| Ref | Part Number | Description |
|---|
| 1 |
121472X |
Wheel Steering (AYP part number) Price: Call Us |
| 1 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 2 |
156483 |
Axle Asm Stmp Dropped STLT Price: Call Us |
| 3 |
156483 |
Spindle Asm LH Price: Call Us |
| 3 |
237-68 |
O-RING Price: $3.22 |
| 4 |
120-5118 |
SHAFT-ADJUSTER Price: $44.64 |
| 4 |
157473 |
Spindle Asm RH Price: Call Us |
| 5 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 5 |
6266H |
Bearing Race Thrust Harden Price: Call Us |
| 6 |
119-4067 |
SCREW-HH Price: $0.81 |
| 6 |
121748X |
Washer 25/32 X 1-5/8 X 16 Ga Price: Call Us |
| 7 |
19272016 |
Washer 27/32 X 1-1/4 X 16 Ga Price: Call Us |
| 7 |
99-2097 |
DETENT Price: $12.71 |
| 8 |
120-5116 |
WASHER-WAVE Price: $9.17 |
| 8 |
12000029 |
Ring Klip #t5304-75 Price: Call Us |
| 9 |
108-0015 |
WASHER-FLAT Price: $0.39 |
| 9 |
3366R |
Bearing Col Strg Blk Price: Call Us |
| 10 |
137-6130 |
SCREW-ADJUSTER, BEDBAR This part replaces 115-7039. Price: $25.42 |
| 10 |
156438 |
Link Drag Extended Stamped Price: Call Us |
| 11 |
10040600 |
Washer Lock Hvy Hlcl Spr 3/8 Price: Call Us |
| 11 |
119-4155 |
WASHER-HARDENED Price: $4.16 |
| 12 |
120-5120 |
SPRING-COMPRESSION Price: $2.89 |
| 13 |
119-4039 |
NUT-HEX, NI Price: $0.28 |
| 13 |
154779 |
Bearing Axle STLT/GT Price: Call Us |
| 15 |
112-1718-01 |
BEDBAR Price: $300.88 |
| 15 |
73901000 |
Nut Lock Flange 5/8-11 Unc Price: Call Us |
| 16 |
119-4151 |
SCREW-BEDKNIFE Price: $0.41 |
| 17 |
137-6091 |
BEDKNIFE-EDGEMAX This part replaces 121-3165. Price: $172.72 |
| 17 |
156546 |
Shaft Asm Strg Price: Call Us |
| 18 |
57079 |
Washer Thrust 515 x 750 x 033 Price: Call Us |
| 19 |
124035X |
Support Shaft (AYP part number) Price: Call Us |
| 20 |
126684X |
Washer Shim 1/4 X 5/8 X 062 (AYP part number) Price: Call Us |
| 22 |
71200410 |
Screw Hex Socket 1/4-20 x 5/8 (AYP part number) Price: Call Us |
| 23 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532127501. Price: $27.99 |
| 24 |
61-1950 |
WASHER-PLASTIC Price: $0.55 |
| 25 |
154406 |
Bracket Steering Price: Call Us |
| 25 |
56-9520 |
BUSHING-FLANGED Price: $2.15 |
| 26 |
126847X |
Bushing Link Drag Blk LR Price: Call Us |
| 26 |
69-8980 |
WASHER Price: $0.58 |
| 27 |
120-9941 |
BOLT-BEDBAR Price: $13.66 |
| 27 |
136874 |
Gear Sector Price: Call Us |
| 28 |
19131416 |
Washer 13/32 X 7/8 X 16 Ga. (AYP part number) Price: Call Us |
| 28 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 29 |
127-4284 |
WASHER-SPECIAL Price: $5.88 |
| 29 |
17490612 |
Screw Thdrol 3/8-16 x 3/4 Ty-tt Price: Call Us |
| 30 |
115-5258 |
SPRING-WIRE, FLAT Price: $3.40 |
| 30 |
76020412 |
Pin Cotter 1/8 X 3/4 Cad. Price: Call Us |
| 31 |
140-5510 |
BEARING-SEALED, STAINLESS This part replaces 115-3296. Price: $28.48 |
| 32 |
115-3299 |
SEAL-FLOCKED Price: $13.85 |
| 32 |
130465 |
Rod Tie (AYP part number) Price: Call Us |
| 34 |
137-8407 |
ES REEL+,5IN FWY(18)11 BLD LD(FSR) This part replaces 133-0112. Price: $767.86 |
| 36 |
155099 |
Bushing Strg (AYP part number) Price: Call Us |
| 37 |
130-0064 |
INSERT-THREADED, 5 INCH (LH) Price: $42.48 |
| 37 |
152927 |
Screw Price: Call Us |
| 38 |
126805X |
Insert Cap Strg Wh Au Price: Call Us |
| 38 |
130-0063 |
INSERT-THREADED, 5 INCH (RH) Price: $42.48 |
| 39 |
19133808 |
Washer 13/32 X 2-3/8 X 8 Ga Price: Call Us |
| 39 |
3296-28 |
NUT-LOCK, NI Price: $0.61 |
| 40 |
7810H |
Lock nut Price: Call Us |
| 41 |
100711L |
Adaptor Wheel Strg Price: Call Us |
| 42 |
145054 |
Boot Steering Dash Price: Call Us |
| 43 |
121749X |
Washer 25/32 X 1 1/4 X 16 Ga Price: Call Us |
| 44 |
153720 |
Extension Steering Shaft LR/LT (AYP part number) Price: Call Us |
| 46 |
121232X |
Cap Spindle Fr Top Blk Price: Call Us |
| 47 |
6855M |
Fitting Grease Price: Call Us |
| 51 |
73800500 |
Nut Lock Hex w/Ins 5/16-18 Price: Call Us |
| 54 |
74780520 |
Bolt Fin Hex 5/16-18 Unc x 1-1/4 Price: Call Us |
| 62 |
156594 |
Kit, Steering Assembly Svc Price: Call Us |
| 63 |
74780616 |
Bolt Fin Hex 3/8-16 unc x 1 Gr. 5 Price: Call Us |
| 65 |
154780 |
Spacer Axle Price: Call Us |
| 66 |
154404 |
Bearing Arm Pittman Price: Call Us |
| 67 |
74781044 |
Bolt, Fin Hex 5/8-11 UNC x 2-3/4 Price: Call Us |
