| Ref | Part Number | Description |
|---|
| 1 |
532170803 |
CONTROL, THROTTLE Price: $24.99 |
| 1 |
94-2672 |
CHUTE ASSEMBLY This part replaces 44-5300. Price: $596.99 |
| 2 |
3290-409 |
RIVET Price: $0.34 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 4 |
82-5510 |
DECAL-WARNING Price: $7.09 |
| 5 |
532181444 |
EXHAUST TUBE LH KAWI Price: $54.99 |
| 5 |
56-4780-03 |
IMPELLER ASM This part replaces 56-4780. Price: $926.99 |
| 6 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 6 |
532181442 |
EXHAUST TUBE RH KAWI Price: $59.99 |
| 7 |
59-5070-03 |
MTG PLATE ASM This part replaces 59-5070. Price: $328.99 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 8 |
74-0910-03 |
BRACKET This part replaces 59-4980. Price: $63.99 |
| 9 |
59-5050 |
LH BRACKET ASM, WELDED Price: $122.99 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 10 |
59-5140-03 |
BLOWER MT ASM This part replaces 59-5140. Price: $186.99 |
| 11 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 12 |
62-6520 |
KNOB Price: $7.79 |
| 13 |
3257-40 |
KEY Price: $7.99 |
| 14 |
53-4530-03 |
GEAR BOX ASM This part replaces 53-4530. Price: $1,650.99 |
| 15 |
59-5150-01 |
GEARBOX COVER This part replaces 59-5150. Price: $41.91 |
| 16 |
3255-17 |
WASHER-LOCK, EXT Price: $0.29 |
| 17 |
3290-134 |
SCREW Price: $0.27 |
| 18 |
323-7 |
SCREW-HH Price: $0.65 |
| 19 |
74-0910-03 |
BRACKET This part replaces 59-5000. Price: $63.99 |
| 20 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 21 |
3218-3 |
NUT-JAM Price: $0.25 |
| 22 |
59-5090 |
RH BRACKET ASM, WELDED Price: $129.99 |
| 23 |
322-3 |
SCREW-HH Price: $0.79 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 24 |
44-5460-03 |
LH PLT BRKT This part replaces 44-5460. Price: $16.99 |
| 25 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 25 |
532190784 |
THROTTLE CONTROL This part replaces 532191694. Price: $22.99 |
| 26 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 26 |
873920600 |
Nut, Keps 3/8-24 unf Price: $3.99 |
| 27 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 28 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
63-9710 |
SPACER-BEARING Price: $10.24 |
| 30 |
321-3 |
SCREW-HH Price: $0.28 |
| 31 |
13-0269 |
BLOWER HOUSING ASM Price: $579.99 |
| 32 |
37-6730 |
CUP-BEARING Price: $15.84 |
| 32 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 33 |
38-7820 |
BEARING-BALL Price: $13.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
63-9700-03 |
PLATE-COVER This part replaces 63-9700. Price: $18.43 |
| 35 |
43-0940 |
SPACER Price: $1.25 |
| 36 |
3235-22 |
SCREW-HH, LOCK Price: $2.59 |
| 37 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 38 |
43-0960-03 |
BRACKET-CHUTE This part replaces 43-0960. Price: $18.26 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 101 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 105 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
