| Ref | Part Number | Description |
|---|
| 1 |
None |
O-Ring, 2-1/8 X 2-1/2 X 3/16 |
| 1 |
237-78 |
O-RING Price: $3.85 |
| 1 |
539104190 |
CONTROL LEVER WELDMENT Price: $30.99 |
| 2 |
None |
O-Ring, 3/4 X 1 X 1/8 |
| 2 |
539102592 |
GRIP Price: $7.99 |
| 2 |
99-5610 |
PIN Price: $40.16 |
| 3 |
None |
O-Ring, 2-5/16 X 2-1/2 X 3/32 |
| 3 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 3 |
98-1880-03 |
KNUCKLE-PIVOT This part replaces 98-1880. Price: $350.23 |
| 4 |
None |
Seal, Hydraulic Cylinder Piston Rod Wiper |
| 4 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 4 |
539102593 |
WASHER, 3/8 DISC SPRING SPEC Price: $2.99 |
| 5 |
None |
Retainer, Hydraulic Cylinder Front Head |
| 5 |
237-21 |
O-RING Price: $0.70 |
| 5 |
539102809 |
CONTROL ARM Price: $24.99 |
| 6 |
539990655 |
HCS 3/8C X 1 1/2 Price: $3.99 |
| 6 |
94-8947 |
BUSHING-FLANGE Price: $4.54 |
| 7 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 8 |
539105279 |
PUMP CONTROL LINK Price: $17.99 |
| 9 |
596040901 |
Hardware This part replaces 539990223. Price: $2.99 |
| 10 |
539102590 |
BALL JOINT, RIGHT HANDED Price: $19.99 |
| 11 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 11 |
99-2561 |
DISCONTINUED Price: Call Us |
| 12 |
539104382 |
PUMP LEVER Price: $39.99 |
| 13 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 14 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 15 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 15 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 16 |
106-9208 |
SHORT CYLINDER PIN ASM This part replaces 83-6790. Price: $83.12 |
| 16 |
539991055 |
TAP BOLT 5/16C X 2 1/4 Price: $2.99 |
| 17 |
539103297 |
SPRING Price: $6.99 |
| 18 |
539103547 |
WASHER Price: $0.99 |
| 19 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 19 |
75-6370 |
CAP-SENSOR Price: $8.87 |
| 20 |
32104-76 |
SCREW-HWHTF Price: $2.29 |
| 20 |
596584101 |
Nuts This part replaces 539991073. Price: $2.99 |
| 21 |
539104995 |
SPACER Price: $11.99 |
| 21 |
92-8754 |
DISCONTINUED Price: Call Us |
| 22 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 22 |
94-9998 |
WASHER-THRUST Price: $11.60 |
| 23 |
539102720 |
DAMPENER Price: $39.99 |
| 23 |
94-9974 |
RING-RETAINING Price: $0.70 |
| 24 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 24 |
93-6687 |
DECAL-NO STEP Price: $14.45 |
| 25 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 25 |
99-2564 |
DISCONTINUED Price: Call Us |
| 26 |
539105023 |
BRACKET "I" Price: $6.99 |
| 26 |
92-8002 |
SWITCH-LIFT, BACK BIASED Price: $105.67 |
| 27 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 27 |
75-5350 |
PIN-SLIDE, CYLINDER Price: $41.31 |
| 28 |
140-6431 |
PIVOT PIN ASM This part replaces 95-7158. Price: $37.92 |
| 28 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 29 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 29 |
98-8811 |
CYLINDER - HYD Price: $877.67 |
| 30 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 30 |
596039001 |
Screws This part replaces 539976952. Price: $2.99 |
| 31 |
539104363 |
CONTROL WELDMENT LT Price: $119.99 |
| 31 |
82-6490 |
HOSE Price: $83.18 |
| 32 |
539102591 |
BALL JOINT, LEFT HANDED Price: $19.99 |
| 33 |
539104364 |
CONTROL WELDMENT RT. Price: $119.99 |
| 33 |
75-5890 |
HOSE Price: $75.32 |
| 34 |
539101080 |
SWITCH, INTERLOCK Price: $14.99 |
| 35 |
539102678 |
TAPPED PLATE Price: $12.99 |
| 36 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 37 |
539990588 |
HCS 3/8C X 2 Price: $3.99 |
| 38 |
99-5615 |
DISCONTINUED Price: $1,494.85 |
| 39 |
328-7 |
SCREW-HH Price: $4.00 |
| 40 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 41 |
98-8069 |
CYLINDER - HYD 1-5/8 Price: $778.75 |
| 42 |
92-7564 |
HOSE-HYD Price: $84.98 |
| 43 |
105-0110 |
NO. 5 LIFT ARM ASM This part replaces 99-2565. Price: $912.87 |
| 44 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 45 |
60-6700 |
BOLT-HH Price: $1.29 |
| 46 |
93-7961 |
CLAMP-DRAIN, CASE Price: $12.42 |
| 47 |
93-7960 |
SPACER Price: $5.67 |
| 48 |
82-8170 |
CLAMP Price: $17.27 |
| 49 |
83-6780 |
PIN-CYLINDER Price: $130.51 |
| 50 |
2412-96 |
CLAMP-R Price: $3.46 |
| 51 |
92-7565 |
HOSE ASM Price: $89.51 |
| 52 |
322-4 |
SCREW-HH Price: $0.35 |
| 53 |
92-7562 |
HOSE ASM Price: $71.47 |
| 54 |
138-6951 |
CYLINDER ASM-HYDRAULIC This part replaces 93-2650. Price: $664.52 |
| 55 |
93-6693 |
DECAL-PLATE, FLOOR Price: $10.84 |
| 57 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 60 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 61 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 62 |
98-7974 |
WASHER-THRUST Price: $37.96 |
| 63 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 64 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 65 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 66 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 67 |
33114-010 |
SCREW-HH Price: $1.56 |
| 68 |
106-9004 |
BUMPER This part replaces 99-5605. Price: $6.35 |
| 69 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 70 |
302-60 |
FITTING-GREASE Price: $2.26 |
