| 38 |
62-7650 |
GASKET Price: $4.28 |
| 39 |
63-7373 |
DISCONTINUED Price: Call Us |
| 40 |
46-6560 |
BUSHING Price: $2.94 |
| 41 |
46-6550 |
FITTING-ELBOW, 90 DEG Price: $37.39 |
