| Ref | Part Number | Description |
|---|
| 2 |
194177X428 |
Control Bar Price: Call Us |
| 3 |
194788 |
Rope Guide Price: Call Us |
| 4 |
194179X479 |
Upper Handle Price: Call Us |
| 5 |
169708X479 |
Lower Handle Price: Call Us |
| 6 |
192301X004 |
Hinge Bracket Price: Call Us |
| 7 |
191574 |
Handle Bolt 5/16-18 Price: Call Us |
| 8 |
161622 |
Clip, Closeout Price: Call Us |
| 9 |
160830 |
Mulcher Plate Price: Call Us |
| 010 |
98-9459 |
CAMSHAFT-FUEL Price: $159.71 |
| 10 |
132004 |
Locknut, Hex 1/4-20 Price: Call Us |
| 11 |
158152 |
Engine Zone Control Cable Price: Call Us |
| 12 |
750634 |
Screw, Hex Head, Threaded, Rolled #10-24 x1/2 Price: Call Us |
| 13 |
86899X004 |
Up-Stop Bracket Price: Call Us |
| 15 |
186577X004 |
Axle Arm Assembly (Rear, RH / Front, LH) Price: Call Us |
| 16 |
189713X428 |
Handle Knob Price: Call Us |
| 18 |
186578X004 |
Axle Arm Assembly (Rear, LH / Front, RH) Price: Call Us |
| 19 |
51793 |
Hairpin Cotter Price: Call Us |
| 020 |
98-9382 |
BEARING-BALL Price: $23.27 |
| 20 |
750097 |
Screw Price: Call Us |
| 21 |
188987 |
Rear Deflector Price: Call Us |
| 22 |
664-26 |
Wire Tie Price: Call Us |
| 23 |
160831 |
Discharge Guard Price: Call Us |
| 25 |
166785 |
Nut, Hex Price: Call Us |
| 27 |
193436 |
Torsion Spring Price: Call Us |
| 28 |
193825 |
Blade Adapter Price: Call Us |
| 030 |
98-9383 |
DISCONTINUED Price: Call Us |
| 30 |
851074 |
Hardened Washer Price: Call Us |
| 31 |
850263 |
Helical Lockwasher 3/8 Price: Call Us |
| 32 |
851084 |
Hex Head Screw 3/8-24 x 1/4 Grade 8 Price: Call Us |
| 33 |
73930500 |
Nut, Hex, Centerlock 5/16-18 Price: Call Us |
| 34 |
400781X479 |
Support, Wheel Bracket, LH Price: Call Us |
| 35 |
400782X479 |
Support, Wheel Bracket, RH Price: Call Us |
| 36 |
160835X007 |
Adjuster, Wheel Bracket Price: Call Us |
| 37 |
160833 |
Hinge Rod Price: Call Us |
| 38 |
404763 |
Danger Decal Price: Call Us |
| 39 |
168360X004 |
Selector Spring Price: Call Us |
| 040 |
98-9590 |
NUT-CAP Price: $3.86 |
| 40 |
87877 |
Selector Knob Price: Call Us |
| 41 |
150406 |
Screw, Hex Head, Threaded, Rolled 3/8-16 x 1 Price: Call Us |
| 43 |
183901 |
Washer Price: Call Us |
| 44 |
160828 |
Shoulder Bolt Price: Call Us |
| 45 |
193851X617 |
Wheel & Tire Assembly, Rear, 8" Price: Call Us |
| 46 |
83923 |
Locknut, Hex 3/8-16 Price: Call Us |
| 47 |
193855X617 |
Wheel & Tire Assembly, Front, 7" Price: Call Us |
| 48 |
17600406 |
Screw, Hex Head, Serrated, Type TT 1/4 x 20 Price: Call Us |
| 050 |
98-9595 |
KEY-WOODRUFF Price: $2.04 |
| 53 |
197991 |
Clip, Cable Price: Call Us |
| 060 |
98-9669 |
GEAR-PUMP, INJECTION Price: $86.00 |
| 070 |
98-9511 |
STOPPER-FUEL, CAMSHAFT Price: $5.18 |
| 080 |
98-9350 |
BOLT Price: $0.98 |
| 090 |
98-9644 |
GOVERNOR SHAFT ASM Price: $527.54 |
| 100 |
98-9562 |
HOLDER-GEAR, GOVERNOR Price: $61.49 |
| 110 |
98-9673 |
GEAR-GOVERNOR Price: $137.25 |
| 120 |
98-9561 |
HOLDER-WEIGHT, GOVERNOR Price: $23.68 |
| 130 |
98-9559 |
GOVERNOR WEIGHT ASM Price: $105.15 |
| 140 |
98-9560 |
SHAFT-WEIGHT, GOVERNOR Price: $6.17 |
| 145 |
98-9692 |
ROLLER Price: $11.45 |
| 150 |
98-9563 |
SLEEVE-GOVERNOR Price: $29.68 |
| 160 |
98-9564 |
WASHER-THRUST Price: $5.01 |
| 170 |
98-9381 |
BEARING-BALL Price: $21.66 |
| 180 |
98-9657 |
CIRCLIP-SHAFT, GOVERNOR Price: $4.48 |
| 193732 |
Operator's |
Manual, English Price: Call Us 193732 |
