| Ref | Part Number | Description |
|---|
| 1 |
98-2354-03 |
LATCH-SEAT Price: $41.34 |
| 1 |
98000129 |
NUT Price: Call Us |
| 2 |
161415X431 |
SHIELD.SIDE.OUTER.LH Price: Call Us |
| 2 |
98-2353 |
BRACKET-LATCH, SEAT Price: $17.71 |
| 3 |
32128-25 |
NUT-HF Price: $3.19 |
| 3 |
8393J |
STAKE PIN TI Price: Call Us |
| 4 |
12000036 |
KLIP RING TI Price: Call Us |
| 4 |
98-9342 |
DECAL-SOLENOID, INFORMATION Price: $69.36 |
| 5 |
72140506 |
BOLT Price: Call Us |
| 5 |
98-9302 |
PLATE-STOP, IDLER Price: $12.42 |
| 6 |
66-4190-03 |
SPRING-IDLER, CLUTCH Price: $7.20 |
| 6 |
8394J |
SPRING TI Price: Call Us |
| 7 |
105-4674 |
DECAL-NOISE Price: $4.80 |
| 7 |
8392J |
LATCH BRACKET TI Price: Call Us |
| 8 |
109230X |
SPRING CRT Price: Call Us |
| 8 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 9 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 10 |
25-8640 |
SCREW-HH Price: $1.09 |
| 11 |
3296-3 |
NUT-LOCK Price: $0.54 |
| 11 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 12 |
10040500 |
LOCKWASHER Price: Call Us |
| 12 |
98-9311 |
SWIVEL-THROTTLE Price: $28.41 |
| 13 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 13 |
72110510 |
BOLT Price: Call Us |
| 14 |
124343X |
BRKT SHIELD TINE Price: Call Us |
| 14 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 15 |
161414X431 |
SHIELD.SIDE.OUTER.RH Price: Call Us |
| 15 |
322-3 |
SCREW-HH Price: $0.79 |
| 16 |
73510400 |
NUT Price: Call Us |
| 16 |
75-3400 |
SHAFT-PIVOT, SEAT Price: $21.81 |
| 17 |
110-4149 |
KIT-SEAT PLATE This part replaces 98-2350-03. Price: $166.30 |
| 18 |
106-9224 |
DECAL-DANGER Price: $4.87 |
| 18 |
72040410 |
BOLT Price: Call Us |
| 19 |
102701X |
GRIP CRT Price: Call Us |
| 19 |
233-42 |
KNOB Price: $12.88 |
| 20 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 20 |
73220600 |
NUT.HEX.3/8-16UNC Price: Call Us |
| 21 |
102156X |
SUB= 102156X500 Price: Call Us |
| 21 |
98-9303 |
CABLE-THROTTLE Price: $21.41 |
| 22 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 22 |
74930632 |
BOLT Price: Call Us |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 23 |
4440J |
HINGE CRT Price: Call Us |
| 24 |
72140404 |
BOLT Price: Call Us |
| 24 |
98-2352-03 |
FRAME-SEAT Price: $456.00 |
| 25 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 25 |
6712 |
J VINYL CAP TI Price: Call Us 6712 J |
| 26 |
109227X |
PAD IDLER TI Price: Call Us |
| 26 |
93-0021 |
SWIVEL-CABLE, THROTTLE Price: $33.15 |
| 27 |
102695X505 |
LEVELING SHIELD Price: Call Us |
| 27 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 28 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 29 |
321-4 |
SCREW-HH Price: $0.99 |
| 30 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 31 |
75-3680-03 |
ROD-SEAT Price: $38.90 |
