| Ref | Part Number | Description |
|---|
| 1 |
121-9184 |
TRANSMISSION ASM Price: $124.99 |
| 2 |
115-4669 |
BELT-V Price: $18.99 |
| 3 |
114-7977-03 |
BRACKET-TRANSMISSION Price: $12.99 |
| 4 |
108-7476 |
SCREW-PLASTITE Price: $0.79 |
| 5 |
138-3235 |
CAP-END This part replaces 42-3520. Price: $3.39 |
| 6 |
107-7491 |
ARM-SPRING Price: $11.99 |
| 7 |
110-0549 |
KNOB-HOC Price: $0.99 |
| 8 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 9 |
100-8774 |
PIVOT ARM ASM Price: $35.99 |
| 10 |
65-4730 |
WASHER-ARM, PIVOT Price: $1.69 |
| 11 |
65-4740 |
WASHER-THRUST, KEYED Price: $1.69 |
| 12 |
65-2720 |
RING-RETAINING,CLIP Price: $0.99 |
| 13 |
65-4710 |
RING-FRICTION Price: $2.99 |
| 14 |
65-4760 |
WASHER-CLUTCH Price: $1.59 |
| 15 |
139-6644 |
KEY-ROCKING, L.H. This part replaces 66-6050. Price: $6.89 |
| 16 |
139-6643 |
KEY-ROCKING, R.H. This part replaces 66-6040. Price: $6.89 |
| 17 |
65-4750 |
GEAR-PINION Price: $10.99 |
| 18 |
65-4720 |
SPRING-COMPRESSION Price: $0.89 |
| 19 |
92-1057 |
BOLT-SHOULDER Price: $3.19 |
| 21 |
74-1671 |
SPACER-COVER, WHEEL Price: $1.49 |
| 22 |
74-1660 |
COVER-WHEEL Price: $7.99 |
| 23 |
603773 |
LOCKNUT This part replaces 125-5069. Price: $2.09 |
| 24 |
100-6351 |
COVER-WHEEL Price: $18.99 |
| 25 |
100-1519 |
LABEL-WHEEL, SMART Price: $6.99 |
