| Ref | Part Number | Description |
|---|
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $138.99 |
| 2 |
874760412 |
BOLT LT Price: $3.99 |
| 10 |
131-6557 |
ALTERNATOR ASM This part replaces 98-9474. Price: $443.05 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 20 |
98-9453 |
PULLEY-DYNAMO Price: $138.04 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $28.99 |
| 22 |
532004152 |
LIGHTBULB Price: $2.99 |
| 24 |
532421299 |
CABLE BATTERY 6 GA. 11" RED Price: $11.99 |
| 25 |
532165987 |
CABLE BATTERY Price: $19.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $3.99 |
| 27 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
| 28 |
532127725 |
CABLE GROUND Price: $4.18 |
| 29 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $12.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $9.99 |
| 30 |
98-7708 |
NUT Price: $7.76 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $6.99 |
| 34 |
532110712 |
SWITCH LT Price: $4.99 |
| 40 |
532197436 |
Price: Call Us |
| 40 |
98-7709 |
COLLAR Price: $8.79 |
| 41 |
539990071 |
HCS.1/4-20.X1/2 This part replaces 871110408. Price: $1.99 |
| 42 |
532154336 |
Cover, Terminal Red This part replaces 532131563. Price: $4.99 |
| 43 |
532192507 |
SOLENOID.W/BRASS.PLUNG Price: $16.99 |
| 48 |
532140844 |
ADAPTER Price: $3.99 |
| 50 |
107-0136 |
ROTOR ASM Price: $268.62 |
| 58 |
532169420 |
This part replaces 532169419. Price: $45.99 |
| 59 |
532180379 |
Switch FBI CRD Price: $10.99 |
| 60 |
98-7711 |
COVER-BEARING Price: $7.32 |
| 66 |
817490608 |
SCREW LT Price: $3.99 |
| 70 |
107-0138 |
BEARING-BALL Price: $48.37 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $11.99 |
| 80 |
98-7713 |
WASHER-THRUST Price: $4.49 |
| 81 |
532109748 |
RELAY.ASSY.T Price: $19.99 |
| 90 |
107-0139 |
DRIVE END FRAME ASM Price: $446.71 |
| 92 |
532196615 |
HARNESS.PIGTAIL.CONSLE Price: $11.99 |
| 93 |
532192540 |
SCREW.PLASTITE Price: $2.99 |
| 100 |
98-7715 |
PLATE-RETAINER Price: $9.38 |
| 110 |
98-7716 |
SCREW-HEAD, ROUND Price: $0.91 |
| 120 |
98-7717 |
BOLT-THROUGH Price: $9.75 |
| 130 |
133-2811 |
BEARING This part replaces 107-0137. Price: $46.67 |
| 140 |
107-9087 |
FRAME-END Price: $183.56 |
| 150 |
107-0140 |
COVER-END Price: $34.95 |
| 160 |
98-7721 |
RECTIFIER ASM This part replaces 98-9476. Price: $486.45 |
| 170 |
98-7722 |
BUSHING-INSULATION Price: $28.44 |
| 180 |
107-0141 |
BRUSH HOLDER ASM Price: $107.10 |
| 190 |
98-7724 |
BRUSH Price: $12.41 |
| 200 |
98-7725 |
SPRING-BRUSH Price: $4.32 |
| 210 |
98-7726 |
SCREW-HEAD, ROUND Price: $0.42 |
| 220 |
98-7727 |
SCREW-HEAD, ROUND Price: $0.94 |
| 230 |
98-7728 |
SCREW-HEAD, ROUND Price: $0.70 |
| 240 |
98-7729 |
BOLT Price: $2.35 |
| 250 |
98-7730 |
NUT Price: $1.31 |
| 260 |
98-7731 |
BOLT Price: $3.94 |
| 270 |
98-7732 |
NUT Price: $1.45 |
