| Ref | Part Number | Description |
|---|
| 1 |
94-3145 |
SCREW-PULLEY Price: $9.84 |
| 2 |
603000366 |
LIGHT, OIL Price: $17.99 |
| 2 |
74-8080 |
WASHER Price: $4.77 |
| 2 |
DD-E6301-16177 |
CAMSHAFT-INJ PUMP Not Available Price: |
| 3 |
603003554 |
PLUG, HOLE Price: $6.99 |
| 3 |
94-3144 |
PULLEY-CRANKSHAFT Price: $766.47 |
| 3 |
DD-08153-06205 |
BALL BEARING GOV Not Available Price: |
| 4 |
603000760 |
SPACER, KEYSWITCH Price: $3.99 |
| 4 |
74-8100 |
GEAR-PINION Price: $58.79 |
| 4 |
DD-E6300-A0011 |
GEAR ASSEMBLY-INJECTION Not Available Price: |
| 5 |
603000761 |
NUT, KEYSWITCH Price: $5.99 |
| 5 |
98-3833 |
GEAR - OIL PUMP This part replaces 74-8110. Price: $26.24 |
| 5 |
DD-05712-00525 |
FUEL CAMSHAFT KEY Not Available Price: |
| 6 |
603000801 |
ACCESSORY RECEPTACLE Price: $24.99 |
| 6 |
74-8120 |
KEY-WOODRUFF Price: $3.36 |
| 6 |
DD-04612-00240 |
SNAP RING Not Available Price: |
| 7 |
94-3150 |
SCREW-HH Price: $1.50 |
| 7 |
DD-E6300-55452 |
SLEEVE-GOVERNOR Not Available Price: |
| 8 |
531308250 |
SWITCH, ROCKER, LIGHT Price: $24.99 |
| 8 |
74-7560 |
LOCKWASHER This part replaces 94-3151. Price: $0.67 |
| 8 |
DD-15221-55471 |
RETAINER CLIP Not Available Price: |
| 9 |
603003555 |
COVER, HOLE, SWITCH, ROCKER Price: $5.99 |
| 9 |
74-8140 |
COVER Price: $137.43 |
| 9 |
DD-15221-55692 |
GVNR BALL CASE Not Available Price: |
| 10 |
603003556 |
KEYSWITCH, 12V, DIESEL Price: $64.99 |
| 10 |
74-8150 |
GASKET-COVER Price: $4.08 |
| 10 |
DD-07715-03205 |
Ball Price: Call Us |
| 11 |
94-3148 |
SEAL Price: $33.41 |
| 11 |
DD-15221-55741 |
RETAINER CLIP Not Available Price: |
| 12 |
603004168 |
GAUGE FUEL-HOUR SEP GND Price: $179.99 |
| 12 |
74-8170 |
BEARING SET (STD) Price: $208.01 |
| 12 |
74-8180 |
BEARING SET (.30MM OS) SET OF 10 Price: $209.92 |
| 12 |
DD-07715-00403 |
BALL-GVNR SLV Not Available Price: |
| 13 |
603004169 |
CLIP METER ROUND Price: $4.99 |
| 13 |
74-8200 |
THRUST BEARING SET Price: $92.03 |
| 13 |
74-8210 |
THRUST BEARING SET Price: $108.36 |
| 13 |
74-8220 |
THRUST BEARING SET Price: $27.91 |
| 13 |
94-3141 |
DISCONTINUED Price: Call Us |
| 13 |
DD-08240-00001 |
BALL BEARING FUEL Not Available Price: |
| 14 |
74-8230 |
SHAFT-CRANK Price: $3,552.00 |
| 14 |
DD-15221-16321 |
FUEL CAMS RETAINER Not Available Price: |
| 15 |
74-8240 |
DISCONTINUED Price: Call Us |
| 15 |
DD-01123-50814 |
BOLT Not Available Price: |
| 16 |
74-8250 |
PIN This part replaces 74-7990. Price: $0.97 |
| 16 |
DD-E6301-51012 |
PUMP-FUEL INJECTIO Not Available Price: |
| 17 |
94-3149 |
GEAR-FLYWHEEL Price: $113.49 |
| 17 |
DD-15471-52111 |
INJECTION SHIM Not Available Price: |
| 18 |
74-8270 |
DISCONTINUED Price: Call Us |
| 18 |
DD-15401-52112 |
INJECTION PUMP SHIM Not Available Price: |
| 19 |
74-8280 |
SCREW-HH Price: $4.63 |
| 19 |
DD-01123-50822 |
BOLT Not Available Price: |
| 20 |
74-8290 |
DISCONTINUED Price: Call Us |
| 20 |
DD-01513-50822 |
STUD Not Available Price: |
| 21 |
74-8300 |
CLIP-PIN, PISTON Price: $2.96 |
| 21 |
DD-02156-50080 |
HEX NUT Not Available Price: |
| 22 |
74-8310 |
PIN-PISTON Price: $24.33 |
| 22 |
DD-04512-50080 |
LOCK WASHER Not Available Price: |
| 23 |
74-8320 |
DISCONTINUED Price: Call Us |
| 23 |
74-8330 |
PISTON RING SET Price: $277.15 |
| 23 |
74-8340 |
PISTON RING SET Price: $173.77 |
| 23 |
94-3158 |
PISTON RING SET Price: $233.60 |
| 23 |
DD-84612-60500 |
PETCOCK-FUEL BLEED Not Available Price: |
| 24 |
98-9965 |
DISCONTINUED This part replaces 94-3154. Price: Call Us |
| 24 |
DD-E5500-42412 |
FUEL FITTING LINE Not Available Price: |
| 25 |
74-8360 |
CONNECTING ROD This part replaces 94-3153. Price: $1,118.95 |
| 25 |
DD-E5775-52031 |
PUMP ASSEMBLY-FUEL Not Available This part replaces DD-15381-52030. Price: |
| 26 |
DD-E6200-52142 |
GASKET-FUEL PUMP Not Available This part replaces DD-15241-52141. Price: |
| 27 |
74-8380 |
DISCONTINUED Price: Call Us |
| 27 |
74-8390 |
BRG - CONNECTING ROD This part replaces 94-3155. Price: $427.80 |
| 27 |
DD-01513-50616 |
STUD Not Available Price: |
| 28 |
74-8400 |
BOLT-ROD, CONNECTING Price: $23.09 |
| 28 |
DD-02056-50060 |
HEX NUT Not Available Price: |
| 29 |
74-8420 |
PISTON SET Price: $3,551.52 |
| 29 |
74-8430 |
PISTON SET Price: $3,570.53 |
| 29 |
74-8440 |
PISTON SET Price: $2,151.01 |
| 29 |
94-3157 |
PISTON SET Price: $3,570.53 |
| 29 |
DD-04512-50060 |
LOCK WASHER Not Available Price: |
| 30 |
DD-15471-42111 |
FUEL PUMP PIPE Not Available Price: |
| 33 |
94-3152 |
SCREW-HH Price: $2.62 |
