| Ref | Part Number | Description |
|---|
| 1 |
237-79 |
O-RING Price: $5.46 |
| 2 |
340-18 |
FITTING-HYD, 90 DEG Price: $38.93 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
237-22 |
O-RING Price: $2.43 |
| 4 |
340-110 |
FITTING-SWIVEL, 90 DEG Price: $49.98 |
| 5 |
237-42 |
O-RING Price: $2.78 |
| 6 |
76-2810 |
VALVE-NEEDLE Price: $126.27 |
| 7 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 8 |
532139123 |
PULLEY.IDLER.V. This part replaces 532121361. Price: $32.99 |
| 8 |
77-5130 |
DISCONTINUED Price: Call Us |
| 9 |
532177748 |
KEEPER ASM BELT ENGINE Price: $12.99 |
| 9 |
95-5644 |
SEAL KIT This part replaces 69-4270. Price: $19.88 |
| 10 |
532175287 |
BUSHING Price: $17.99 |
| 10 |
95-5636 |
CARTRIDGE-LOGIC, SPOOL This part replaces 69-4190. Price: $415.93 |
| 11 |
353-990 |
PLUG ASM Price: $10.01 |
| 11 |
532179335 |
CLUTCH MZ ZTR GT.48/54"1.125" Price: $299.99 |
| 12 |
237-78 |
O-RING Price: $3.85 |
| 12 |
532143996 |
PULLEY ENG VGT ELECT CLUTCH Price: $37.99 |
| 13 |
94-8140 |
PLUG-ORIFICE (.047) This part replaces 69-4130. Price: $24.85 |
| 14 |
237-58 |
O-RING Price: $2.18 |
| 15 |
3274-20 |
SCREW-HSH Price: $5.65 |
| 15 |
532179115 |
TANK.FUEL.5.0 LEFT.FILL.YTGT Price: $89.99 |
| 16 |
237-81 |
O-RING Price: $2.76 |
| 17 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 18 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 18 |
74-2610 |
TUBE ASSY Price: $116.95 |
| 19 |
323-7 |
SCREW-HH Price: $0.65 |
| 20 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 20 |
532178147 |
CONTROL.THROTTLE.COBRA.42"BLK. Price: $29.99 |
| 21 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532171875. Price: $14.99 |
| 21 |
74-2590 |
TEE-OUTLET, PUMP Price: $263.18 |
| 22 |
340-135 |
O-RING Price: $5.91 |
| 22 |
532175441 |
CHOKE CONTROL This part replaces 532178148. Price: $24.99 |
| 23 |
353-992 |
FLANGE-SPLIT Price: $20.28 |
| 24 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 24 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 25 |
353-991 |
PLUG-HEX, HOLLOW Price: $10.21 |
| 25 |
873920600 |
Nut Keps 3/8-24 Unf Price: $3.99 |
| 26 |
237-156 |
O-RING Price: $1.07 |
| 26 |
532003645 |
BUSHING OUTLET T Price: $3.99 |
| 27 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 27 |
74-2560 |
CARTRIDGE-LOGIC, NC SPOOL TYPE Price: $644.46 |
| 28 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 28 |
532008542 |
FUEL LINE 42" This part replaces 532007834. Price: $5.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
74-2580 |
VALVE - FLOW COMBINING Price: $2,079.20 |
| 30 |
77-0940 |
DISCONTINUED Price: Call Us |
| 31 |
69-5590 |
HOSE ASSEMBLY Price: $131.81 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 39 |
596564004 |
SCREW TT 3/8-16X2.31 UNC This part replaces 817490636. Price: $1.99 |
| 40 |
817490664 |
Screw TT 3/8-16 x 4 Unc Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 47 |
532175288 |
BUSHING Price: $4.99 |
| 62 |
532176252 |
HEAT SHIELD Price: $5.59 |
| 70 |
532175767 |
TUBE.EXHAUST.KAWASAKI.RH Price: $54.99 |
| 71 |
532175766 |
TUBE EXHAUST LH Price: $48.99 |
| 80 |
596433401 |
Nuts This part replaces 532163305. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 84 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
