| Ref | Part Number | Description |
|---|
| 1 |
32144-26 |
SCREW-FLOW, TAPTITE Price: $5.75 |
| 2 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 2 |
532199791 |
PULLEY MANDREL 5.0" Price: $22.99 |
| 3 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 3 |
75-2810 |
BRACKET-COLUMN, STEERING Price: $11.01 |
| 4 |
531350601 |
PULLEY IDLER, BACKSIDE 3 INCH This part replaces 539110311. Price: $19.99 |
| 4 |
75-0560 |
STEERING WHEEL ASM Price: $204.13 |
| 5 |
593787801 |
PULLEYS This part replaces 532173902. Price: $27.99 |
| 5 |
68-5370 |
DECAL Price: $6.21 |
| 6 |
32144-21 |
SCREW Price: $0.20 |
| 6 |
573970402 |
COVER, PULLEY, BLACK Price: $17.99 |
| 7 |
532400140 |
BELT KEEPER.MANDREL.38"COATED Price: $39.99 |
| 7 |
68-5140 |
CAP-WHEEL, STEERING Price: $15.13 |
| 8 |
3220-6 |
NUT-JAM Price: $1.25 |
| 8 |
529311701 |
KEEPER, BELT, BLACK Price: $4.99 |
| 9 |
233-17 |
KNOB Price: $10.58 |
| 9 |
525851801 |
GUIDE, BELT Price: $11.99 |
| 10 |
585053902 |
ARM.IDLER.30".RZ.X431 Price: $6.99 |
| 10 |
93-3139 |
PANEL - TOWER Price: $27.69 |
| 11 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 11 |
532400130 |
BRAKE.ARM.LH.38"TEX.COATED This part replaces 529311801. Price: $14.99 |
| 12 |
532419274 |
BLADE.MOWER.BAGGING.30" Price: $29.99 |
| 12 |
95-1821 |
SPRING-COMPRESSION Price: $6.71 |
| 13 |
539114789 |
SWIVEL Price: $11.99 |
| 13 |
75-1490 |
ROD-BRAKE, PARKING Price: $50.23 |
| 14 |
237-22 |
O-RING Price: $2.43 |
| 14 |
532110485 |
BEARING Price: $11.99 |
| 15 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 15 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 16 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 16 |
581506902 |
Links This part replaces 532195740. Price: $9.99 |
| 17 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 17 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 18 |
525848801 |
SPACER .39 ID X 2.25 Price: $6.99 |
| 18 |
75-6230 |
HOSE Price: $133.10 |
| 19 |
532193216 |
SPRING.BRAKE.RETURN.38" Price: $4.99 |
| 19 |
75-6240 |
HOSE Price: $137.49 |
| 20 |
539107609 |
TORSION SPRING Price: $4.99 |
| 20 |
63-7900-03 |
RACK This part replaces 63-7900. Price: $144.55 |
| 21 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 21 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192870. Price: $49.99 |
| 22 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 22 |
532417344 |
SHIELD.DEFLECT.MWR.30S.BLACK Price: $37.99 |
| 23 |
595935501 |
Pins This part replaces 539110736. Price: $2.99 |
| 23 |
75-5940 |
HOSE Price: $94.45 |
| 24 |
585054001 |
BELT DECK 99.60 EFL Price: $59.99 |
| 24 |
75-6230 |
HOSE This part replaces 75-6220. Price: $133.10 |
| 25 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 25 |
75-6250 |
HOSE Price: $175.77 |
| 26 |
532416405 |
COUPLING.QUICK CONNECT Price: $8.99 |
| 26 |
75-0600 |
UNIT-STEERING, POWER Price: $1,809.64 |
| 27 |
21-9260 |
COVER-DUST Price: $8.19 |
| 27 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 28 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 28 |
596580601 |
Pins This part replaces 539976988. Price: $3.99 |
| 29 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 29 |
596273101 |
Pins This part replaces 539976989. Price: $2.99 |
| 30 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 539107630. Price: $3.99 |
| 31 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 31 |
532137729 |
SCREW.1/4-20X5/8 This part replaces 539107631. Price: $3.99 |
| 32 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 32 |
539990701 |
BLT 3/8-16X1-3/4 WHIZLK ZN SP Price: $2.99 |
| 33 |
218-535 |
NUT-HEX Price: $0.34 |
| 33 |
596241101 |
Bolts This part replaces 539113621. Price: $2.99 |
| 34 |
218-536 |
WASHER-LOCK Price: $1.09 |
| 34 |
539110025 |
BOLT 3/8-16 X 1 1/2 ZINC CLEAR Price: $3.99 |
| 35 |
539108461 |
BOLT 1/4-20 X 1/2 HWST Price: $2.99 |
| 35 |
93-7480 |
LED-MINIATURE Price: $78.50 |
| 36 |
218-533 |
LENS Price: $17.62 |
| 36 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 37 |
539990588 |
HCS 3/8C X 2 Price: $3.99 |
| 38 |
525848601 |
RHSNB 3/8-16 X 4 GR5 ZD Price: $4.99 |
| 39 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 40 |
596433501 |
NUT NUT.3/8-16.HEX.JAM.Z 3/8-1 This part replaces 539109332. Price: $2.99 |
| 41 |
573975201 |
NUT, 7/16-20 HEX NYLOC ZC Price: $2.99 |
| 42 |
596134801 |
Nuts This part replaces 539107590. Price: $1.00 |
| 43 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 44 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 45 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 46 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 539107520. Price: $3.99 |
| 47 |
539109562 |
WASHER 3/8 X 3/4 X .187 TK Price: $3.99 |
| 48 |
595086801 |
Washers This part replaces 539990250. Price: $2.99 |
| 49 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 50 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
