| Ref | Part Number | Description |
|---|
| 1 |
117-5199 |
HUB-PEDAL, TRACTION Price: $47.99 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 2 |
117-9507 |
PEDAL-ACCELERATOR Price: $12.86 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 4 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 5 |
106-3840 |
PEDAL-TRACTION Price: $88.41 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
92-7305 |
SPRING-EXTENSION Price: $9.99 |
| 7 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 11 |
127-2721 |
CABLE-TRACTION Price: $141.82 |
| 12 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 13 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 14 |
66-8010 |
SPACER Price: $4.19 |
| 15 |
2411-41 |
ROD END-BALL JOINT Price: $40.28 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 587016002. Price: $34.99 |
| 17 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 18 |
321-9 |
SCREW-HH Price: $0.27 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
93-2092 |
CLAMP-CABLE Price: $3.46 |
| 20 |
115-0282 |
PROXIMITY SENSOR ASM Price: $155.22 |
| 21 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 586840201. Price: $7.99 |
| 22 |
323-17 |
SCREW-HH Price: $2.05 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029802. Price: $14.99 |
| 23 |
62-4420 |
WASHER Price: $6.69 |
| 24 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 25 |
117-8066 |
MOW-STOP Price: $62.29 |
| 26 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 27 |
106-3731 |
ROD-PIVOT Price: $36.19 |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 28 |
110-8982 |
WASHER-SPRING Price: $2.71 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 30 |
115-0120-03 |
PEDAL-BRAKE Price: $158.58 |
| 31 |
125-8775 |
BUSHING-FLANGE Price: $1.09 |
| 32 |
104-7179 |
PIVOT-PEDAL Price: $43.97 |
| 33 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 34 |
99-7963-03 |
PEDAL-PARK Price: $26.63 |
| 35 |
115-5300 |
PROXIMITY SWITCH ASM Price: $137.95 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
115-0129 |
ROD-PAWL, BRAKE Price: $29.11 |
| 37 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 38 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 39 |
99-7214 |
PAWL-BRAKE Price: $28.35 |
| 40 |
99-7140 |
SPRING-TORSION Price: $21.98 |
| 41 |
52-2891 |
BUSHING-FLANGED, NYLON Price: $3.19 |
| 42 |
323-12 |
SCREW-HH Price: $1.14 |
| 43 |
117-0238 |
DETENT Price: $11.85 |
| 44 |
5-0652 |
SPACER Price: $5.35 |
| 45 |
283-14 |
PIN-CLEVIS Price: $2.92 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 46 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 47 |
117-0106 |
CABLE-BRAKE, RH Price: $117.67 |
| 48 |
117-0107 |
CABLE-BRAKE, LH Price: $113.33 |
| 49 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 50 |
115-8060 |
CLEVIS-DOUBLE Price: $15.64 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
115-8059 |
YOKE-CABLE Price: $11.28 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597070202 |
Links This part replaces 588794402. Price: $49.99 |
| 62 |
597070302 |
Links This part replaces 588794502. Price: $49.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 585338801. Price: $14.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683701. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
