| Ref | Part Number | Description |
|---|
| 4 |
683-0254B |
Bracket Assembly, Deck, Hanger LH Not Available This part replaces 683-0254. Price: |
| 9 |
710-0528 |
Hex Cap Screw, 5/16-18 x 1.25 Price: $3.90 |
| 11 |
710-0650 |
Self Tapping Screw, 5/16-18 x .875 Price: $3.71 |
| 12 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 13 |
710-1260A |
Self Tapping Screw, 5/16-18 x .75 Price: $3.34 |
| 17 |
712-0417A |
HEX NUT Price: $6.50 |
| 19 |
912-3027 |
LOCK NUT 1/4 This part replaces 712-3027. Price: $3.85 |
| 20 |
714-0104 |
Internal Cotter Pin, .072 x 1.12 Price: $3.90 |
| 21 |
917-04074 |
Adjustment, Deck, Gear This part replaces 717-1553. Price: $11.45 |
| 22 |
631-05229 |
CHUTE ASSEMBLY This part replaces 731-1032A. Price: $71.37 |
| 23 |
932-0306A |
COMPRESSION SPRING This part replaces 732-0306. Price: $7.69 |
| 25 |
734-06265 |
DECK WHEEL (5.0 DIA X 1.38) This part replaces 734-0973. Price: $11.69 |
| 26 |
736-0105 |
Bell Washer, .401 x .87 x .063 Price: $3.96 |
| 27 |
936-0119 |
LOCK WASHER 5/16 This part replaces 736-0119. Price: $4.29 |
| 29 |
938-0373 |
Shoulder Bolt, .496 x 1.525:3/8-16 This part replaces 738-0373. Price: $8.45 |
| 32 |
747-1116 |
Deck Release Pin Price: $11.17 |
| 40 |
96606 |
Retainer Hook Bracket This part replaces 16606. Price: $6.71 |
| 41 |
918-04197B |
PULLEY & SPINDLE ASSEMBLY 5.75" W/O FTG This part replaces 618-0324. Price: $138.69 |
| 43 |
710-0604A |
Self-tapping Screw, 5/16-18 x .625 This part replaces 710-0604. Price: $3.96 |
| 44 |
712-0181 |
Top Lock Jam Nut, 3/8-16 Price: $3.90 |
| 45 |
712-0271 |
Hex Sems Nut, 1/4-20 Price: $3.78 |
| 47 |
731-2231B |
Belt Cover This part replaces 731-2231. Price: $40.56 |
| 48 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 49 |
942-0616A |
Blades This part replaces 7420616. Price: $29.15 |
| 51 |
OEM-190-116 |
Mulch Kit This part replaces 7311643A. Price: $89.03 |
| 52 |
712-3087 |
WING NUT 1/4-20 Price: $3.53 |
| 53 |
712-0291 |
Center Lock Nut, 1/4-20 Price: $3.93 |
| 54 |
710-0106 |
Hex Cap Screw, 1/4-20 x 1.25 Price: $3.66 |
| 56 |
736-0173 |
Flat Washer, .28 x .74 x .063 Price: $3.76 |
