| Ref | Part Number | Description |
|---|
| 1 |
121-6425 |
DECK ASM Price: $5,494.04 |
| 1 |
532059192 |
VALVE CAP Price: $3.99 |
| 2 |
532065139 |
VALVE STEM LT Price: $5.99 |
| 2 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 3 |
110-9683 |
SHAFT-REAR ROLLER Price: $35.70 |
| 3 |
532148736 |
RIM.ASM.8X5.FRONT.SERVICE.SLVR This part replaces 532106228. Price: $119.99 |
| 4 |
36-1740 |
ROLLER-DECK Price: $37.03 |
| 5 |
532122075 |
TIRE.FRT.(16X6).TURF.SAVER This part replaces 532106230. Price: $54.99 |
| 6 |
532000278 |
FITTING LT This part replaces 532124957. Price: $2.99 |
| 7 |
322-29 |
SCREW-HH Price: $2.69 |
| 7 |
532009040 |
BEARING T This part replaces 532124959. Price: $3.99 |
| 8 |
532104757 |
CAP.HUB.FRONT.LT.BLACK This part replaces 532175039. Price: $1.99 |
| 8 |
93-4803 |
ROLLER-DECK Price: $41.58 |
| 9 |
105-4549 |
SPACER-ROLLER Price: $10.26 |
| 9 |
532122077 |
TIRE.REAR.TS.(23X10.5X12) This part replaces 532105588. Price: $279.99 |
| 10 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 11 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 11 |
532106277 |
RIM.ASM.12"REAR.SILVER Price: $139.99 |
| 12 |
68-6840 |
SHAFT-ROLLER Price: $64.07 |
| 13 |
68-6710 |
ROLLER Price: $59.98 |
| 14 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 15 |
3231-33 |
SCREW-CARR Price: $4.29 |
| 16 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 17 |
108-1914 |
PAD-BUMPER Price: $11.14 |
| 18 |
3269-24 |
RIVET Price: $1.79 |
| 19 |
3233-34 |
SCREW-CARR Price: $7.98 |
| 20 |
108-1908 |
SPACER-IDLER Price: $23.93 |
| 21 |
108-4393 |
BELT-HEX Price: $166.54 |
| 22 |
107-4725 |
PULLEY Price: $274.56 |
| 23 |
140-5847 |
PULLEY-IDLER This part replaces 01-268-0160. Price: $98.46 |
| 24 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 25 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 26 |
108-1926 |
WASHER Price: $5.30 |
| 27 |
108-1921 |
SPRING-TORSION Price: $28.33 |
| 28 |
140-7078 |
IDLER ARM ASM This part replaces 108-1930. Price: $49.85 |
| 29 |
32120-84 |
RING-SNAP, EXTERNAL Price: $0.61 |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 31 |
9136144 |
SCREW-HWHTF Price: $6.29 |
| 32 |
108-1924 |
SPACER-IDLER Price: $11.13 |
| 33 |
108-1993 |
SCREW-HSBH Price: $3.66 |
| 34 |
106-7354-01 |
MOUNT-WHEEL, LH Price: $102.99 |
| 35 |
323-23 |
SCREW-HH Price: $2.07 |
| 36 |
98-7912 |
TUBE-SPANNER Price: $12.23 |
| 37 |
1-603299 |
ROLLER-SCALP, ANTI Price: $21.99 |
| 38 |
98-7913 |
TUBE-SPACER Price: $6.81 |
| 39 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 40 |
3231-27 |
SCREW-CARR Price: $0.54 |
| 41 |
3296-45 |
NUT-HEX Price: $3.79 |
| 46 |
138-1930 |
LOW DRIVEN SPINDLE ASM This part replaces 119-4778. Price: $605.97 |
| 47 |
110-0621-03 |
BLADE-MEDIUM FLOW Price: $38.49 |
| 48 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 49 |
92-5816 |
BOLT-BLADE Price: $4.93 |
