| Ref | Part Number | Description |
|---|
| 1 |
27-4720 |
SHAFT-PIVOT, SEAT Price: $32.27 |
| 1 |
48135-58 |
Hose, Clear Poly 12" x 84" Price: Call Us |
| 2 |
36-7550 |
DISCONTINUED Price: Call Us |
| 2 |
486044-01 |
Strap, Ratchet- 66 x 1" Price: Call Us |
| 3 |
107-3039 |
PIN-LYNCH This part replaces 3290-243. Price: $6.96 |
| 3 |
452529 |
Elbow, Exhaust - TLB25 Price: Call Us |
| 4 |
04001-71 |
Bolt, Hex Head 1/2-13 x 1-1/2", (STT-52 & STTII-52) Price: Call Us |
| 4 |
37-9580 |
DISCONTINUED Price: Call Us |
| 5 |
04040-13 |
Flat Washer, 1/2 (.562 x 1.375 x .109) Price: Call Us |
| 5 |
27-9870 |
PIN-SWITCH, SEAT Price: $31.55 |
| 6 |
3220-2 |
NUT-JAM Price: $0.50 |
| 6 |
426327 |
Bracket, License Plate Price: Call Us |
| 7 |
04021-07 |
HEX LOCKNUT, ELASTIC STOP, 1/2-13 Price: Call Us |
| 7 |
3253-24 |
WASHER-LOCK/SP Price: $0.37 |
| 8 |
04021-08 |
HEX, NUT, ELASTIC STOP LOCK, 1/4-20 Price: Call Us |
| 8 |
2411-33 |
BALLJOINT-RH (W/GROMMET) This part replaces 37-9570. Price: $24.45 |
| 9 |
04001-203 |
Bolt, Hex Head 1/4-20 x 4" Price: Call Us |
| 9 |
3217-7 |
NUT-HEX Price: $0.28 |
| 10 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 10 |
462633 |
Stack Assembly w/Decals Price: Call Us |
| 11 |
323-12 |
SCREW-HH Price: $1.14 |
| 11 |
484947 |
Disk, Anti-Friction Price: Call Us |
| 12 |
32121-4 |
PIN-ROLL, SLOTTED Price: $3.49 |
| 12 |
452517 |
Boom Weldment Price: Call Us |
| 13 |
28-0570 |
SPRING-COMPRESSION Price: $33.04 |
| 13 |
484894 |
Chain w/2-Hooks Price: Call Us |
| 14 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 14 |
462612 |
Handle w/Grips Price: Call Us |
| 15 |
485075 |
Grip, Handle 1-1/4" x 6" Price: Call Us |
| 15 |
71-4490 |
SEAT SUPT BRKT WA *R This part replaces 27-9830. Price: $142.74 |
| 16 |
485076 |
Grip, Handle 1-1/4" x 20" Price: Call Us |
| 17 |
04003-23 |
Carriage Bolt, 3/8-16 x 1.0" Price: Call Us |
| 18 |
04017-26 |
Bolt, Hex Head Serrated Flange 3/8-16 x 3/4" Price: Call Us |
| 19 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 20 |
452536 |
Hose Holder Weldment Price: Call Us |
| 21 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 22 |
485050 |
Washer, Rubber Price: Call Us |
| 23 |
04001-11 |
Bolt, Hex Head 5/16-18 x 1-1/2" (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 24 |
485062 |
Quick Pin Assembly w/Lanyard Price: Call Us |
| 25 |
462641 |
Nozzle w/Decal Price: Call Us |
| 26 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 27 |
04001-49 |
Bolt, Hex Head 5/16-18 x 3.00" Price: Call Us |
| 28 |
452540 |
Band, Hose Support - 16" Price: Call Us |
| 29 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
