| Ref | Part Number | Description |
|---|
| 1 |
142829 |
SUB= 145775 Price: Call Us |
| 2 |
72140506 |
BOLT Price: Call Us |
| 2 |
99-5610 |
PIN Price: $40.16 |
| 3 |
138017 |
BRKT ASM SWAY BAR Price: Call Us |
| 3 |
98-1880-03 |
KNUCKLE-PIVOT This part replaces 98-1880-01. Price: $350.23 |
| 4 |
105-3366 |
NO. 1 LIFT ARM ASM Price: $1,019.52 |
| 4 |
138440 |
BRKT DECK SW BAR Price: Call Us |
| 5 |
4939M |
SUB= 85902 Price: Call Us |
| 5 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 6 |
130832 |
SUB= 130833 Price: Call Us |
| 6 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 7 |
106-9208 |
SHORT CYLINDER PIN ASM This part replaces 83-6790. Price: $83.12 |
| 8 |
850857 |
BLADE BOLT Price: Call Us |
| 8 |
94-9998 |
WASHER-THRUST Price: $11.60 |
| 9 |
10030600 |
SUB= 10040600 Price: Call Us |
| 9 |
94-9974 |
RING-RETAINING Price: $0.70 |
| 10 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 10 |
75-5350 |
PIN-SLIDE, CYLINDER Price: $41.31 |
| 11 |
140-6431 |
PIVOT PIN ASM This part replaces 95-7158. Price: $37.92 |
| 12 |
129895 |
BEARING.BALL Price: Call Us |
| 13 |
137645 |
SUB= 137646 Price: Call Us |
| 13 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 14 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 14 |
33114-020 |
SCREW-HH Price: $0.28 |
| 15 |
110485X |
BEARING Price: Call Us |
| 15 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 16 |
140329 |
STRIPPER RND MWR Price: Call Us |
| 16 |
99-5621 |
GUIDE-HOSE Price: $34.45 |
| 17 |
2412-96 |
CLAMP-R Price: $3.46 |
| 18 |
105-7916 |
HYD HOSE ASM Price: $202.95 |
| 19 |
132827 |
BOLT SHD 5/16-18 Price: Call Us |
| 19 |
322-4 |
SCREW-HH Price: $0.35 |
| 20 |
105-9274 |
HYD HOSE ASM Price: $242.86 |
| 21 |
138-6951 |
CYLINDER ASM-HYDRAULIC This part replaces 93-2650. Price: $664.52 |
| 21 |
73680500 |
SUB= 73690500 Price: Call Us |
| 23 |
137607 |
BRKT DEFLECTOR Price: Call Us |
| 23 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 24 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 24 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 25 |
123713X |
SPRING TORSION Price: Call Us |
| 25 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 26 |
110452X |
NUT PUSH M Price: Call Us |
| 26 |
98-7974 |
WASHER-THRUST Price: $37.96 |
| 27 |
106736X |
DEFLECTOR-SHLD T Price: Call Us |
| 27 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 28 |
19111016 |
WASHER Price: Call Us |
| 28 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 29 |
106735X |
ROD-HINGE T Price: Call Us |
| 29 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 30 |
138776 |
SUB= 157722 Price: Call Us |
| 30 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 31 |
129963 |
WASHER Price: Call Us |
| 31 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 32 |
105-0142-03 |
ROD-PIVOT, FRONT Price: $122.57 |
| 32 |
153532 |
PULLEY.MANDREL.38 Price: Call Us |
| 33 |
137266 |
SUB= 139729 Price: Call Us |
| 33 |
98-3929 |
SPRING-TORSION Price: $23.85 |
| 34 |
93-6738 |
CHAIN Price: $13.80 |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 36 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 36 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 40 |
73680600 |
SUB= 73690600 Price: Call Us |
| 41 |
133551 |
PIVOT ROD Price: Call Us |
| 43 |
133504 |
CLUTCH ROD SECOND Price: Call Us |
| 45 |
4497H |
RETAINER M Price: Call Us |
| 53 |
130840 |
BRAKE ASM Price: Call Us |
| 54 |
133943 |
HARDENED WASHER Price: Call Us |
| 55 |
133840 |
IDLER ARM ASSY Price: Call Us |
| 56 |
122052X |
SPACER RETAINER Price: Call Us |
| 67 |
106932X |
KNOB T(3/8 HOLE) Price: Call Us |
| 68 |
144200 |
BELT.V.T-PATH Price: Call Us |
| 69 |
76020312 |
SUB= 3145 Price: Call Us |
| 71 |
142427 |
ROD CLUTCH 38/42 Price: Call Us |
| 72 |
131870 |
RETURN SPRING Price: Call Us |
| 73 |
127847 |
CLUTCH ARM SECOND Price: Call Us |
| 74 |
121748X |
WASHER Price: Call Us |
| 75 |
12000029 |
RING Price: Call Us |
| 76 |
128903 |
SHOULDER BOLT Price: Call Us |
| 77 |
127845 |
SPRING KEEPER Price: Call Us |
| 78 |
154809 |
LEVER ASM-CLUTCH Price: Call Us |
| 79 |
127498 |
BUSHING Price: Call Us |
| 80 |
153701 |
SPRING.CLUTCH.MWR Price: Call Us |
| 81 |
73350600 |
NUT Price: Call Us |
| 82 |
142028 |
TRUNION ADJ Price: Call Us |
| 86 |
7631J |
RUNNER-LH M Price: Call Us |
| 87 |
128772 |
RUNNER RH Price: Call Us |
| 88 |
19111216 |
WASHER M Price: Call Us |
| 89 |
19131612 |
WASHER GT Price: Call Us |
| 107 |
133502 |
RETAINER SPACER Price: Call Us |
| 108 |
133503 |
IDLER ARM STIFF Price: Call Us |
| 109 |
74760640 |
BOLT Price: Call Us |
| 110 |
142587 |
UPSTOP DECK FT 38 Price: Call Us |
| 116 |
17490512 |
SCREW Price: Call Us |
| 122 |
131289 |
BRAKE ROD LH Price: Call Us |
| 123 |
131288 |
BRAKE ROD RH Price: Call Us |
| 124 |
72110614 |
BOLT Price: Call Us |
| 128 |
153390 |
WASHER.FELT. Price: Call Us |
| 130794 |
MANDREL |
ASM Price: Call Us 130794 |
