| Ref | Part Number | Description |
|---|
| 1 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 1 |
532423469 |
WHEEL STEERING Price: $32.99 |
| 2 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 4 |
62-7400 |
DECAL Price: $24.54 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 5 |
62-5400 |
DISCONTINUED Price: Call Us |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
75-9310 |
DISCONTINUED Price: Call Us |
| 7 |
3256-21 |
WASHER-FLAT Price: $0.25 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
62-7320 |
TRACTION PEDAL STOP WA Price: $65.13 |
| 10 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 11 |
62-7350 |
DISCONTINUED Price: Call Us |
| 12 |
76-2200-03 |
FOOTREST-PEDAL, TRACTION This part replaces 76-2200. Price: $42.73 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
76-2260 |
PAD-FOOTREST Price: $8.40 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
76-2270 |
DISCONTINUED Price: Call Us |
| 15 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
32128-25 |
NUT-HF Price: $3.19 |
| 18 |
32144-22 |
SCREW Price: $0.75 |
| 19 |
28-0120 |
L.H. HINGE BRACKET Price: $48.24 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
321-5 |
SCREW-HH Price: $0.22 |
| 21 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 22 |
76-0130 |
CHAIN ASSY Price: $10.35 |
| 23 |
72-9540 |
HEAT SHIELD BRACKET Price: $13.76 |
| 24 |
72-4150-03 |
DISCONTINUED This part replaces 72-4150. Price: Call Us |
| 25 |
322-3 |
SCREW-HH Price: $0.79 |
| 26 |
321-2 |
SCREW-HH Price: $2.79 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 27 |
66-6120 |
FOOTREST PAD Price: $30.72 |
| 28 |
62-7280 |
DISCONTINUED Price: Call Us |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
72-4360-03 |
LH FOOTREST ASM This part replaces 72-4360. Price: $136.22 |
| 30 |
62-7190 |
SPACER-STEEL Price: $3.87 |
| 31 |
62-5000 |
GRASS DEFLECTOR Price: $17.98 |
| 32 |
58-6520 |
DECAL-GREASE Price: $2.57 |
| 33 |
61-2970 |
DISCONTINUED Price: Call Us |
| 34 |
32104-82 |
SCREW-HHF Price: $0.95 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 35 |
61-2980 |
RH FRT GRASS SHIELD *R Price: $96.44 |
| 36 |
32122-14 |
SCREW-PPH Price: $1.02 |
| 38 |
66-5340-03 |
FRONT GRILLE This part replaces 66-5340. Price: $116.48 |
| 39 |
61-3010 |
HOOD/GRILLE SUPT WA *B Price: $118.38 |
| 40 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 41 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 42 |
28-0130 |
RH HINGE BRKT Price: $48.24 |
| 43 |
3229-11 |
SCREW-CARR This part replaces 3229-22. Price: $0.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
