| Ref | Part Number | Description |
|---|
| 1 |
194177X421 |
Control Bar Price: Call Us |
| 1 |
71-2200 |
SWING ARM ASM Price: $366.84 |
| 2 |
194179X479 |
Upper Handle Price: Call Us |
| 3 |
169708X479 |
Lower Handle Price: Call Us |
| 4 |
194788 |
Rope Guide Price: Call Us |
| 4 |
71-2290 |
FORK AND TRIPLE BEARING ASM Price: $199.01 |
| 5 |
132004 |
Nut, Hex Price: Call Us |
| 5 |
71-2310 |
DISCONTINUED Price: Call Us |
| 6 |
191574 |
Handle Bolt Price: Call Us |
| 7 |
664-26 |
Wire Tie Price: Call Us |
| 10 |
71-2280 |
BAND-INDICATOR, WEIGHT Price: $18.88 |
| 11 |
183281 |
Cable, Engine Zone Control Price: Call Us |
| 11 |
40-4150 |
ROLLER Price: $7.98 |
| 12 |
40-4160 |
GUIDE-SLEEVE Price: $4.51 |
| 12 |
750634 |
Hex Washer Head Screw Price: Call Us |
| 13 |
429930X004 |
Up-Stop Bracket Price: Call Us |
| 14 |
189713X428 |
Knob, Handle Price: Call Us |
| 15 |
51793 |
Hairpin Cotter Price: Call Us |
| 15 |
71-2240 |
KNOB ASM Price: $80.40 |
| 17 |
40-4230 |
PLUG Price: $6.02 |
| 18 |
17600406 |
Screw Price: Call Us |
| 18 |
71-2250 |
BRACKET-SPRING Price: $28.69 |
| 19 |
401174X004 |
Axle Arm Assembly, Front, LH Price: Call Us |
| 19 |
71-2330 |
RING-SNAP Price: $1.25 |
| 20 |
401175X004 |
Axle Arm Assembly, Front, RH Price: Call Us |
| 20 |
71-2340 |
ABSORBER-SHOCK Price: $317.85 |
| 21 |
418655 |
Kit, Rear Skirt Price: Call Us |
| 21 |
71-2320 |
PIN Price: $7.60 |
| 22 |
401621X004 |
Selector Spring, Front Price: Call Us |
| 23 |
401814X428 |
Rear Door Assembly Price: Call Us |
| 23 |
71-2270 |
NUT-SPECIAL Price: $3.05 |
| 24 |
1-613235 |
WASHER This part replaces 40-4070. Price: $1.49 |
| 24 |
426589 |
Nut, Hex 5/16-18 Price: Call Us |
| 25 |
40-4310 |
BEARING-THRUST, NEEDLE Price: $36.99 |
| 25 |
410387X479 |
Handle Bracket Assembly, LH Price: Call Us |
| 26 |
40-4060 |
DISCONTINUED Price: Call Us |
| 26 |
410388X479 |
Handle Bracket Assembly, RH Price: Call Us |
| 27 |
71-2260 |
SPRING Price: $84.32 |
| 28 |
407499X005 |
Wheel Adjusting Bracket, Front, LH Price: Call Us |
| 29 |
407500X005 |
Wheel Adjusting Bracket, Front, RH Price: Call Us |
| 30 |
401629 |
Spacer Price: Call Us |
| 32 |
401623X004 |
Selector Spring, Rear Price: Call Us |
| 33 |
701037X421 |
Selector Knob Price: Call Us |
| 34 |
401173X004 |
Axle Arm Assembly, Rear, LH Price: Call Us |
| 36 |
401638 |
Shoulder Bolt 5/16-18 Price: Call Us |
| 37 |
193931X428 |
Wheel & Tire Assembly, Front 7 x 1-3/4 Price: Call Us |
| 40 |
411949 |
Frame, Grassbag Price: Call Us |
| 41 |
88652 |
Hinge Screw Price: Call Us |
| 42 |
405421 |
Spring, Rear Door, LH Price: Call Us |
| 43 |
405423 |
Spring, Rear Door, RH Price: Call Us |
| 44 |
184193 |
Bolt, Rear Door Price: Call Us |
| 45 |
150406 |
Hex Head Thread Rolling Screw 3/8-16 x 1 Price: Call Us |
| 46 |
404763 |
Danger Decal Price: Call Us |
| 47 |
73930500 |
Nut, Hex Price: Call Us |
| 49 |
193905X428 |
Wheel & Tire Assembly, Rear 8 x 1-3/4 Price: Call Us |
| 50 |
411060 |
Grassbag Price: Call Us |
| 53 |
851084 |
Hex Head Screw 3/8-24 x 1-3/8 Grade 8 Price: Call Us |
| 54 |
850263 |
Helical Lockwasher Price: Call Us |
| 55 |
851074 |
Hardened Washer Price: Call Us |
| 57 |
851514 |
Blade Adapter Price: Call Us |
| 61 |
409148 |
Flanged Locknut, Hex Price: Call Us |
| 67 |
197991 |
Clip, Cable Price: Call Us |
| 73 |
401630 |
Washer, Curved, Cylindrical Price: Call Us |
| 74 |
851201X004 |
Washer, Special, Engine Price: Call Us |
| 76 |
410589 |
Baffle, Rear Price: Call Us |
| 77 |
17411312 |
Screw, Rear Baffle Price: Call Us |
| 77 |
193732 |
Operator's Manual, English Price: Call Us |
| 77 |
193734 |
Operator's Manual, French Price: Call Us |
