| Ref | Part Number | Description |
|---|
| 1 |
532423829 |
DECAL.WARNING.CUST.RESP.E85. Price: $14.99 |
| 1 |
603-0719A-0637 |
HOOD HINGE ASSEMBLY Not Available This part replaces 603-0719-0637. Price: |
| 1 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 2 |
532424102 |
DECAL, WARNING SPARK ARRESTOR Price: $9.99 |
| 2 |
603-0784-0637 |
PANEL BRACKET ASSEMBLY (RH) (POWDER BLACK) Not Available Price: |
| 2 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 3 |
581627301 |
DECAL.BADGE.170MM.TEXTLOGO. Price: $11.99 |
| 3 |
603-0785-0637 |
PANEL BRACKET ASSEMBLY (LH) (POWDER BLACK) Not Available Price: |
| 3 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 4 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 4 |
532445758 |
DECAL.SIDE.PANEL.YTA19K42 Price: $9.99 |
| 4 |
603-0924-0637 |
BRACKET ASSEMBLY (POWDER BLACK) Not Available Price: |
| 5 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 5 |
603-0925-0637 |
BRACKET ASSEMBLY (LH) PANEL (POWDER BLACK) Not Available Price: |
| 6 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 6 |
581579501 |
DECAL.MOWER.WARN.KEEP.HAND.AWY Price: $3.99 |
| 6 |
625-0052 |
HEADLIGHT ASSEMBLY-F Not Available Price: |
| 7 |
532446125 |
DECAL.REPLACEMENT.YTA19K42 Price: $2.99 |
| 7 |
703-3394-0637 |
INTAKE SCREEN Not Available This part replaces 703-3394. Price: |
| 7 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 8 |
581578901 |
DECAL.FENDER.WARNING.ENGLISH Price: $3.99 |
| 8 |
703-3712 |
SHIELD-UPPER HEAT Not Available Price: |
| 8 |
76-2940 |
BUMPER Price: $9.73 |
| 9 |
703-3764 |
BRACKET-PANEL MTG Not Available Price: |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 10 |
66-8610 |
DISCONTINUED Price: Call Us |
| 10 |
703-3765 |
SHIELD-LOWER HEAT Not Available Price: |
| 11 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 11 |
710-0473 |
Screw, Truss Hd, 10-24 x .5 Price: $3.90 |
| 12 |
710-0599 |
Screw, Hex Wash Hd Tapp 1/4-20 x .5 Price: $3.86 |
| 12 |
76-1910 |
DISCONTINUED Price: Call Us |
| 13 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 13 |
82-9060 |
DISCONTINUED Price: Call Us |
| 14 |
531229001 |
DECAL.DECK.BELT.ROUTE.42"2021 This part replaces 581580001. Price: $1.99 |
| 14 |
710-3170 |
SCREW 5/16-18 x .56 Not Available Price: |
| 14 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 15 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 15 |
712-0272 |
Nut, Hex Sems, 10-24 Price: $3.58 |
| 16 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 16 |
712-0324 |
Nut, Hex Nylon Insert Lock, 1/4-20 Price: $3.38 |
| 17 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 17 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
| 18 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 18 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 19 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 19 |
726-3056 |
Latch, 1/4 Turn Panel Price: $6.20 |
| 20 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 20 |
532145005 |
DECAL BTRY SYMBOLS Price: $3.99 |
| 20 |
727-3194 |
Cylinder, Gas Spring Price: $106.14 |
| 21 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 22 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 22 |
731-3278 |
SIDE PANEL (RH) Not Available Price: |
| 23 |
731-3279 |
SIDE PANEL (LH) Not Available Price: |
| 23 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 24 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 24 |
726P05561 |
PANEL LATCH This part replaces 732-0936. Price: $30.60 |
| 25 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 25 |
732-0937 |
Spring, Compression Price: $7.18 |
| 26 |
736-0272 |
FLAT WASHER .510 x .995 This part replaces 7360272. Price: $4.37 |
| 26 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 27 |
738-0380 |
Screw, Shoulder, .5 x .27 Lg 3/8-16 Price: $7.34 |
| 27 |
93-3164 |
CAP Price: $11.64 |
| 28 |
93-3163 |
SPRING Price: $26.01 |
| 29 |
93-3165 |
BRACKET Price: $37.47 |
| 30 |
322-6 |
SCREW-HH Price: $0.45 |
| 31 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 532439966 |
PAD.FOOT.RH.HUSQ.ERGO.LT.GREY |
Price: $7.99 532439966 |
| 581724801 |
DECAL.BYPASS.FENDER.CRD/LT/YT |
Price: $3.99 581724801 |
