| Ref | Part Number | Description |
|---|
| 1 |
99-5608-03 |
SPRING-TORSION, RH Price: $35.46 |
| 2 |
99-5609-03 |
SPRING-TORSION, LH Price: $35.46 |
| 3 |
161963 |
Gasket, Gearcase Price: Call Us |
| 3 |
82-6840 |
SPACER Price: $3.31 |
| 4 |
3256-35 |
WASHER-FLAT Price: $0.68 |
| 4 |
5020J |
Bearing, Needle Price: Call Us |
| 5 |
1370H |
Washer, Thrust 5/8 x 1.10 x 1/32 Price: Call Us |
| 5 |
322-7 |
SCREW-HH Price: $0.89 |
| 6 |
137335 |
Pinion, Input Price: Call Us |
| 6 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
140-6431 |
PIVOT PIN ASM This part replaces 95-7158. Price: $37.92 |
| 7 |
145101 |
Shaft, Input Price: Call Us |
| 8 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 8 |
4895H |
Bearing, Needle Price: Call Us |
| 9 |
154467 |
Washer, Seal Price: Call Us |
| 9 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 10 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 10 |
7392M |
Ball, Steel Price: Call Us |
| 11 |
100371K |
Spring, Shift, Fork Price: Call Us |
| 11 |
93-6696 |
DECAL-WARNING Price: $14.78 |
| 12 |
106160X |
O-Ring Price: Call Us |
| 12 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 13 |
142145 |
Asm. Bracket Shift Price: Call Us |
| 13 |
99-5610 |
PIN Price: $40.16 |
| 14 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 14 |
8353J |
Fork, Shift Price: Call Us |
| 15 |
12000039 |
Ring, Klip Price: Call Us |
| 15 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 16 |
154466 |
Shaft, Shift Price: Call Us |
| 16 |
98-1880-03 |
KNUCKLE-PIVOT Price: $350.23 |
| 17 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 18 |
4358J |
Washer Price: Call Us |
| 18 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 19 |
12000040 |
Ring, Klip Price: Call Us |
| 19 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 21 |
102115X |
Gear, Reverse Idler Price: Call Us |
| 21 |
106-9004 |
BUMPER This part replaces 99-5605. Price: $6.35 |
| 22 |
6803J |
Bearing, Needle Price: Call Us |
| 22 |
98-7974 |
WASHER-THRUST Price: $37.96 |
| 23 |
102111X |
Shaft, Reverse Idler Price: Call Us |
| 23 |
99-6903-03 |
NO. 3 LIFT ARM ASM Price: $966.43 |
| 24 |
10040700 |
Washer, Lock 7/16 Price: Call Us |
| 24 |
99-6902-03 |
NO. 2 LIFT ARM ASM Price: $867.02 |
| 25 |
73610700 |
Nut, Hex 7/16-20 Price: Call Us |
| 27 |
143009 |
Bearing, Shaft, Ground Drive L.H. Price: Call Us |
| 28 |
106390X |
Spacer 0.765 x 1.125 x 1.23 Price: Call Us |
| 29 |
102134X |
Chain #35-50 Pitch Price: Call Us |
| 30 |
150737 |
Ground Shaft Assembly Price: Call Us |
| 31 |
143008 |
Bearing, Shaft, Ground Drive R.H. Price: Call Us |
| 32 |
106388X |
Spacer 0.70 x 1.00 x 1.150 Price: Call Us |
| 33 |
102121X |
Sprocket and Gear Assembly Price: Call Us |
| 34 |
102112X |
Shaft, Reduction (2nd) Price: Call Us |
| 35 |
102101X |
Screw, Whiz, Lock 5/16-18 x 3-1/2 Price: Call Us |
| 37 |
4422J |
Bearing, Needle Price: Call Us |
| 38 |
154356 |
Sprocket, Tine Price: Call Us |
| 39 |
105345X |
Gear, Cluster, Red 1st & 2nd Price: Call Us |
| 40 |
105346X |
Gear, Reverse Price: Call Us |
| 41 |
8358J |
Shaft, Reduction (1st) Price: Call Us |
| 42 |
4220R |
Washer, Thrust Price: Call Us |
| 43 |
106146X |
Spacer 1.01 x 1.75 x 0.760 Price: Call Us |
| 44 |
155236 |
Seal Asm, Oil Price: Call Us |
| 49 |
132688 |
Shaft, Tine Price: Call Us |
| 50 |
106147X |
Chain, Roller #50-50 Pitch Price: Call Us |
| 51 |
17720408 |
Screw 1/4-20 x 1/2 Price: Call Us |
| 52 |
73220500 |
Nut, Hex 5/16-18 Price: Call Us |
| 53 |
165140 |
Kit, Bearing Price: Call Us |
| 58 |
179520 |
Bolt Shoulder Price: Call Us |
| 60 |
183226 |
Fitting Grease Price: Call Us |
