| Ref | Part Number | Description |
|---|
| 1 |
18-2970 |
CLIP-FUEL LINE Price: $8.67 |
| 1 |
431082 |
Hub, Clutch Pulley Price: Call Us |
| 2 |
04003-49 |
Bolt, Carriage 3/8-16 x 1" Price: Call Us |
| 2 |
32144-41 |
SCREW-TAPTITE Price: $4.79 |
| 3 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 3 |
424367 |
Quick Pin, 5/16" Dia. Price: Call Us |
| 4 |
04003-23 |
Carriage Bolt, 3/8-16 x 1.0" Price: Call Us |
| 4 |
52-4360 |
DISCONTINUED Price: Call Us |
| 5 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 5 |
323-6 |
SCREW-HH Price: $0.66 |
| 6 |
04043-04 |
Flatwasher, 3/8 (.391 x .938 x .105 HD) Grade 8 Price: Call Us |
| 6 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 7 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 7 |
32105-8 |
SCREW-SHH Price: $1.99 |
| 8 |
04021-05 |
Bolt, Hex Head 3/8-16 x 1" Ser. Flg. Price: Call Us |
| 8 |
62-7770 |
KEY-IGNITION This part replaces 218-412. Price: $4.39 |
| 9 |
486324 |
Pulley, 5.73 OD, Double Groove Price: Call Us |
| 9 |
52-3890 |
DISCONTINUED Price: Call Us |
| 10 |
04001-224 |
Hub, Tapered, 1" Bore Price: Call Us |
| 10 |
52-4100 |
DISCONTINUED Price: Call Us |
| 11 |
2812-4 |
REDUCER-PIPE Price: $9.67 |
| 11 |
483285 |
Pulley, Double Groove Price: Call Us |
| 12 |
353-880 |
DISCONTINUED Price: Call Us |
| 12 |
48141 |
TAPERED HUB, 1.00" BORE Price: Call Us |
| 13 |
04063-01 |
Key, 1/4 x 1/4 x 1.25" Pulley Mtg. Price: Call Us |
| 13 |
2811-10 |
ELBOW-STREET, 90 DEG Price: $11.68 |
| 14 |
486380 |
Gearbox Assembly Price: Call Us |
| 14 |
52-4290 |
STRAP-BATTERY BOX Price: $31.67 |
| 15 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 15 |
52-4320 |
DISCONTINUED Price: Call Us |
| 16 |
04001-09 |
Bolt, Heax Head 5/16-18 x 1" (48V / 52V) Price: Call Us |
| 16 |
52-4310 |
DISCONTINUED Price: Call Us |
| 17 |
427811 |
Mounting Bracket, Gearbox Price: Call Us |
| 17 |
52-3900 |
DISCONTINUED Price: Call Us |
| 18 |
32153-3 |
NUT-HEX, SIDE DEFORM Price: $5.59 |
| 18 |
427882 |
Support Strap, Gearbox Price: Call Us |
| 19 |
428002 |
Mounting Plate, Gearbox Price: Call Us |
| 19 |
52-4410 |
DISCONTINUED Price: Call Us |
| 20 |
04001-46 |
Bolt, Hex Head 3/8-16 x 2-1/4" - 61" Price: Call Us |
| 20 |
52-3810 |
DISCONTINUED Price: Call Us |
| 21 |
453492 |
Idler Arm Bracket, Gearbox Price: Call Us |
| 21 |
52-4330 |
BOX HOLD DOWN *R Price: $103.57 |
| 22 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 22 |
43689 |
Pivot, Idler Short Price: Call Us |
| 23 |
322-3 |
SCREW-HH Price: $0.79 |
| 23 |
48224 |
BEARINGS, BALL, NEUTRAL RETURN Price: Call Us |
| 24 |
04001-54 |
Bolt, Hex Head 3/8-16 x 3" - 52" Price: Call Us |
| 24 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 25 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 25 |
463157 |
Idler Arm Assembly, Gearbox Output (INCL. 23) Price: Call Us |
| 26 |
322-6 |
SCREW-HH Price: $0.45 |
| 26 |
486265 |
Clutch, GT3.5 (28.6mm Bore) Price: Call Us |
| 27 |
04063-28 |
Key, 1/4 x 1/4 x 3-1/2" Price: Call Us |
| 27 |
12-8140 |
KEY SWITCH Price: $39.86 |
| 28 |
04041-28 |
Flatwasher, 7/16-.469 x 1.75 x .25 (48, 52) Price: Call Us |
| 28 |
3219-14 |
NUT-HEX Price: $0.25 |
| 29 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 29 |
3253-2 |
WASHER-LOCK Price: $0.25 |
| 30 |
04102-06 |
Bolt, Hex Head 7/16-20 x 3" w/t Patch Price: Call Us |
| 30 |
52-3860 |
DISCONTINUED Price: Call Us |
| 31 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 31 |
486172 |
Pulley, Clutch 7.30 DIA Price: Call Us |
| 32 |
38-0430 |
SWITCH Price: $54.52 |
| 32 |
486323 |
Belt, Gearbox Input Price: Call Us |
| 33 |
40-7420 |
DISCONTINUED Price: Call Us |
| 33 |
48181 |
IDLER PULLEY, "V" GROOVE Price: Call Us |
| 34 |
04001-51 |
Capscrew, Hex Head 3/8-16 x 3-3/4" Price: Call Us |
| 34 |
353-704 |
DISCONTINUED Price: Call Us |
| 35 |
04001-172 |
Bolt, Hex Head 1/4-20 x 1" Grade 8 Black Price: Call Us |
| 35 |
38-3260 |
DISCONTINUED Price: Call Us |
| 36 |
237-7 |
O-RING Price: $8.82 |
| 36 |
486267 |
Pulley, Gearbox Input, 6.95 DIA, Double Groove Price: Call Us |
| 37 |
463156 |
Idler Arm Assembly, Gearbox Input (INCL. 23) Price: Call Us |
| 37 |
52-3850 |
Strap-Battery Holddown Price: Call Us |
| 38 |
04001-139 |
Bolt, Hex Head 3/8-16 x 2-1/2" Grade 8 Price: Call Us |
| 38 |
323-39 |
SCREW-HH This part replaces 323-21. Price: $1.60 |
| 39 |
483112 |
Spring, Transmission Drive Price: Call Us |
| 39 |
52-4470 |
DISCONTINUED Price: Call Us |
| 40 |
04001-136 |
Bolt, Hex Head 3/8-16 x 1-1/2" Grade 8 Black Price: Call Us |
| 40 |
52-4350 |
SUPPORT-SW BAIL *R Price: $67.14 |
| 41 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 41 |
483210 |
Pulley, Idler 5" Dia. Price: Call Us |
| 42 |
04112-06 |
Nut, 3/4-16 Spriral Lock Price: Call Us |
| 42 |
321-3 |
SCREW-HH Price: $0.28 |
| 43 |
486266 |
Pulley, Blower, 6.95 DIA, Double Groove Price: Call Us |
| 43 |
5-4460 |
WASHER-PIVOT This part replaces 5-1350. Price: $6.19 |
| 44 |
52-4340 |
PIVOT SWITCH Price: $50.84 |
| 45 |
3-8664 |
WASHER-THRUST Price: $5.69 |
| 46 |
2412-85 |
DISCONTINUED Price: Call Us |
| 47 |
218-331 |
BATTERY BOOT Price: $9.89 |
| 48 |
44-8520 |
DISCONTINUED Price: Call Us |
| 49 |
2412-84 |
DISCONTINUED Price: Call Us |
| 50 |
52-4370 |
DISCONTINUED Price: Call Us |
