| Ref | Part Number | Description |
|---|
| 1 |
BS-212897 |
CAMSHAFT & GEAR Not Available Price: |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 2 |
BS-261183 |
TAPPET VALVE Not Available Price: |
| 3 |
BS-490348 |
CONNECTING ROD ASSEMBLY Not Available This part replaces BS-391775. Price: |
| 4 |
BS-222299 |
LOCK Not Available Price: |
| 5 |
BS-92909 |
SCREW CONNECTING ROD Not Available Price: |
| 6 |
BS-391285 |
PISTON ASSY, STANDARD Not Available Price: |
| 7 |
BS-499996 |
PISTON RING SET STD Not Available This part replaces BS-391780. Price: |
| 8 |
BS-299691 |
PIN Not Available Price: |
| 9 |
BS-260924 |
LOCK PISTON PIN Not Available Price: |
| 10 |
BS-222725 |
COVER CYLINDER HEAD Not Available Price: |
| 11 |
BS-222744 |
SHIELD CYLINDER Not Available Price: |
| 12 |
BS-398333 |
Housing, Blower Price: Call Us |
| 13 |
BS-65906 |
SPRING Not Available Price: |
| 14 |
BS-690656 |
VALVE RETAINER Not Available This part replaces BS-221596. Price: |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 15 |
BS-26828 |
SPRING Not Available Price: |
| 16 |
BS-494553 |
RETAINER-ROTO Not Available This part replaces BS-93630. Price: |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 17 |
BS-691939 |
VALVE RETAINER Not Available This part replaces BS-292260. Price: |
| 18 |
BS-93585 |
SCREW-SEM-SUMP MOUNTING Not Available Price: |
| 19 |
BS-690946 |
Plug-Oil Drain (Square Socket) This part replaces BS-91084. Price: $5.60 |
| 20 |
BS-261185 |
VALVE EXHAUST Not Available Price: |
| 21 |
BS-261462 |
VALVE INTAKE Not Available Price: |
| 22 |
BS-281658S |
Cap-Oil Fill This part replaces BS-66768. Price: $4.37 |
| 23 |
BS-291675S |
OIL SEAL Not Available This part replaces BS-291675. Price: |
| 24 |
BS-391784 |
BASE-ENGINE Not Available Price: |
| 25 |
BS-271702S |
CRANKCASE GASKET Not Available This part replaces BS-271702. Price: |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 26 |
BS-391086S |
Seal-Oil (Magneto Side) This part replaces BS-391086. Price: $7.18 |
| 27 |
BS-491986 |
CRANK BUSHING Not Available This part replaces BS-231055. Price: |
| 28 |
BS-23513 |
BUSHING Not Available Price: |
| 29 |
None |
Cylinder Assy |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 30 |
BS-691968 |
Governor/Oil Slinger This part replaces BS-490815. Price: $46.54 |
| 31 |
BS-691666 |
BREATHER ASSEMBLY SCREW Not Available This part replaces BS-93394. Price: |
| 32 |
BS-495735 |
BREATHER ASSEMBLY Not Available This part replaces BS-391406. Price: |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 33 |
BS-27803S |
BREATHER GASKET Not Available This part replaces BS-27803. Price: |
| 34 |
BS-692253 |
BREATHER TUBE Not Available This part replaces BS-280100. Price: |
| 35 |
583864502 |
Rods Price: $6.99 |
| 35 |
BS-222698S |
Key-Flywheel (Aluminum) This part replaces BS-222698. Price: $3.71 |
| 36 |
BS-696537 |
RING GEAR Not Available This part replaces BS-392134. Price: |
| 37 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 37 |
BS-212359 |
LINK COUNTERWEIGHT Not Available Price: |
| 38 |
BS-392299 |
CRANKSHAFT Not Available Price: |
| 39 |
BS-261196 |
Gear, Timing Price: Call Us |
| 40 |
BS-391988 |
FLYWHEEL & RING GEAR ASSY - MAGNETO Not Available Price: |
| 41 |
BS-391373 |
WEIGHT-COU Not Available Price: |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532008883. Price: $4.99 |
| 42 |
BS-298909 |
Pin, Counterweight Price: $8.83 |
| 43 |
BS-231038 |
Spacer, Counterweight Price: Call Us |
| 44 |
BS-93875 |
Screw, Counterweight Price: Call Us |
| 45 |
BS-19203 |
Puller, Flywheel Price: $18.70 |
| 46 |
BS-691748 |
ROTATING SCREEN Not Available This part replaces BS-222562. Price: |
| 47 |
IH-77652-C1 |
SCREEN Not Available Price: |
| 48 |
BS-220865 |
