| Ref | Part Number | Description |
|---|
| 1 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 2 |
532197202 |
HANDLE.LOWER.21.GREY Price: $19.99 |
| 2 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 3 |
2412-133 |
CLAMP-R Price: $3.19 |
| 3 |
532405416 |
SPRING.RH.REAR.DOOR.21.RWGD Price: $4.99 |
| 4 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 4 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532194788. Price: $7.99 |
| 5 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 5 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532132004. Price: $1.99 |
| 6 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $7.99 |
| 6 |
86-7040 |
ROD-PROP, SEAT Price: $29.51 |
| 7 |
218-461 |
NUT-HH Price: $2.50 |
| 7 |
532191574 |
BOLT, HANDLE 5/16-18X1.75 Price: $5.99 |
| 8 |
237-7 |
O-RING Price: $8.82 |
| 8 |
532185588 |
KNOB.HANDLE.STAR.HUSQ.GRAY Price: $5.99 |
| 9 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 9 |
532197019 |
BAIL.DSTRT.FL.AW.CREAS.ORANGE Price: $14.99 |
| 10 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 10 |
532188821 |
BOLT Price: $4.99 |
| 11 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 11 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 12 |
43-8610 |
GUIDE Price: $23.35 |
| 12 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 13 |
237-30 |
O-RING Price: $2.50 |
| 13 |
532405415 |
SPRING.LH.REAR.DOOR.21.RWGD Price: $4.99 |
| 14 |
532750634 |
SCREW Price: $2.99 |
| 14 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 15 |
532850733 |
BRACKET.UPSTOP This part replaces 532125162. Price: $4.99 |
| 15 |
62-3010-01 |
BRACKET-RH This part replaces 62-3010. Price: $11.57 |
| 16 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 16 |
532401815 |
DOOR.REAR.21.RWGD This part replaces 532408888. Price: $14.99 |
| 17 |
532184193 |
BOLT Price: $4.99 |
| 17 |
62-3020-01 |
BRACKET-LH This part replaces 62-3020. Price: $12.72 |
| 18 |
532198170 |
PLUG.MULCHER.RGD.21. Price: $32.99 |
| 18 |
70-1890-03 |
GUARD-FLYWHEEL This part replaces 70-1890. Price: $29.13 |
| 19 |
3234-6 |
SCREW-HHF Price: $3.19 |
| 19 |
532407535 |
HOUSING.21.RWD.ORANGE.WALK. Price: $139.99 |
| 20 |
532193917 |
BRKT.ASM.HNDL.21.RWGD.LT.BLACK This part replaces 532194029. Price: $11.99 |
| 20 |
67-8190-01 |
BRACKET-SUPPORT, ENGINE This part replaces 67-8190. Price: $50.66 |
| 21 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 21 |
532194031 |
BRKT.ASM.HNDL Price: $32.99 |
| 22 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 22 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532150078. Price: $4.99 |
| 23 |
596031601 |
Screws This part replaces 532163183. Price: $2.99 |
| 24 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 25 |
532161333 |
CLIPPING DEFLECTOR Price: $9.99 |
| 26 |
532163409 |
SCREW Price: $3.99 |
| 27 |
532408442 |
SKIRT.REAR.21.RWGD.BLACK(2 2M) Price: $8.99 |
| 28 |
532088652 |
HINGE SCREW Price: $3.99 |
| 29 |
532191221 |
SNAP-ON.ZONE.CABLE.ASS Price: $19.99 |
| 30 |
532421176 |
ADAPTER.BLADE/PULLEY.25M This part replaces 532189179. Price: $24.99 |
| 31 |
532189028 |
BLADE.21.PUSH/RWGD/FWG Price: $19.99 |
| 32 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 33 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 34 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 35 |
585472601 |
KIT.SHIELD.DEBRIS.22FD/21RD This part replaces 532405843. Price: $25.99 |
| 36 |
532192325 |
SCREW.HEX.WSH Price: $4.99 |
| 37 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 39 |
532410668 |
GBAG.92510010.BLK.GEN.SERVICE This part replaces 532409726. Price: $54.99 |
| 40 |
532411951 |
FRAME.GBAG.21.RWGD.SC Price: $59.99 |
| 41 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532404763. Price: $3.99 |
| 42 |
532054583 |
SCREW Price: $4.99 |
| 45 |
532183058 |
DOOR.ASM.MULCH.21.RWD This part replaces 532190510. Price: $99.99 |
| 46 |
532169699 |
DEFLECTOR.21.MCUT.RWGD.GRAY This part replaces 532190512. Price: $8.99 |
| 47 |
532088349 |
NUT Price: $3.99 |
| 48 |
532188839 |
BRACKET.DEBRIS.SHIELD.BZP This part replaces 532190939. Price: $4.99 |
| 58 |
532182003 |
CLIP Price: $5.99 |
| 59 |
532182748 |
GRIP.HANDLE.FOAM.WIDE.(1 SIDE) Price: $7.99 |
| 96 |
532197991 |
CLIP.CABLE.BLK Price: $3.99 |
