| Ref | Part Number | Description |
|---|
| 1 |
601001033 |
ASSEMBLY SPINDLE L.H. Price: $22.93 |
| 1 |
84-1880 |
FAN Price: $250.88 |
| 2 |
601001034 |
BUSHING, SPINDLE Price: $8.99 |
| 2 |
84-1890 |
DISCONTINUED Price: Call Us |
| 3 |
601001035 |
WASHER, FLAT Price: Call Us |
| 3 |
84-1930 |
FAN HUB *O Price: $111.65 |
| 4 |
32120-10 |
RING-SNAP Price: $1.29 |
| 4 |
601001035 |
WASHER, FLAT Price: Call Us |
| 5 |
36-7290 |
BEARING Price: $40.48 |
| 5 |
601001037 |
ASSEMBLY SPINDLE, R.H. Price: $25.54 |
| 6 |
322-4 |
SCREW-HH Price: $0.35 |
| 6 |
601001034 |
BUSHING, SPINDLE Price: $8.99 |
| 7 |
601001035 |
WASHER, FLAT Price: Call Us |
| 7 |
84-1940-03 |
HUB ASM This part replaces 84-1940. Price: $150.60 |
| 8 |
32128-20 |
NUT-HF Price: $0.99 |
| 8 |
601001036 |
RING, RET E NLA Price: $6.74 |
| 9 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 9 |
601001038 |
BRACKET, AXLE OUTER FRONT Price: Call Us |
| 10 |
601001039 |
Hanger Price: Call Us |
| 10 |
66-2440 |
DISCONTINUED Price: Call Us |
| 11 |
601001072 |
Screw, 5/16-18 x.63 HHC GR2 Price: Call Us |
| 11 |
63-7380 |
RESERVE TANK W/ENG Price: $114.51 |
| 12 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 12 |
601001059 |
Nut, 5/16-18 Reg H Ctr Lk Price: Call Us |
| 13 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 13 |
601001040 |
AXLE BRACKET, INNER Price: Call Us |
| 14 |
601000519 |
SCREW, 5/16-18X .50 WAHHT Price: $1.99 |
| 14 |
63-6760 |
FITTING-CONNECTOR Price: $61.52 |
| 15 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 15 |
601001041 |
Screw, 3/8-18 x 2.75 H HC GR 2 Price: Call Us |
| 16 |
601002407 |
NUT 3/8-16 This part replaces 601000060. Price: $3.99 |
| 16 |
63-7790 |
SCREW-CAP Price: $1.46 |
| 17 |
601001042 |
STEERING ASSEMBLY Price: $27.97 |
| 17 |
71-2910-03 |
RH REAR ENGINE ANGLE This part replaces 71-2910. Price: $22.46 |
| 18 |
117-2738 |
ENGINE-MITSUBISHI (SERVICE) This part replaces 94-3558. Price: $11,452.38 |
| 18 |
601001043 |
Clamp, .625 Dia. Price: Call Us |
| 19 |
601000073 |
SCREW, 5/16-18X .75 HHC This part replaces 601000072. Price: $2.99 |
| 19 |
66-2320-03 |
LH FRONT MOUNT ASM This part replaces 66-2320. Price: $62.36 |
| 20 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 20 |
601000059 |
NUT, 5/16-18 REGHEXCTRLK Price: $5.99 |
| 21 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 21 |
601001044 |
Brake Arm Assembly Price: Call Us |
| 22 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 22 |
601001045 |
LATCH, PARKING BRAKE Price: Call Us |
| 23 |
601001046 |
Bolt, .373 x .140 H H SH 1/4-20 Price: Call Us |
| 23 |
84-1870 |
DISCONTINUED Price: Call Us |
| 24 |
601002318 |
RP NUT This part replaces 601000062. Price: $9.99 |
| 24 |
63-6720-03 |
IDLER LEVER This part replaces 63-6720. Price: $66.34 |
| 25 |
323-6 |
SCREW-HH Price: $0.66 |
| 25 |
601004047 |
Bracket, Clutch and Brake Price: Call Us |
| 26 |
323-8 |
SCREW-HH Price: $1.20 |
| 26 |
601000519 |
SCREW, 5/16-18X .50 WAHHT Price: $1.99 |
| 27 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 28 |
601001048 |
ROCKER ARM MOWER ENGAGEMENT Price: $4.99 |
| 28 |
63-8140 |
PULLEY-IDLER Price: $47.94 |
| 29 |
601001049 |
Bolt 500 x 1.18 HHC 3/8-16 Price: Call Us |
| 29 |
92-8876 |
V-BELT Price: $33.06 |
| 30 |
601000656 |
WASHER, FLAT .390X1.25X. Price: $1.99 |
| 30 |
70-8560 |
DISCONTINUED Price: Call Us |
| 31 |
5-0652 |
SPACER Price: $5.35 |
| 31 |
601002407 |
NUT 3/8-16 This part replaces 601000060. Price: $3.99 |
| 32 |
601001050 |
HANGER Price: Call Us |
| 32 |
67-4700 |
GLOW LAMP This part replaces 66-8700. Price: $117.35 |
| 33 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 33 |
601000073 |
SCREW, 5/16-18X .75 HHC This part replaces 601000072. Price: $2.99 |
| 34 |
601000019 |
WASHER, FLAT .344X .69X. Price: $2.99 |
| 35 |
321-4 |
SCREW-HH Price: $0.99 |
| 36 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 37 |
321-3 |
SCREW-HH Price: $0.28 |
| 38 |
5-3637 |
SPACER Price: $2.23 |
| 39 |
43-5920 |
WASHER-LOCK, SPRING Price: $0.25 |
| 40 |
48-7880 |
NUT-HEX This part replaces 43-5970. Price: $0.25 |
| 41 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 42 |
57-6390 |
NUT-JAM Price: $0.89 |
| 43 |
33114-016 |
SCREW-HH This part replaces 48-7700. Price: $0.27 |
| 44 |
71-1520 |
RESERVOIR CAP Price: $21.69 |
| 45 |
32105-8 |
SCREW-SHH Price: $1.99 |
| 46 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 47 |
3217-5 |
NUT-HEX Price: $0.25 |
| 48 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
