| Ref | Part Number | Description |
|---|
| 1 |
532170551 |
CONTROL.THROTTLE/CHOKE.BLACK This part replaces 532140310. Price: $24.99 |
| 1 |
94-5028 |
SEE PB #941 Price: Call Us |
| 2 |
596582501 |
Bolts This part replaces 817720410. Price: $2.99 |
| 2 |
93-6881 |
RIM ASM Price: $152.01 |
| 3 |
340-6 |
FITTING-STRAIGHT Price: $18.79 |
| 4 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 4 |
532137352 |
MUFFLER.LT.BRIGGS.14HP.IC/OHV Price: $39.99 |
| 5 |
10-6870-03 |
HUB-WHEEL This part replaces 10-6870. Price: $150.01 |
| 6 |
111512 |
DISCONTINUED This part replaces 10-6830. Price: Call Us |
| 7 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 8 |
75-9990 |
HYD MOTOR ASM Price: $831.33 |
| 9 |
93-6782-01 |
FORK-WHEEL, REAR This part replaces 93-6782. Price: $916.89 |
| 10 |
3274-93 |
SCREW-HSH Price: $3.39 |
| 11 |
3220-3 |
NUT-HJ Price: $0.28 |
| 12 |
3220-12 |
NUT-HEX JAM LH Price: $1.83 |
| 13 |
21-0141 |
RH BALL JOINT ASM Price: $109.12 |
| 13 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED Price: $8.99 |
| 14 |
322-9 |
SCREW-HH Price: $3.09 |
| 14 |
813280324 |
Nipple Pipe 3/8 Npt X 3" Price: $3.12 |
| 15 |
3255-2 |
WASHER-LOCK, EXT Price: $0.95 |
| 15 |
532428287 |
VALUE.OIL.DRAIN This part replaces 813200300. Price: $14.99 |
| 16 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 16 |
75-7730 |
WASHER-THRUST Price: $2.88 |
| 17 |
325-6 |
SCREW-HH Price: $1.42 |
| 18 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 19 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 20 |
69-9760 |
COVERPLATE Price: $5.38 |
| 21 |
56-7976 |
CLAMP-TUBE Price: $2.44 |
| 22 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 23 |
3257-42 |
KEY-WOODRUFF Price: $5.99 |
| 23 |
532156123 |
SHIELD HEAT Price: $6.23 |
| 24 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 25 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 26 |
93-6843 |
HYD HOSE ASM Price: $194.30 |
| 27 |
61-2070-03 |
TUBE-STEERING This part replaces 61-2070. Price: $89.00 |
| 28 |
237-30 |
O-RING Price: $2.50 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
532157103 |
TANK.FUEL(3.5.GAL) This part replaces 532153630. Price: $69.99 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
532106082 |
PAD-SPACER LT Price: $3.99 |
| 35 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 37 |
587044808 |
HOSE.1/4".LOW.PERM.FUEL.LN.8" This part replaces 532124923. Price: $5.99 |
| 39 |
532109227 |
PAD IDLER TI Price: $3.99 |
| 40 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 49 |
817000616 |
SCREW 3/8-16X1 This part replaces 817490616. Price: $5.99 |
| 62 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 72 |
596134201 |
Screws This part replaces 871070512. Price: $2.99 |
| 78 |
874760620 |
BOLT This part replaces 817490620. Price: $4.99 |
