| Ref | Part Number | Description |
|---|
| 1 |
35115A |
Cylinder Assembly (Incl. Ref. #2, 3 4) Price: Call Us |
| 2 |
26727 |
Pin-Dowel Price: Call Us |
| 3 |
27642 |
Plug-Drain, Oil (SQH 1/4-18) Price: Call Us |
| 4 |
32600 |
Seal-Oil Price: Call Us |
| 5 |
29314B |
Valve, Intake (Std.)(Incl. Ref. #9) Price: Call Us |
| 5 |
29315C |
Valve, Intake (1/32" Oversize) (Incl. Ref. #86) Price: Call Us |
| 6 |
29313C |
Valve, Exhaust (Std.) (Incl. Ref. #9) Price: Call Us |
| 6 |
29315C |
Valve, Intake (1/32" Oversize) (Incl. Ref. #86) Price: Call Us |
| 7 |
31671 |
Cap-Upper Valve Spring Price: Call Us |
| 8 |
31672 |
Spring-Valve Price: Call Us |
| 9 |
31673 |
Cap-Valve, Spring Price: Call Us |
| 11 |
35116 |
Crankshaft Assy. (Incl. Ref. #24) Price: Call Us |
| 12 |
32323 |
Washer-Thrust Price: Call Us |
| 13 |
34686 |
Decal-Name Price: Call Us |
| 14 |
34514 |
Piston, Pin Ring Assy. (Incl. Ref. #15 16) (Std.) Price: Call Us |
| 14 |
34515 |
Piston, Pin Ring Assy. (Incl. Ref. #15 16) (.010 0versize) Price: Call Us |
| 14 |
34516 |
Piston, Pin Ring Assy. (Incl. Ref. #15 16) (.020 0versize) Price: Call Us |
| 14A |
32538B |
Piston Pin Assy. (Incl. Ref. #16) (Std.) Price: Call Us |
| 14A |
32548B |
Piston Pin Assy. (Incl. Ref. #16) (.010 oversize) Price: Call Us |
| 14A |
32549B |
Piston Pin Assy. (Incl. Ref. #16) (.020 oversize) Price: Call Us |
| 15 |
28986 |
Piston Ring Set Std. Price: Call Us |
| 15 |
28987 |
Piston Ring Set .010 O.S. Price: Call Us |
| 15 |
28988 |
Piston Ring Set .020 O.S. Price: Call Us |
| 16 |
20381 |
Ring-Retaining, Piston Pin Price: Call Us |
| 17 |
32875 |
Rod Assembly, Connecting (Incl. Ref. #18 19) Price: Call Us |
| 18 |
32610A |
Bolt-Rod, Connecting Price: Call Us |
| 19 |
32654 |
Dipper-Oil Price: Call Us |
| 21 |
33149A |
Camshaft (Compression Release) Price: Call Us |
| 22 |
27241 |
Lifter-Valve Price: Call Us |
| 23 |
30756B |
Cover, Cylinder (Incl. No. 24, 25, 106 133) Price: Call Us |
| 24 |
28540 |
OIL SEAL Price: Call Us |
| 25 |
27625 |
Plug-Fill, Oil Price: Call Us |
| 28 |
650488 |
Screw (1/4-20 x 1-1/4) Price: Call Us |
| 33 |
30579 |
CYLINDER HEAD Price: Call Us |
| 34 |
33344 |
Baffle-Heat Price: Call Us |
| 35 |
650694A |
Screw (5/16-18 X 2) Price: Call Us |
| 36 |
6021A |
Screw (5/16-18x1-1/2) Price: Call Us |
| 37 |
33636 |
Plug, Spark (J17LM or equiv.) Price: Call Us |
| 37 |
34251 |
Plug, Spark (Champion RCJ-8) Price: Call Us |
| 39 |
27666 |
Body-Breather Price: Call Us |
| 40 |
31410 |
Element-Breather Price: Call Us |
| 41 |
34146 |
Cover-Breather Price: Call Us |
| 42 |
650128 |
Screw Price: Call Us |
| 43 |
32446 |
GROMMET Price: Call Us |
| 44 |
32447 |
Breather Tube Price: Call Us |
| 46 |
28416A |
Pipe, Intake (Incl. Ref. #48) Price: Call Us |
| 47 |
650664 |
Screw (1/4-20 x 1-19/32) Price: Call Us |
| 48 |
650840 |
Screw-Hex Hd. Price: Call Us |
| 49 |
111-1250 |
WHEEL 180X45 RIBBED This part replaces 6201. Price: $27.74 |
| 53 |
34694 |
Cup-Starter Price: Call Us |
| 54 |
35185 |
Screen-Starter Price: Call Us |
| 56 |
28539 |
Ring, Retainer Price: Call Us |
| 58 |
31858 |
Jet-Main Price: Call Us |
