| Ref | Part Number | Description |
|---|
| 1 |
100-6571 |
HOOD ASM This part replaces 14-7149. Price: $1,342.17 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD This part replaces 532416480. Price: $69.99 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
65-5100 |
HANDLE-DOOR Price: $9.05 |
| 3 |
63-7030-03 |
SCREEN-HOOD REAR This part replaces 63-7030. Price: $141.98 |
| 4 |
321-3 |
SCREW-HH Price: $0.28 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 5 |
93-3187 |
DISCONTINUED Price: Call Us |
| 6 |
32128-33 |
NUT-HF Price: $0.25 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
93-3193 |
DISCONTINUED Price: Call Us |
| 8 |
66-8110 |
TRIM-HOOD Price: $4.91 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
3290-359 |
SCREW-HWH Price: $6.23 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
63-6900-01 |
LH HOOD HINGE PLATE ASM This part replaces 63-6900. Price: $23.15 |
| 11 |
76-4790 |
PAD-RUBBER Price: $17.89 |
| 12 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 13 |
3274-32 |
SCREW-HSBH Price: $4.79 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
66-3040-03 |
COVER-BOX, TOOL This part replaces 66-3040. Price: $26.24 |
| 15 |
66-3050 |
DISCONTINUED Price: Call Us |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
27-7310 |
DECAL-REFUELING Price: $27.52 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
92-8798 |
DECAL - WARNING Price: $36.29 |
| 18 |
71-3520 |
DISCONTINUED Price: Call Us |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
92-6501 |
DISCONTINUED Price: Call Us |
| 20 |
63-7310 |
DISCONTINUED Price: Call Us |
| 21 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 24 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 25 |
32128-20 |
NUT-HF Price: $0.99 |
| 26 |
46-6810 |
SCREW AND WASHER ASM Price: $3.49 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 27 |
93-7830 |
DECAL-TORQUE This part replaces 67-1720. Price: $23.91 |
| 28 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
66-3200 |
TREAD-FOOTREST, LH Price: $7.38 |
| 30 |
66-3210 |
TREAD-FOOTREST, LH Price: $30.94 |
| 31 |
92-5540 |
TREAD-FOOTREST, RH Price: $23.53 |
| 32 |
63-7320 |
DISCONTINUED Price: Call Us |
| 33 |
66-8760 |
DISCONTINUED Price: Call Us |
| 34 |
53-4430 |
DECAL-OIL Price: $8.99 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 35 |
92-6500 |
DISCONTINUED Price: Call Us |
| 36 |
92-5545-01 |
COVER-TOWER, FRONT This part replaces 92-5545. Price: $78.48 |
| 37 |
62-5550 |
DECAL Price: $9.32 |
| 38 |
92-5772 |
DISCONTINUED Price: Call Us |
| 39 |
63-7300 |
DISCONTINUED Price: Call Us |
| 40 |
63-8050 |
BOX-CONTROL Price: $106.29 |
| 41 |
106-8095 |
DECAL-TOWER This part replaces 66-2470. Price: $48.49 |
| 42 |
63-6890-01 |
RH HOOD HINGE PLATE ASM This part replaces 63-6890. Price: $12.36 |
| 43 |
46-8091 |
SCREW-HWH Price: $3.59 |
| 44 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 45 |
66-2870 |
CABLE-HOOD STOP Price: $27.51 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 46 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 47 |
59-9740 |
FLEX DRAW LATCH ASM Price: $36.89 |
| 48 |
3290-271 |
RIVET-POP Price: $0.25 |
| 49 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
82-8950 |
FOAM Price: $13.01 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 53 |
92-5548-01 |
SHIELD-STOP, PEDAL This part replaces 92-5548. Price: $31.35 |
| 54 |
321-4 |
SCREW-HH Price: $0.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
32148-9 |
NUT-CLINCH Price: $2.65 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
32148-7 |
NUT-CLINCH Price: $0.98 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
