| Ref | Part Number | Description |
|---|
| 1 |
108319 |
GASKET Price: $5.88 |
| 2 |
32120-64 |
RING-SNAP, EXTERNAL Price: $0.25 |
| 3 |
54-0320 |
GEAR-SPUR Price: Call Us |
| 4 |
237-80 |
O-RING Price: $6.10 |
| 5 |
94-7691 |
Adapter (Incl. Ref. #4) Price: Call Us |
| 6 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 7 |
98-5341 |
HOSE - RESV TO HYDRO UNIT Price: $19.43 |
| 8 |
237-42 |
O-RING Price: $2.78 |
| 9 |
237-22 |
O-RING Price: $2.43 |
| 10 |
63-7550 |
HOSE ASM- HYD. Price: $88.89 |
| 11 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 12 |
323-16 |
SCREW-HH Price: $2.89 |
| 13 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 14 |
54-0240 |
FAN 8" Price: Call Us |
| 15 |
3255-5 |
WASHER-LOCK, EXT Price: $0.25 |
| 16 |
32144-19 |
SCREW-SHWH Price: $0.89 |
| 17 |
321-2 |
SCREW-HH Price: $2.79 |
| 18 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 19 |
3256-55 |
WASHER-FLAT Price: $3.69 |
| 20 |
54-0930 |
TRANS PULLEY Price: Call Us |
| 21 |
3241-7 |
SCREW-SQH This part replaces 3241-2. Price: $3.39 |
| 22 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 23 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 24 |
3257-24 |
KEY-WOODRUFF Price: $2.49 |
| 25 |
98-5342 |
HOSE - RESV TO PUMP Price: Call Us |
| 26 |
3250-46 |
SCREW-PPH Price: $18.99 |
| 27 |
98-5529 |
PLATE-TRACTION WELDED Price: $138.13 |
| 28 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 29 |
75-4130 |
PLATE-SWITCH Price: $13.26 |
| 30 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 31 |
3296-9 |
NUT-HEX Price: $0.25 |
| 32 |
323-14 |
SCREW-HH Price: $1.34 |
| 33 |
3217-6 |
NUT-HEX Price: $1.19 |
| 34 |
322-7 |
SCREW-HH Price: $0.89 |
| 35 |
251-259 |
BEARING-BALL This part replaces 251-307. Price: $13.67 |
| 36 |
92-6290 |
SPACER Price: $2.84 |
| 37 |
92-6289 |
Swing Arm Assembly (Incl. Ref.# 24) Price: Call Us |
| 38 |
75-5470 |
SPACER-BEARING Price: $3.06 |
| 39 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 40 |
76-8640 |
STUD-TRACTION Price: $23.60 |
| 41 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 42 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 43 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 44 |
322-6 |
SCREW-HH Price: $0.45 |
| 45 |
92-6270-03 |
TRACTION PLATE WA This part replaces 92-6270. Price: $129.46 |
| 46 |
3256-68 |
WASHER-FLAT Price: $2.69 |
| 47 |
76-9430-03 |
SPRING-EXTENTION This part replaces 76-9430. Price: $28.14 |
| 48 |
76-6880 |
HOSE ASSY Price: $54.50 |
