| Ref | Part Number | Description |
|---|
| 1 |
106-0050 |
LH INNER COVER ASM This part replaces 69-6800. Price: $186.64 |
| 1 |
532199298 |
DECK.SVC.54".5GWB.GREY This part replaces 532403125. Price: $449.99 |
| 2 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 3 |
69-6360-01 |
PLATE-GEARBOX, LH ASM This part replaces 69-6360. Price: $258.21 |
| 4 |
32128-21 |
NUT-HF Price: $0.39 |
| 5 |
237-81 |
O-RING Price: $2.76 |
| 6 |
340-8 |
FITTING-STRAIGHT Price: $9.70 |
| 7 |
237-65 |
O-RING Price: $2.50 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 8 |
88-9360 |
HOSE ASSY Price: $386.10 |
| 9 |
88-9370 |
HOSE ASSY Price: $240.46 |
| 10 |
237-22 |
O-RING Price: $2.43 |
| 11 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 12 |
237-42 |
O-RING Price: $2.78 |
| 12 |
532404851 |
ROD.ANTI.SWAY.48/54"K4 Price: $22.99 |
| 13 |
597023501 |
MANDRELS This part replaces 532187291. Price: $24.99 |
| 13 |
94-4907 |
MOTOR-HYD This part replaces 69-2780. Price: $1,685.80 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 14 |
63-0660 |
GEARBOX PULLEY WA Price: $80.31 |
| 15 |
23-1640 |
BUSHING-TAPERLOCK Price: $68.50 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
106-0051 |
LH OUTER COVER ASM This part replaces 69-6810. Price: $251.73 |
| 16 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 17 |
3269-25 |
RIVET-POP Price: $0.27 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 18 |
69-6870 |
PLATE-MAGNET Price: $4.91 |
| 19 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 19 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 20 |
69-6260 |
MAGNET Price: $58.32 |
| 21 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
3233-30 |
SCREW-CARR Price: $3.26 |
| 23 |
69-6960 |
SPACER-IDLER Price: $22.57 |
| 24 |
140-5848 |
PULLEY-IDLER This part replaces 63-1540. Price: $62.48 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
32128-23 |
NUT-HF Price: $1.51 |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $4.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
3231-28 |
SCREW-CARR Price: $1.92 |
| 27 |
532187257 |
DEFLECTOR.BLACK.54" This part replaces 532188938. Price: $64.99 |
| 28 |
95-0845 |
DECAL-HOC This part replaces 71-4260. Price: $11.75 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $14.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 39 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH This part replaces 532197380. Price: $37.99 |
| 43 |
531169301 |
SERVICE KIT ARM.IDLER This part replaces 532196065. Price: $9.99 |
| 47 |
587686701 |
BELT.DECK.DRIVE.BELT.54 This part replaces 532196103. Price: $54.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 50 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 52 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 97 |
532178515 |
WASHER Price: $5.99 |
| 98 |
547878302 |
SPRING BELT TENSIONER BLACK This part replaces 532196105. Price: $5.99 |
| 113 |
596435701 |
Bolts This part replaces 872110508. Price: $2.99 |
| 114 |
532187556 |
ROD TENSION RELIEF Price: $17.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 120 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 122 |
532187557 |
BUSHING.RELIEF.TENSION Price: $7.99 |
| 184 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 185 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 187 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 190 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 192 |
532198468 |
KEEPER.BELT.IDLER.54"T Price: $7.99 |
| 194 |
874490736 |
BOLT.HEX.WASHER.HEAD.7/16-24X This part replaces 872140716. Price: $9.99 |
| 196 |
596337801 |
Bolts This part replaces 872140620. Price: $4.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
