| Ref | Part Number | Description |
|---|
| 1 |
69-9560-01 |
HOUSING-CONTROL This part replaces 69-9560. Price: $199.96 |
| 2 |
3234-7 |
SCREW-HHF Price: $1.99 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
80-9330 |
AUDIO ALARM ASM Price: $137.61 |
| 4 |
323-4 |
SCREW-HH Price: $1.02 |
| 5 |
71-4270 |
DISCONTINUED Price: Call Us |
| 6 |
69-6260 |
MAGNET Price: $58.32 |
| 7 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 8 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 10 |
43-4000 |
CIRCUIT BREAKER Price: $116.55 |
| 11 |
3290-133 |
SCREW Price: $1.19 |
| 12 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 13 |
69-7040 |
HOLDER-CUP Price: $57.78 |
| 14 |
321-3 |
SCREW-HH Price: $0.28 |
| 15 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
71-2430-03 |
REAR PLATE ASM This part replaces 71-2430. Price: $54.89 |
| 17 |
532197296 |
SPRING.BRAKE.HG3000/3500 Price: $5.99 |
| 17 |
71-4130 |
SUPPORT-CONTROL Price: $347.75 |
| 18 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 19 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 21 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 22 |
98-4437 |
CONTROLLER ASM This part replaces 71-2480. Price: $1,680.76 |
| 23 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 24 |
67-7160 |
BLOCK-FUSE Price: $18.75 |
| 25 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 26 |
69-8210-03 |
SUPPORT-COVER This part replaces 69-8210. Price: $47.02 |
| 27 |
32128-20 |
NUT-HF Price: $0.99 |
| 29 |
532197659 |
ROD.BRAKE.HG-0510 Price: $19.99 |
| 30 |
84-5270 |
VOLTAGE REGULATOR Price: $226.12 |
| 31 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 32 |
80-4890 |
DECAL - SERVICE Price: $26.87 |
| 33 |
109355 |
FUSE-BLADE, 15 AMP This part replaces 218-581. Price: $3.09 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 35 |
583864502 |
Rods This part replaces 532199591. Price: $6.99 |
| 37 |
532121749 |
WASHER Price: $2.99 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 56 |
532140218 |
V-BELT. Price: $49.99 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 73 |
595316601 |
Bolts This part replaces 874490544. Price: $3.99 |
| 80 |
532400507 |
BRKT.STRP.TRQ.LT.HYD.C Price: $12.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT This part replaces 532195403. Price: $9.99 |
| 163 |
532199000 |
ROD.PEDAL.CONTROL.0510 Price: $27.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532196211. Price: $2.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 532403118. Price: $9.99 |
| 185 |
596435101 |
Bolts This part replaces 872110620. Price: $2.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
532195804 |
LINK.CLUTCH.ANIT-ROTAT Price: $5.99 |
| 203 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH This part replaces 532197867. Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 532197868. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX This part replaces 532401722. Price: $6.99 |
| 215 |
532401723 |
PEDAL.REVERSE.TEX.GT.4 Price: $12.99 |
