| Ref | Part Number | Description |
|---|
| 1 |
462839 |
Deck Latch Assembly (Includes Grip) Price: Call Us |
| 2 |
3-4371 |
CASE ASM This part replaces 4-4549. Price: $1,438.03 |
| 2 |
43874 |
Spacer, Deck Latch Price: Call Us |
| 3 |
3-0596 |
HOUSING-AXLE Price: $308.03 |
| 3 |
485704 |
Spring, Torsion - Lever Return Price: Call Us |
| 4 |
04021-05 |
Bolt, Hex Head 3/8-16 x 1" Ser. Flg. Price: Call Us |
| 4 |
237-33 |
O-RING Price: $11.26 |
| 5 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 5 |
483345 |
Lanyard, Deck Height Pin Assembly Price: Call Us |
| 6 |
04001-31 |
Capscrew, Hex Head 3/8-16 x 2-1/2" Price: Call Us |
| 6 |
322-4 |
SCREW-HH Price: $0.35 |
| 7 |
04006-02 |
Bolt, Hex Wshr Head 5/16-18 x 1-1/4" Price: Call Us |
| 7 |
251-138 |
BEARING-BALL Price: $65.70 |
| 8 |
251-137 |
BEARING-BALL Price: $74.53 |
| 8 |
425737-G |
Adjustment Bracket, Cutting Height (Scag Gold) Price: Call Us |
| 9 |
32120-62 |
RING-RETAINING Price: $4.29 |
| 10 |
253-82 |
SEAL-OIL Price: $28.34 |
| 10 |
43487 |
Pin, Deck Lift Price: Call Us |
| 11 |
04050-18 |
Retaining Ring, 1/2" Ext. "E" Price: Call Us |
| 11 |
105-5381 |
AXLE This part replaces 3-8392. Price: $249.43 |
| 12 |
3257-23 |
KEY-WOODRUFF Price: $6.79 |
| 12 |
482534 |
Linkage Assembly, Deck Lift Price: Call Us |
| 13 |
3-0492 |
ROLLER ASM Price: $521.02 |
| 13 |
43873 |
Spacer, Deck Lift Pedal Price: Call Us |
| 14 |
04021-07 |
HEX LOCKNUT, ELASTIC STOP, 1/2-13 Price: Call Us |
| 15 |
04001-87 |
Bolt, Hex Head 1/2-13 x 4" (lower) Price: Call Us |
| 15 |
32108-51 |
DISCONTINUED Price: Call Us |
| 16 |
04108-04 |
Capscrew, 5/8-11 x 1-1/2" Price: Call Us |
| 16 |
3296-19 |
NUT-HEX Price: $0.65 |
| 17 |
04030-07 |
Lockwasher, 5/8" Spring Price: Call Us |
| 17 |
3-8347 |
CAP-HUB Price: $67.73 |
| 18 |
04003-21 |
Carriage Bolt, 3/8-16 x 2-1/2" Price: Call Us |
| 18 |
3-0454 |
GEAR-RING Price: $291.29 |
| 19 |
3-0450 |
CASE-DIFFERENTIAL Price: $131.21 |
| 19 |
43572 |
Yoke, Front Caster Wheel Price: Call Us |
| 20 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 20 |
3-0452 |
SHAFT-GEAR, DIFFERENTIAL Price: $9.70 |
| 21 |
04021-07 |
HEX LOCKNUT, ELASTIC STOP, 1/2-13 Price: Call Us |
| 21 |
3-0453 |
SPACER-GEAR, DIFFERENTIAL Price: $11.54 |
| 22 |
04040-13 |
Flat Washer, 1/2 (.562 x 1.375 x .109) Price: Call Us |
| 22 |
105-5380 |
GEAR-DIFFERENTIAL This part replaces 3-3858. Price: $38.93 |
| 23 |
3296-27 |
NUT-LOCK, NI Price: $0.27 |
| 23 |
431018 |
Pivot, Deck Link Price: Call Us |
| 24 |
3273-23 |
SCREW-HH Price: $8.35 |
| 24 |
428513 |
Link, Decklift (black) Price: Call Us |
| 25 |
3-0455 |
SHAFT-IDLER Price: $54.87 |
| 25 |
452408 |
Adjustment Bracket, Lower Cut Height Price: Call Us |
| 26 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 26 |
237-22 |
O-RING Price: $2.43 |
| 27 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 27 |
3-0457 |
GEAR-INTERMEDIATE Price: $344.97 |
| 28 |
3-0456 |
GEAR-IDLER Price: $72.91 |
| 28 |
482628 |
Chain, Deck Lift Price: Call Us |
| 29 |
04001-153 |
Bolt, Hex Head 1/2-13 x 2-1/4" Price: Call Us |
| 30 |
483177 |
Spring, Decklift Price: Call Us |
| 31 |
424504 |
Foot Pedal, Height Adjustment Price: Call Us |
| 32 |
48114-04 |
GREASE FITTING, STR. 1/4-28 SELF TAP. Price: Call Us |
| 33 |
43212 |
Spacer, Deck Assist Price: Call Us |
| 485592 |
Grip, |
Deck Latch Price: Call Us 485592 |
