| Ref | Part Number | Description |
|---|
| 1 |
532199606 |
KIT.SVC.WELDMENT.42" This part replaces 532196495. Price: $228.99 |
| 1 |
95-7509 |
SHAFT-GEAR, DIFFERENTIAL Price: $139.55 |
| 2 |
95-7512 |
SHAFT-GEAR, DIFFERENTIAL Price: $106.50 |
| 3 |
95-7517 |
GEAR-BEVEL, 15 TOOTH Price: $126.37 |
| 4 |
119-8558 |
BEARING-NOSEAL This part replaces 99-7530. Price: $14.99 |
| 5 |
99-7552 |
SHIM 0.1 Price: $3.12 |
| 5 |
99-7553 |
SHIM 0.2 Price: $2.83 |
| 5 |
99-7554 |
SHIM 0.5 Price: $3.19 |
| 6 |
532195186 |
ARM.SUSPENSION.MOWER.R Price: $8.99 |
| 6 |
99-7531 |
CLIP Price: $1.42 |
| 7 |
110-4753 |
SHAFT-GEAR, BEVEL This part replaces 95-7529. Price: $139.91 |
| 7 |
532416358 |
SCREW.#10 X 0.750.BOS THREAD Price: $2.99 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $5.99 |
| 8 |
95-7519 |
GEAR-BEVEL, 17 TOOTH Price: $130.17 |
| 9 |
99-7532 |
BEARING-ROLLER, TAPER Price: $45.81 |
| 13 |
532192870 |
MANDREL ASM This part replaces 532192872. Price: $30.99 |
| 14 |
532187281 |
HOUSING MANDREL Price: $20.99 |
| 15 |
532110485 |
BEARING Price: $7.99 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $4.99 |
| 20 |
532159770 |
BAFFLE.VORTEX Price: $12.99 |
| 21 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873680500. Price: $2.69 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $3.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $2.99 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $5.99 |
| 26 |
532110452 |
NUT PUSH M Price: $1.99 |
| 27 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $27.99 |
| 29 |
532131491 |
ROD.HINGE Price: $1.99 |
| 30 |
532173984 |
SCREW, WASHER HEAD Price: $2.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $1.99 |
| 32 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $7.99 |
| 33 |
532400234 |
NUT.FLANGE.LOCK.TOP Price: $3.99 |
| 34 |
872110612 |
BOLT.3/8-16X1.50 Price: $3.99 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $14.99 |
| 37 |
819131316 |
WASHER Price: $2.99 |
| 38 |
532432520 |
KEEPER.BELT.MANDREL.PULLEY Price: $5.99 |
| 40 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.69 |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $2.99 |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $2.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.49 |
| 47 |
532197250 |
BRKT.CLUTCH.CABLE Price: $2.99 |
| 55 |
532197249 |
IDLER.ARM Price: $3.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $3.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 59 |
532141043 |
GUARD, BELT Price: $3.99 |
| 60 |
532197402 |
ARM BRAKE MOWER This part replaces 532197261. Price: $11.99 |
| 62 |
872110616 |
BOLT Price: $3.99 |
| 63 |
532199478 |
ARM.BRAKE.ZINC This part replaces 532199477. Price: $12.99 |
| 64 |
532199918 |
LINK BRAKE This part replaces 532199790. Price: $12.99 |
| 67 |
532409792 |
Price: Call Us |
| 68 |
532429636 |
BELT.DECK.DRIVE.42" Price: $30.99 |
| 69 |
872140505 |
BOLT Price: $2.69 |
| 70 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED Price: $52.99 |
| 113 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
| 116 |
532004898 |
BOLT This part replaces 532124842. Price: $1.99 |
| 117 |
532188606 |
WHEEL.GAGE.HALF.SPOKED Price: $7.99 |
| 118 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.69 |
| 119 |
734117201 |
WASHER This part replaces 819121414. Price: $1.99 |
| 122 |
532197258 |
KEEPER BELT ENGINE LH Price: $9.99 |
| 123 |
532197259 |
KEEPER BELT RH Price: $9.99 |
| 144 |
532199204 |
KEEPER.BELT.MOWER Price: $3.99 |
| 145 |
532177968 |
Pulley, Idler, Flat This part replaces 532193197. Price: $14.99 |
| 147 |
532401971 |
RETURN SPRING Price: $3.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. Price: $19.99 |
| 188 |
532195161 |
STUD.FASTNER.W/ANTI-ROTATE Price: $3.99 |
| 189 |
873900500 |
NUT LOCK HEX FLANGE 5/16-18 Price: $2.99 |
| 192 |
532197260 |
BRKT.BRAKE.STAND.LH. Price: $8.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 241 |
532152927 |
SCREW Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $5.99 |
