| Ref | Part Number | Description |
|---|
| 1 |
532160525 |
CHASSIS KIT This part replaces 532159527. Price: $88.41 |
| 1 |
86-5570 |
HOSE ASM Price: $151.86 |
| 2 |
532145009 |
KIT.DRAWBAR.SERVICE This part replaces 532140356. Price: $44.99 |
| 2 |
86-3220 |
HOSE ASM Price: $68.45 |
| 3 |
237-22 |
O-RING Price: $2.43 |
| 3 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 4 |
340-138 |
FITTING-HYD, 45 DEG Price: $31.15 |
| 4 |
819131216 |
Washer 13/32 x 3/4 x 16 Ga. Price: $2.99 |
| 5 |
237-79 |
O-RING Price: $5.46 |
| 5 |
532155272 |
BUMPER.RUBBER.HOOD Price: $3.99 |
| 6 |
21-9260 |
COVER-DUST Price: $8.19 |
| 7 |
76-8140-03 |
BRACKET-GEAR, STEERING Price: $70.53 |
| 8 |
76-8160-03 |
SUPPORT-GEAR, STEERING Price: $25.24 |
| 9 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 9 |
532161916 |
DASH This part replaces 532157261. Price: $19.39 |
| 10 |
323-6 |
SCREW-HH Price: $0.66 |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX This part replaces 532155927. Price: $9.99 |
| 11 |
74-3670 |
DISCONTINUED Price: Call Us |
| 12 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 13 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 13 |
532172107 |
DASH PANEL ASM. This part replaces 532157262. Price: $9.99 |
| 14 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 14 |
82-4950 |
PLUNGER-SPRING Price: $145.10 |
| 15 |
74-5770-03 |
DISCONTINUED Price: Call Us |
| 16 |
32121-10 |
PIN-ROLL Price: $6.99 |
| 17 |
532156051 |
HOOD - LT/YT Price: $549.99 |
| 17 |
74-5790 |
SHAFT-PIVOT Price: $75.26 |
| 18 |
32121-123 |
PIN-ROLL Price: $0.81 |
| 18 |
532126938 |
BUMPER HOOD T Price: $3.99 |
| 19 |
3220-3 |
NUT-HJ Price: $0.28 |
| 20 |
323-8 |
SCREW-HH Price: $1.20 |
| 20 |
532180679 |
PLATE MTG.BATTERY/FUEL TANK This part replaces 532156437. Price: $9.99 |
| 21 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 22 |
76-9100 |
SPACER Price: $4.07 |
| 23 |
532124028 |
BUSHING.SNAP.NYL.BLK. Price: $4.99 |
| 23 |
93-9415 |
PANEL-CONTROL, TOWER Price: $68.85 |
| 24 |
233-17 |
KNOB Price: $10.58 |
| 25 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 25 |
68-8080 |
WHEEL-STEERING Price: $273.84 |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 26 |
72-0130 |
DISCONTINUED Price: Call Us |
| 27 |
107-2561 |
NUT-HEX This part replaces 47-6990. Price: $14.65 |
| 28 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 28 |
532156880 |
GRILLE.LT.P/L HUSQVARNA.SERVIC This part replaces 532149776. Price: $256.99 |
| 29 |
532149777 |
LENS LT/PL HUSQVARNA Price: $24.99 |
| 29 |
76-9450 |
DISCONTINUED Price: Call Us |
| 30 |
532192813 |
FENDER W/OUT CUP HOLDER This part replaces 532156489. Price: $125.54 |
| 30 |
84-0680 |
LINK-SHIFT V Price: $32.00 |
| 31 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 31 |
532139976 |
BRACKET.SUPPORT.FENDER Price: $14.99 |
| 32 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 33 |
69-1560-03 |
DISCONTINUED Price: Call Us |
| 34 |
2410-64 |
PLUG-BUTTON Price: $0.74 |
| 35 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 36 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 37 |
63-7900-03 |
RACK Price: $144.55 |
| 38 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 38 |
532139886 |
BRACKET LH PIVOT Price: $6.99 |
| 39 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 39 |
532139887 |
BRACKET RH PIVOT Price: $6.99 |
| 40 |
95-1821 |
SPRING-COMPRESSION This part replaces 95-1821-03. Price: $6.71 |
| 41 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 42 |
76-9050 |
ROD-BRAKE, PARK Price: $33.40 |
| 43 |
86-5730 |
RH FRONT TUBE ASM Price: $85.91 |
| 44 |
86-5740 |
LH FRONT TUBE ASM Price: $126.12 |
| 45 |
94-8299 |
STEERING TUBE ASM Price: $135.28 |
| 46 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 47 |
3256-71 |
WASHER-FLAT Price: $0.81 |
| 48 |
32144-57 |
SCREW Price: $1.04 |
| 49 |
2412-74 |
R-CLAMP Price: $2.37 |
| 50 |
340-159 |
FITTING-HYD, 90 DEG Price: $55.33 |
| 51 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 51 |
86-3210 |
DISCONTINUED Price: Call Us |
| 52 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 52 |
95-4375 |
DISCONTINUED Price: Call Us |
| 53 |
340-70 |
NUT-LOCK Price: $2.10 |
| 53 |
532150067 |
BRACKET PNT PICK OFF LT/PL Price: $1.64 |
| 54 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 55 |
20-9500 |
WASHER Price: $3.53 |
| 56 |
31-0390 |
DISC-FRICTION Price: $11.25 |
| 57 |
596230901 |
Screws This part replaces 874780412. Price: $2.99 |
| 57 |
76-8340 |
SHAFT-PIVOT, STEERING Price: $89.60 |
| 58 |
532150127 |
AIR DUCT P/L/LT Price: $13.99 |
| 58 |
76-8150-03 |
SUPPORT-SHAFT, STEERING Price: $25.87 |
| 59 |
92-9729 |
DISCONTINUED Price: Call Us |
| 60 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 60 |
872140606 |
Bolt Rdhd Sqnk 3/8-16unc x 3/4 Price: $4.99 |
| 61 |
59-6430 |
DISCONTINUED Price: Call Us |
| 64 |
532154798 |
DASH LOWER Price: $17.99 |
| 68 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 71 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873680400. Price: $3.99 |
| 74 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 122 |
532157301 |
BRACKET SHIFT STLT Price: $7.99 |
| 123 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 129 |
596582301 |
Washers This part replaces 819091016. Price: $2.99 |
| 134 |
532160219 |
ROD SUPPORT HOOD LT/PL HUS. Price: $7.99 |
| 140 |
532158418 |
BRACKET SUSPENSION FRONT Price: $7.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT This part replaces 532156095. Price: $7.99 |
| 143 |
532186689 |
BRACKET, SWAYBAR CHASSIS This part replaces 532154966. Price: $5.99 |
| 144 |
532175582 |
BRKT, FOOT REST This part replaces 532154207. Price: $4.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 147 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
