| Ref | Part Number | Description |
|---|
| 3 |
09267300 |
PIN, PIVOT/TRUNNION This part replaces 09209100. Price: $6.45 |
| 4 |
06500826 |
NUT,LK-CTR .31-18 GA ZCC This part replaces 06529800. Price: $1.45 |
| 5 |
09248000 |
ROD - BRAKE 12 INCH Price: $15.95 |
| 6 |
08328500 |
SG-COMP .142 X .710 X 2.00 Price: $18.45 |
| 7 |
06401013 |
WSHR-FLT .406X.812X.065 ZCC This part replaces 06436200. Price: $0.95 |
| 8 |
06500917 |
NUT-STD .375-16 G2 ZCC This part replaces 06529400. Price: $0.95 |
| 9 |
09235200 |
SHAFT - BRAKE CROSS Price: $19.95 |
| 10 |
09236900 |
INTERLOCK - FIXED Price: $24.50 |
| 11 |
09237400 |
INTERLOCK - ADJUSTABLE Price: $4.75 |
| 12 |
06500910 |
NUT-JAM .375-16 G2 ZCC This part replaces 06535900. Price: $0.95 |
| 13 |
05901711 |
BLT-HEX .38-16X1.00 G5 ZCC This part replaces 05948700. Price: $1.45 |
| 14 |
06500825 |
NUT-LK-CTR .38-16 ZC120 This part replaces 06529600. Price: $0.95 |
| 15 |
05517400 |
BSHG-FLG .630X1.000X.625 NY This part replaces 045787. Price: $6.45 |
| 16 |
09304700 |
SPACER .630X.878X1.000 Price: $2.95 |
| 17 |
06608700 |
KEY-WDRF .19X.75 HRD #9 This part replaces 124549. Price: $0.95 |
| 18 |
09235300 |
ARM - BRAKE LH Price: $19.95 |
| 19 |
05709200 |
RG-RTNG-EXT .625X.050 Price: $2.45 |
| 20 |
06401118 |
WSHR, FLT .656X1.313X.095 ZCC This part replaces 06442800. Price: $2.45 |
| 22 |
09237200 |
SHAFT - BRAKE ACTUATING Price: $24.95 |
| 23 |
09237000 |
ACTUATOR Price: $35.60 |
| 24 |
05800900 |
PIN-ROLL .125X1.00 Price: $0.45 |
| 25 |
06608700 |
KEY-WDRF .19X.75 HRD #9 This part replaces 124549. Price: $0.95 |
| 26 |
05517400 |
BSHG-FLG .630X1.000X.625 NY This part replaces 045787. Price: $6.45 |
| 27 |
09304700 |
SPACER .630X.878X1.000 Price: $2.95 |
| 28 |
06408900 |
WSHR-FL-STL .627X.990X.032 Price: $1.65 |
| 29 |
05709200 |
RG-RTNG-EXT .625X.050 Price: $2.45 |
| 30 |
07505200 |
KNOB-STEERING LOCK This part replaces 039360. Price: $19.95 |
| 31 |
09237100 |
ROD - BRAKE ACTUATING Price: $9.55 |
| 33 |
08333200 |
SG-TENS .105X.85X5.00 WLD 40 Price: $13.95 |