| 59 |
28537 |
Washer, Flat Price: Call Us |
| 60 |
28458 |
BALL BEARING Price: Call Us |
| 61 |
30200 |
Screw (10-24 x 9/16) Price: Call Us |
| 62 |
28277 |
Washer-Flat Price: Call Us |
| 63 |
31334 |
Rod-Governor Price: Call Us |
| 65 |
650561 |
Screw (1/4-20x19/32) Price: Call Us |
| 66 |
34346 |
Decal-Instruction Price: Call Us |
| 67 |
33341 |
Baffle-Extension Price: Call Us |
| 68 |
650701 |
Screw-Hex Washer Hd. Price: Call Us |
| 69 |
29212 |
Screw Price: Call Us |
| 70 |
33663C |
Housing, Blower Price: Call Us |
| 71 |
650815 |
Washer-Belleville Price: Call Us |
| 72 |
650816 |
Nut-Flywheel Price: Call Us |
| 73 |
29752 |
Nut and Lock Washer (1/4-28) Price: Call Us |
| 74 |
16645 |
Lockwasher Price: Call Us |
| 75 |
30747 |
Clip, Shorting Price: Call Us |
| 76 |
31708 |
BRACKET, AIRCLEANER Price: Call Us |
| 77 |
28820 |
Screw (10-32 x 1/2) Price: Call Us |
| 78 |
31700 |
AIRCLEANER Price: Call Us |
| 79 |
31715 |
Body-Air Cleaner Price: Call Us |
| 80 |
650152 |
Screw Price: Call Us |
| 82 |
31426 |
Spring-Extension Price: Call Us |
| 83 |
28942 |
Screw (10-32 x 3/8) Price: Call Us |
| 84 |
27793 |
Conduit Price: Call Us |
| 85 |
31342 |
Spring-Compression Price: Call Us |
| 86 |
650549 |
Screw Price: Call Us |
| 89 |
29752 |
Nut and Lock Washer (1/4-28) Price: Call Us |
| 90 |
650168 |
Washer Price: Call Us |
| 91 |
33879A |
Control Assy., Speed (Incl. Ref. #42, 85, 86 95) Price: Call Us |
| 92 |
28942 |
Screw (10-32 x 3/8) Price: Call Us |
| 93 |
27261 |
Washer Price: Call Us |
| 94 |
33966 |
Bracket-Gov. Speed Limit Price: Call Us |
| 98 |
650695A |
Screw, Hex Flange Hd. Price: Call Us |
| 100 |
31510 |
Lever-Governor Price: Call Us |
| 101 |
31335 |
Clamp-Lever, Governor Price: Call Us |
| 102 |
650548 |
Screw Price: Call Us |
| 103 |
650691 |
Washer-Flat Price: Call Us |
| 105 |
30590A |
Washer-Flat Price: Call Us |
| 106 |
30574 |
Shaft-Governor Price: Call Us |
| 107 |
30591 |
Gear Assy., Governor (Incl. No.132) Price: Call Us |
| 108 |
29193 |
Ring-Retaining Price: Call Us |
| 109 |
30588A |
Spool-Governor Price: Call Us |
| 111 |
34183A |
Plate, Fuel Tank Price: Call Us |
| 112 |
34182 |
Bracket-Fuel Tank Price: Call Us |
| 113 |
650561 |
Screw (1/4-20x19/32) Price: Call Us |
| 114 |
34156 |
Tank Assy.,Fuel (Incl. Ref. #115) Price: Call Us |
| 115 |
33032 |
Cap-Fuel Price: Call Us |
| 116 |
650665 |
Screw (1/4-15x7/8) Price: Call Us |
| 117 |
32961 |
Valve-Shut Off Price: Call Us |
| 118 |
34682 |
Line-Fuel Price: Call Us |
| 118A |
29774 |
Line-Fuel (8.62) Price: Call Us |
| 119 |
26460 |
Clamp-Line, Fuel Price: Call Us |
| 120 |
650128 |
Screw Price: Call Us |
| 121 |
29745 |
Extension-Blower Price: Call Us |
| 123 |
34212 |
Bracket-Hold Down Price: Call Us |
| 124 |
30200 |
Screw (10-24 x 9/16) Price: Call Us |
| 128 |
34080 |
Spacer Price: Call Us |
| 129 |
34443A |
Solid State Price: Call Us |
| 130 |
650814 |
Screw Price: Call Us |
| 131 |
650872 |
Stud Price: Call Us |
| 132 |
611080 |
Clip Price: Call Us |
| 133 |
610961 |
Key-Flywheel Price: Call Us |
| 145 |
631921 |
Carburetor (Incl. Ref. #87) Price: Call Us |
