| Ref | Part Number | Description |
|---|
| 1 |
532071673 |
Cap, Plunger Price: $3.99 |
| 1 |
63-8090-03 |
LOWER HOUSING ASM Price: $1,548.75 |
| 2 |
3219-2 |
NUT-HEX Price: $0.37 |
| 2 |
532123436 |
Rod, Parking Brake Price: $4.99 |
| 3 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 3 |
532123437 |
Bracket, Parking Brake Price: $4.46 |
| 4 |
21-8270 |
PIN-DOWEL Price: $6.65 |
| 4 |
532008883 |
Cover, Pedal This part replaces 532124872. Price: $3.49 |
| 5 |
532132205 |
Bracket, Clutch/Brake Pedal, L.H. Price: $4.84 |
| 6 |
532003145 |
COTTER PIN This part replaces 876020312. Price: $1.40 |
| 7 |
819131016 |
Washer 13/32 x 5/8 x 16 Gauge Price: $3.99 |
| 8 |
817490508 |
Screw, Hex Washer Head Threaded, Rolling 5/16-18 x 1/2 Price: $3.99 |
| 9 |
876020412 |
Pin, Cotter 1/8 x 3/4 Price: $3.99 |
| 10 |
819131316 |
Washer 13/32 x 13/16 x 16 Gauge Price: $2.99 |
| 11 |
532123543 |
Rod, Brake, Front Price: $8.38 |
| 12 |
532136263 |
Assembly, Clutch/Brake Pedal Price: $65.99 |
| 13 |
532123394 |
Rod, Clutch Price: $7.99 |
| 14 |
532121978 |
Bracket, Lift Shaft Price: $2.38 |
| 15 |
532123641 |
Assembly, Brake, Pivot, Arm Price: $12.18 |
| 16 |
819251816 |
Washer 25/32 x 1-1/8 x 16 Gauge Price: $3.99 |
| 17 |
812000034 |
Ring, Klip Price: $2.99 |
| 18 |
532151332 |
SPRING, BRAKE ROD This part replaces 532106888. Price: $2.99 |
| 19 |
873220600 |
Nut, Hex 3/8-16 This part replaces 873350600. Price: $3.99 |
| 20 |
873680600 |
Nut, Crownlock 3/8-16 UNC Price: $1.99 |
| 21 |
532131461 |
CLUTCH KIT This part replaces 532131460. Price: $13.99 |
| 23 |
3210-7 |
SCREW-HH Price: $0.61 |
| 25 |
532004921 |
Retainer Spring This part replaces 532124961. Price: $3.99 |
| 27 |
532136780 |
Link, Lift, Rear Price: $5.99 |
| 28 |
532140777 |
Assembly, Rear Mower Lift This part replaces 532136779. Price: $19.69 |
| 29 |
872110506 |
Bolt, Carriage 5/16-18 UNC x 3/4 Price: $3.99 |
| 30 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873510500. Price: $2.69 |
| 30 |
92-5088 |
FITTING-ELBOW, 45 DEG Price: $124.81 |
| 31 |
532133095 |
Spring, Counterbalance Price: $6.99 |
| 32 |
532133721 |
Link, Lift Lever Price: $13.90 |
| 40 |
72-9420 |
VENT Price: $6.85 |
| 41 |
92-5083 |
HOSE-HYD Price: $25.27 |
| 42 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 43 |
354-71 |
DISCONTINUED Price: Call Us |
| 44 |
77-0550 |
DISCONTINUED Price: Call Us |
| 45 |
289-6 |
NIPPLE-PIPE Price: $6.96 |
| 46 |
2810-1 |
COUPLING-PIPE Price: $4.55 |
| 47 |
2412-119 |
CLAMP-HOSE, WORM DRIVE Price: $1.83 |
