| Ref | Part Number | Description |
|---|
| 1 |
122-0723 |
HARNESS-WIRE, HEADLINER Price: $1,442.69 |
| 1 |
539105060 |
CLEVIS PIN Price: $4.99 |
| 2 |
125-9606-03 |
BRACKET-FUSE BLOCK Price: $17.40 |
| 2 |
596933401 |
Washers This part replaces 539991043. Price: $2.99 |
| 3 |
104-2408 |
SCREW-HSBH Price: $2.19 |
| 3 |
539105069 |
E-RING 5/8 Price: $2.99 |
| 4 |
120-4578 |
NUT-HF Price: $0.41 |
| 4 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 5 |
596917701 |
Pins This part replaces 539102526. Price: $4.99 |
| 5 |
99-7430 |
RELAY-MINI Price: $22.99 |
| 6 |
130-0588 |
NUT-SWITCH Price: $2.99 |
| 6 |
539105059 |
LANYARD Price: $4.99 |
| 7 |
42863 |
STRIP-JUMPER Price: $2.90 |
| 7 |
594722002 |
LIFT This part replaces 539102641. Price: $4.99 |
| 8 |
42862 |
BLOCK-TERMINAL, GROUND Price: $19.58 |
| 8 |
539104321 |
ADJ. PLATE WLDMNT Price: $63.99 |
| 9 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 9 |
539104530 |
DECK LIFT SPACER Price: $5.99 |
| 10 |
107-1013 |
NUT-SPEED Price: $2.89 |
| 10 |
539104323 |
ADJ. PLATE PAINTED Price: $23.99 |
| 11 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 11 |
609900 |
NUT-SPEED Price: $7.99 |
| 12 |
125-9603-03 |
PLATE-COVER, FUSE Price: $14.06 |
| 12 |
596273101 |
Pins This part replaces 539976989. Price: $2.99 |
| 13 |
125-7438 |
KNOB-SCREW, THUMB Price: $2.73 |
| 13 |
596564404 |
Bolts This part replaces 539990629. Price: $2.99 |
| 14 |
32115-15 |
PUSHNUT-RETAINER, BOLT This part replaces 106-8737. Price: $0.99 |
| 14 |
539102515 |
GRIP Price: $3.99 |
| 15 |
121-8481 |
PANEL-AIR/HEAT Price: $48.23 |
| 16 |
539105050 |
LIFT LINKAGE,PAINTED Price: $23.99 |
| 17 |
122-0150 |
SWITCH, ROTARY Price: $26.70 |
| 17 |
539101232 |
BUSHING, FLANGED Price: $11.99 |
| 18 |
125-9510 |
KNOB-CONTROL Price: $4.99 |
| 18 |
539104761 |
GREASE ZERK LONG Price: $2.99 |
| 19 |
539108354 |
SHAFT LIFT REAR Price: $108.99 |
| 19 |
99-7420 |
PLUG-HOLE Price: $7.64 |
| 20 |
539976982 |
WASHER 5/8 FLAT Price: $3.99 |
| 20 |
95-8999 |
SWITCH Price: $42.14 |
| 21 |
125-9691-03 |
PANEL-SWITCH, LIGHTS Price: $11.73 |
| 21 |
539990654 |
COTTER PIN Price: $2.99 |
| 22 |
125-9688 |
DECAL-WASHER Price: $3.04 |
| 22 |
539104808 |
PILLOW BLOCK Price: $7.99 |
| 23 |
119-8355 |
SWITCH-ROCKER Price: $108.05 |
| 23 |
584392702 |
REINFORCEMENT.PLATEX431 This part replaces 539104807. Price: $11.99 |
| 24 |
125-7437 |
LIGHT-DOME Price: $52.67 |
| 24 |
539991046 |
BOLT 5/16C X 2 1/2 Price: $3.99 |
| 25 |
130-5867 |
COVER-LIGHT, REAR Price: $23.83 |
| 26 |
3229-34 |
SCREW-CARR Price: $1.99 |
| 26 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 27 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 27 |
539101982 |
EYEBOLT, RH Price: $37.99 |
| 28 |
132-3600 |
DECAL-PANEL, FUSE Price: $4.13 |
| 28 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 29 |
539104760 |
DECK LIFT SPRING Price: $5.99 |
| 30 |
130-0436 |
PANEL-SWITCH Price: $4.11 |
| 30 |
539101050 |
GRIP Price: $2.99 |
| 31 |
539104523 |
PIN Price: $7.99 |
| 31 |
92-9698 |
SCREW-SHOULDER Price: $3.63 |
| 32 |
94-8196 |
WASHER-NYLON Price: $4.44 |
| 33 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 33 |
539101058 |
SPRING Price: $3.99 |
| 34 |
104-7201 |
NUT-HF Price: $0.69 |
| 34 |
539923787 |
BSHG .875 X 1.375 X .074 ZD Price: $2.99 |
| 35 |
539990761 |
NUT 1/4C CENTER LOCK Price: $2.99 |
| 36 |
539101082 |
ROLL PIN 3/16 X 1-1/4 ZD Price: $2.99 |
| 37 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 38 |
539101802 |
E-RING 7/8 Price: $2.99 |
| 39 |
539104310 |
CONNECTING LINK Price: $22.99 |
| 40 |
539990655 |
HCS 3/8C X 1 1/2 Price: $3.99 |
| 41 |
539105181 |
LIFT PEDAL BLK Price: $84.99 |
| 42 |
539105187 |
ANTI-SKID PAD Price: $2.99 |
| 43 |
539105184 |
TIGHTENING PLATE BLK Price: $37.99 |
| 44 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
