| Ref | Part Number | Description |
|---|
| 1 |
HG-71097 |
Kit, Housing, Main, LH Price: $432.84 |
| 2 |
HG-70983L |
Kit, Housing, Side, LH Price: $124.29 |
| 4 |
HG-70723 |
Kit, Block, 7 Piston Price: $200.36 |
| 5 |
HG-54315 |
SPACER .32 x 1.005 x .179 This part replaces HG-52527. Price: $2.30 |
| 6 |
HG-70331 |
Kit, Block, 10cc Cylinder Price: $165.42 |
| 7 |
HG-9005110-5600 |
Plug, 9/16-18 Price: $17.80 |
| 9 |
HG-53246 |
Screw, Hex Washer Price: $2.95 |
| 15 |
HG-51625 |
Rod, Bypass Price: $14.41 |
| 16 |
HG-51627 |
Ring, Ret .375 External Price: $3.63 |
| 18 |
HG-51628 |
Ring, Retaining .375 External Price: $3.63 |
| 19 |
HG-51048 |
Trunnion, Swashplate Price: $77.60 |
| 24 |
736-0371 |
Washer, .34 x .88 x .06 Price: $3.94 |
| 27 |
HG-2003014 |
Spring, Block Price: $4.13 |
| 28 |
HG-2003017 |
Washer, .59 x .79 x .04 Price: $3.75 |
| 29 |
HG-51062P |
INPUT SHAFT This part replaces HG-51062. Price: $118.00 |
| 30 |
HG-50315 |
Ball Bearing 17 x 40 x 12 Price: $15.85 |
| 31 |
HG-2000022 |
Ring, Reatining Price: $3.90 |
| 32 |
HG-50951 |
Washer, 1.23 x 1.57 x .04 Price: $3.76 |
| 33 |
HG-51161 |
Seal, Lip 17 x 40 x 7 Price: $10.34 |
| 34 |
HG-50329 |
Ring Retaining Internal Price: $9.70 |
| 35 |
HG-50551P |
Thrust Bearing, 30 x 52 x 13 Price: $26.00 |
| 36 |
HG-44371 |
Washer, .63 x 1.00 x .05 Price: $13.59 |
| 37 |
HG-44145 |
Ring, Reatining, Motor Shaft Price: $3.68 |
| 38 |
HG-51130 |
Gear, 13T Pinion Price: $8.69 |
| 39 |
HG-51845 |
Shaft, Motor Price: $67.19 |
| 40 |
HG-51069 |
Washer, .71 x 1.16 x .04 Price: $3.76 |
| 41 |
HG-50132 |
Washer Price: $3.90 |
| 42 |
HG-51129 |
Gear, 10T/48T Price: $46.69 |
| 43 |
HG-51043 |
Gear, 10T Jackshaft Price: $24.65 |
| 44 |
HG-51083 |
Pin, Jackshaft Price: $29.08 |
| 45 |
HG-52531 |
Ring, Spiral Retaining-87 Price: $2.90 |
| 46 |
HG-52541 |
Gear, Bull 52T Price: $54.14 |
| 47 |
HG-52532 |
Washer, 1.018 x 1.571 x .105 Price: $2.44 |
| 48 |
HG-52542 |
Buahing, Sleeve (Inboard) Price: $5.67 |
| 49 |
HG-52545 |
Shaft, Axle, 1.00 x 11.70 DD Price: $80.02 |
| 50 |
HG-51517 |
Bushing, 1.003 x 1.571 x .625 Price: $10.30 |
| 51 |
HG-51518 |
Seal, Lip, TC4, 1.00 x 1.577 x .27 Price: $11.37 |
| 52 |
HG-70853 |
Kit, Seals & Rings Price: $60.20 |
| 53 |
HG-70868L |
Kit, Expansion Plate LH Price: $18.69 |
| 54 |
HG-72135 |
Kit, Fan & Pulley Price: $51.94 |
| 55 |
HG-71356 |
Kit, Brake Arm Price: $20.65 |
| 57 |
HG-71529 |
Kit, Center Section LH Price: $203.90 |
| 59 |
HG-71006 |
Kit, Bypass Arm Price: $17.33 |
| 61 |
HG-71497 |
Kit, Filter Price: $17.43 |
| 100 |
HG-51635 |
Disc, Cog Brake Price: $15.37 |
| 131 |
HG-71341 |
Socket Cap Screw, 5/16-24 x 7/8 Price: $7.94 |
| 135 |
732-04448 |
Spring, Extension Price: $9.09 |
| 138 |
HG-71510 |
Kit, Breather Price: $19.71 |
| 140 |
HG-51946 |
Arm, Left Return Price: $12.05 |
| 200 |
HG-71592 |
Kit, RTN Bidirectional Price: $42.78 |
