| Ref | Part Number | Description |
|---|
| 1 |
131-1235 |
RIGHT DECK ASM Price: $2,726.27 |
| 1 |
532170690 |
TUBE HANDLE BAGGER This part replaces 532165249. Price: $7.14 |
| 2 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 3 |
3296-45 |
NUT-HEX Price: $3.79 |
| 3 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 4 |
131-1231-01 |
PLATE-STIFFENER Price: $95.51 |
| 4 |
532169916 |
HANDLE.BAGGER.W/LVRS.BLK.CRD Price: $9.99 |
| 5 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 5 |
874981024 |
SCREW.PAN.HEAD Price: $4.99 |
| 6 |
132-9421 |
PULLEY-IDLER, FLAT Price: $41.10 |
| 6 |
532750029 |
SCREW This part replaces 874981032. Price: $4.99 |
| 7 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 7 |
873401000 |
NUT Price: $6.99 |
| 8 |
108-8076 |
V-BELT, DECK Price: $29.86 |
| 8 |
532441543 |
COVER.PNT.BGR.CRD.WSLOTS.MS668 This part replaces 532181095. Price: $199.99 |
| 9 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 9 |
872140418 |
Bolt Carriage 1/4-20 x 2.25d x Gr.5 Price: $7.99 |
| 10 |
139-1039 |
LOW DRIVEN SPINDLE ASM This part replaces 119-4776. Price: $589.65 |
| 10 |
583110201 |
TUBE.SUPPORT.BAGGER.CRD This part replaces 532181282. Price: $59.99 |
| 11 |
32108-103 |
SCREW-FH Price: $0.68 |
| 11 |
532165719 |
BRACKET.SUPPORT.UPPER.BAG.CRD Price: $9.99 |
| 12 |
583173701 |
BRKT.PIVOT.LH.CRD This part replaces 532188848. Price: $7.99 |
| 12 |
69-9290 |
PAD-BUMPER Price: $9.52 |
| 13 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 14 |
104-2250-01 |
SKID-SIDE Price: $116.02 |
| 14 |
596564404 |
Bolts This part replaces 874520636. Price: $2.99 |
| 15 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 15 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 16 |
131-1243 |
PLATE-SPINDLE Price: $62.97 |
| 16 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 17 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 17 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 18 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 19 |
132-6150-01 |
BRACKET-CASTER Price: $155.45 |
| 19 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 20 |
100-5623 |
DECAL-HOC Price: $20.17 |
| 20 |
532188847 |
BRKT.PIVOT.RH.CRD Price: $7.99 |
| 21 |
120-5587 |
PIN-CLEVIS Price: $10.38 |
| 21 |
532193838 |
NEEDS DESCRIPTION Price: Call Us |
| 22 |
104-7524 |
SHIM Price: $5.30 |
| 22 |
532165781 |
BRKT.SIDE.BAG.CRD Price: $2.99 |
| 23 |
132-6157-01 |
BRACKET-FORK Price: $59.18 |
| 24 |
3231-33 |
SCREW-CARR Price: $4.29 |
| 24 |
532165783 |
TUBE.PIVOT.BAG.CRD.BLACK Price: $22.99 |
| 25 |
3233-2 |
SCREW-CARR Price: $1.49 |
| 25 |
583211601 |
TUBE.FRONT.BAGGER.CRD This part replaces 532193705. Price: $84.99 |
| 26 |
106-2047 |
ROD-TENSION Price: $9.83 |
| 27 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 28 |
104-0858 |
BOLT-SHOULDER Price: $4.69 |
| 28 |
532165787 |
GRIP.HANDLE.BLACK Price: $5.99 |
| 29 |
920242 |
WASHER-FLAT This part replaces 9202424. Price: $5.19 |
| 30 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 31 |
325-7 |
SCREW-HH Price: $1.53 |
| 31 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 32 |
32120-72 |
RING-SNAP Price: $2.09 |
| 32 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 33 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 34 |
110-6128 |
IDLER ARM ASM Price: Call Us |
| 34 |
532165570 |
HANDLE.MULCHER.92.CRD (2 2) Price: $44.99 |
| 35 |
32128-14 |
NUT-HF Price: $0.41 |
| 35 |
532165572 |
PIN Price: $12.99 |
| 36 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 36 |
68-0090 |
SCREW-ADJUSTING Price: $7.49 |
| 37 |
139-1728 |
BOLT-HH FT This part replaces 9114524. Price: $1.29 |
| 37 |
532175401 |
Plug Support Bagger CRD Price: Call Us |
| 38 |
107938 |
SPRING-EXTENSION Price: $9.99 |
| 38 |
872010520 |
BOLT.5/16-18X2.5 Price: $4.99 |
| 39 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 39 |
532416257 |
SEAL.BAGGER.CRD This part replaces 532180985. Price: $29.99 |
| 40 |
9136144 |
SCREW-HWHTF Price: $6.29 |
| 41 |
532169683 |
BRKT.VERT.ADJ.BAGGER.CRD Price: $4.99 |
| 41 |
70-1160 |
WASHER Price: $3.59 |
| 43 |
532174083 |
PLUG, TUBING END Price: $5.99 |
| 44 |
532193312 |
NEEDS DESCRIPTION Price: Call Us |
| 46 |
872110510 |
BOLT.CARRIAGE.5/16-18 Price: $4.99 |
| 47 |
583211501 |
TUBE.UPPER.BAGGER.CRD This part replaces 532193704. Price: $279.99 |
| 49 |
583208201 |
BAR.SPREADER.BAGGER.CRD This part replaces 532193305. Price: $12.99 |
| 50 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 51 |
529846601 |
SERVICE KIT LATCH.SPRING.BAGGE This part replaces 532199903. Price: $1.99 |
| 52 |
582735501 |
BOLT.CARRIAGE.1/4-20X3/4 This part replaces 872110406. Price: $6.99 |
| 53 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
