| Ref | Part Number | Description |
|---|
| 1 |
461852 |
Cutter Deck w/Decals Price: Call Us |
| 2 |
461663 |
Cutter Spindle Assembly Price: Call Us |
| 3 |
43296 |
SLEEVE, CUTTER SPINDLE Price: Call Us |
| 4 |
482744 |
Pulley, 5.75 O.D. (Gasoline Engines) Price: Call Us |
| 5 |
481022 |
Tapered Bearing Set (Two Bearings W/Race) Price: Call Us |
| 6 |
43644 |
Housing, Spindle Price: Call Us |
| 7 |
48114-04 |
GREASE FITTING, STR. 1/4-28 SELF TAP. Price: Call Us |
| 8 |
43589 |
Spindle Shaft, Tapered Brng Price: Call Us |
| 9 |
43682 |
Idler Pivot Price: Call Us |
| 10 |
04063-08 |
Key, 1/4 x 1/4 x 2.0" Price: Call Us |
| 11 |
43592 |
Spacer, Cutter Blade - Small Price: Call Us |
| 12 |
04001-175 |
Bolt, Hex Head 5/16-18 x 1-1/2" Grade 8 Price: Call Us |
| 13 |
04001-154 |
Bolt, 5/16-18 x 4-3/4" Hex Head Price: Call Us |
| 14 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 15 |
481706 |
Cutter Blade 16-1/2" (marbane) Price: Call Us |
| 15A |
481710 |
Cutter Blade 16-1/2" Hi Lift (marbane) Price: Call Us |
| 16 |
04043-06 |
Flatwasher, 5/8-.688 x 1-3/4 x .134 HD Price: Call Us |
| 17 |
04001-41 |
BOLT, HEX HEAD, 5/8-11 X 9-1/2 GR.5 Price: Call Us |
| 18 |
461023 |
Caster Assembly Price: Call Us |
| 19 |
484368 |
Cap, Spindle 61" Only Price: Call Us |
| 20 |
04017-16 |
Capscrew, 5/16-18 x .75 Serrated Flange Hex Head Price: Call Us |
| 21 |
461844 |
Discharge Chute Assembly - 48V Price: Call Us |
| 22 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 23 |
04001-11 |
Bolt, Hex Head 5/16-18 x 1-1/2" (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 25 |
04043-04 |
Flatwasher, 3/8 (.391 x .938 x .105 HD) Grade 8 Price: Call Us |
| 26 |
04029-03 |
WINGNUT, PLASTIC 3/8-16 X .875 Price: Call Us |
| 27 |
04110-03 |
U-Nut, 3/8-16 (short) Price: Call Us |
| 29 |
04001-172 |
Bolt, Hex Head 1/4-20 x 1" Grade 8 Black Price: Call Us |
| 30 |
04020-09 |
Hex Locknut, Elastic Stop, 3/8-16 Price: Call Us |
| 32 |
48087 |
Belt, RH Blade Drive 48" Price: Call Us |
| 33 |
48089 |
BELT, BLADE DRIVE Price: Call Us |
| 34 |
04021-05 |
Bolt, Hex Head 3/8-16 x 1" Ser. Flg. Price: Call Us |
| 35 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 36 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 37 |
04004-02 |
Bolt, 5/16-18 x 1" Hex Head Price: Call Us |
| 39 |
04017-37 |
Serr. Fl. Hex Head Capscrew, 1/2-13 x 1-3/4 Price: Call Us |
| 40 |
04117-04 |
Nut, Elastic Stop 1/2-13, (STT-52 & STTII-52) Price: Call Us |
| 41 |
04021-04 |
Nut, Center Lock, 5/16-18(32) Price: Call Us |
| 42 |
44078 |
J-Hook, Idler Pulley Price: Call Us |
| 43 |
48181 |
IDLER PULLEY, "V" GROOVE Price: Call Us |
| 44 |
04040-04 |
Flatwasher, 5/16-.344 x .688 x .065 (48V / 52V) Price: Call Us |
| 46 |
483176 |
Pad, Deck Wear Price: Call Us |
| 47 |
43028 |
J-HOOK, IDLER PULLEY Price: Call Us |
| 48 |
43077 |
SPACER, J PULL ROD Price: Call Us |
| 49 |
04041-12 |
Flatwasher, 3/8 (.375 x 1-1/2" x 16 ga.) Price: Call Us |
| 50 |
04001-31 |
Capscrew, Hex Head 3/8-16 x 2-1/2" Price: Call Us |
| 51 |
481024 |
SEAL, 2.00 O.D. X 1.50 BORE Price: Call Us |
| 53 |
43277 |
SPACER, J-PULL ROD Price: Call Us |
| 54 |
48677 |
RELIEF FITTING, TAPERED BEARING SPINDLE Price: Call Us |
| 55 |
43312 |
Spacer, Outside, Cutter Spindle Price: Call Us |
| 56 |
43297 |
SPINDLE BUSHING, BOTTOM Price: Call Us |
| 57 |
481035 |
Nut , Spec ial 1 -1/ 1 6 - 1 8 Price: Call Us |
| 58 |
481625-01 |
Knob, w/stud 3/8-16 x 1-1/4" Price: Call Us |
| 59 |
04001-51 |
Capscrew, Hex Head 3/8-16 x 3-3/4" Price: Call Us |
| 60 |
43681 |
Pivot, Idler - Short Price: Call Us |
| 61 |
483215 |
Idler Pulley, Belt Clutch Price: Call Us |
| 62 |
48224 |
BEARINGS, BALL, NEUTRAL RETURN Price: Call Us |
| 63 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 64 |
482295 |
Wheel, Anti-Scalp Price: Call Us |
| 65 |
45944 |
Shaft Weldment, Guide Roller Price: Call Us |
| 66 |
481025 |
Seal, 2.00" O.D. x 1.625" Bore Price: Call Us |
| 67 |
483378 |
Spring, Discharge Chute Price: Call Us |
| 68 |
424839 |
Baffle Custom-Cut, 48V (7-Position) Price: Call Us |
| 69 |
04001-62 |
Capscrew, Hex Head 3/8-16 x 3.25" Price: Call Us |
| 70 |
04003-23 |
Carriage Bolt, 3/8-16 x 1.0" Price: Call Us |
| 71 |
424661 |
Heatshield, 16" Small Frame Price: Call Us |
| 72 |
04021-22 |
Lock Nut, 5/16-18 Elastic Stop Grade 8 Price: Call Us |
| 73 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 74 |
424367 |
Quick Pin, 5/16" Dia. Price: Call Us |