Washer, Spring Price: Call Us |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 49 |
712-3056 |
Nut, 5/8-NF Price: $4.21 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 50 |
BS-212914 |
HEAD, CYLINDER Not Available Price: |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
BS-271866S |
CYLINDER HEAD GASKET Not Available This part replaces BS-271866. Price: |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 52 |
BS-93723 |
SCREW Not Available Price: |
| 53 |
BS-298968 |
ARMATURE Not Available Price: |
| 54 |
759-3331 |
SPARK PLUG RCJ8 Not Available Price: |
| 55 |
BS-66538S |
Boot-Spark Plug This part replaces BS-66538. Price: $4.77 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 56 |
IH-539882-R1 |
Clip, Wire Price: Call Us |
| 57 |
BS-493880S |
Terminal-Spark Plug This part replaces BS-221798. Price: $4.46 |
| 63 |
IH-77649-C1 |
Wire, Ground Price: Call Us |
| 64 |
None |
Screw, No. 8 X 5/8 Mach Ground |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 65 |
BS-66068 |
Washer, Insulating Price: Call Us |
| 66 |
BS-691077 |
Washer (Ground Terminal) This part replaces BS-92791. Price: $11.38 |
| 67 |
712-0142 |
Nut, No. 8 Mach Price: $3.90 |
| 68 |
BS-66554 |
Collar, Insulating Price: Call Us |
| 69 |
583404901 |
HAIRPIN.SOFT.ZINC.059X1.125 This part replaces 532423303. Price: $2.99 |
| 69 |
BS-592828 |
ALTERNATOR This part replaces BS-391529. Price: $116.49 |
| 70 |
532439661 |
CONSOLE.ASM.RH.GT.FC.HUSQ Price: $79.99 |
| 73 |
596136501 |
Bolts This part replaces 874490540. Price: $3.99 |
| 74 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 74 |
BS-395405 |
STARTER COVER Not Available Price: |
| 75 |
BS-93306 |
COTTER PIN Not Available Price: |
| 76 |
BS-93307 |
RETAINER Not Available Price: |
| 77 |
BS-396349 |
PLATE-CONTROL Not Available Price: |
| 78 |
BS-691024 |
Clamp-Casing This part replaces BS-221535. Price: $6.90 |
| 79 |
BS-690804 |
SLOTTED HEX SCREW Not Available This part replaces BS-93496. Price: |
| 80 |
IH-77674-C1 |
LINK Not Available Price: |
| 81 |
BS-792813 |
Spring-Governor (Brown) This part replaces BS-261306. Price: $5.76 |
| 82 |
BS-261197 |
GOVERNOR SPRING Not Available Price: |
| 83 |
IH-76586-C1 |
Washer, Governor Crank Price: Call Us |
| 84 |
BS-692012 |
Governor Crank This part replaces BS-231058. Price: $47.28 |
| 85 |
BS-391733 |
LEVER Not Available Price: |
| 86 |
BS-92613 |
BOLT Not Available Price: |
| 87 |
BS-231082 |
HEX NUT Not Available Price: |
| 88 |
BS-93686 |
Screw, Gov Control Plate Mtg Price: Call Us |
| 89 |
BS-231039 |
Spacer Price: Call Us |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 99 |
582404501 |
ARM.PIVOTING.TCRD.GEN2.5.BAGGE Price: $5.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 539990858. Price: $2.99 |
| 153 |
532004497 |
RETAINER M Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods This part replaces 532448275. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 587653701. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
585658602 |
Stop This part replaces 585658601. Price: $4.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 587031401. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532197860 |
ROCKER.ASM.PEDAL.CONTR Price: $44.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 215 |
586606502 |
PEDAL.COVER.REVERSE.CRD.X428BK Price: $17.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 220 |
532198908 |
REFLECTOR.RH.TEX GT Price: $14.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 227 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 325 |
585668505 |
BRACKET TORQUE STRAP This part replaces 585668502. Price: $5.99 |
| 326 |
585670803 |
BRACKET TORQUE STRAP This part replaces 585670802. Price: $4.99 |
| 336 |
587259602 |
Bolts This part replaces 587259601. Price: $3.99 |
