| Ref | Part Number | Description |
|---|
| 1 |
112-1350 |
STARTER ASM This part replaces 70-8760. Price: $448.98 |
| 1 |
598602801 |
Decks This part replaces 532402999. Price: $349.99 |
| 2 |
67-4610 |
BOLT W/WASHER Price: $2.32 |
| 3 |
70-8770 |
FRONT BRACKET ASM Price: $181.75 |
| 4 |
67-4720 |
LEVER ASSEMBLY Price: $19.98 |
| 5 |
67-4730 |
DISCONTINUED Price: Call Us |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 6 |
70-8780 |
DISCONTINUED Price: Call Us |
| 7 |
56-1560 |
SWITCH ASM This part replaces 67-4750. Price: $440.70 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 8 |
56-1570 |
BOLT Price: $6.29 |
| 9 |
56-1680 |
COVER SET Price: $20.80 |
| 10 |
56-1670 |
GEAR Price: $119.60 |
| 11 |
67-4790 |
DISCONTINUED Price: Call Us |
| 12 |
67-4780 |
GEAR SET Price: $434.34 |
| 13 |
56-1640 |
STOPPER SET Price: $18.99 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 14 |
67-4770 |
PINION SET Price: $192.09 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 15 |
67-4760 |
SHAFT ASSEMBLY Price: $835.38 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 16 |
56-1610 |
BOLT Price: $6.86 |
| 17 |
56-1720 |
REAR BRKT Price: $150.01 |
| 18 |
93-3573 |
HOLDER ASSY-BRUSH This part replaces 56-1700. Price: $83.00 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 19 |
56-1710 |
DISCONTINUED Price: Call Us |
| 20 |
112-1350 |
STARTER ASM This part replaces 67-4800. Price: $448.98 |
| 20 |
531167001 |
SERVICE KIT BAFFLE.VORTEX BAFF This part replaces 532159770. Price: $11.99 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 21 |
93-3564 |
BEARING REAR This part replaces 56-1600. Price: $33.38 |
| 22 |
56-1590 |
FRONT BRG Price: $44.07 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $29.99 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532173436 |
PULLEY MANDREL Price: $14.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 36 |
532196106 |
PULLEY.IDLER.2006 Price: $34.99 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 55 |
531169401 |
SERVICE KIT IDLER.ARM This part replaces 532197249. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 62 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 68 |
532144959 |
BELT V SECONDARY Price: $37.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 190 |
532197251 |
SPRING.MOWER.DRIVE.ELECTRIC Price: $9.99 |
| 196 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
