| Ref | Part Number | Description |
|---|
| 1 |
106-8094 |
DECAL-CONTROL PANEL This part replaces 66-2460. Price: $91.63 |
| 1 |
93-7835 |
PANEL-CONTROL Price: $60.41 |
| 2 |
3274-65 |
SCREW-HSBH Price: $1.15 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
138-1911 |
PTO SWITCH KIT This part replaces 85-4980. Price: $320.00 |
| 4 |
218-576 |
DISCONTINUED Price: Call Us |
| 5 |
66-2960 |
WARNING LAMP CLUSTER Price: $210.90 |
| 6 |
66-2940 |
GAUGE-FUEL Price: $178.34 |
| 7 |
27-2360 |
SWITCH Price: $46.56 |
| 8 |
218-447 |
WASHER-LOCK Price: $3.79 |
| 9 |
218-446 |
NUT-HEX Price: $6.09 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 11 |
218-473 |
BOOT-SWITCH Price: $17.61 |
| 11 |
532179335 |
CLUTCH MZ ZTR GT.48/54"1.125" Price: $299.99 |
| 12 |
218-497 |
DISCONTINUED PLEASE SEE NOTES Price: Call Us |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 13 |
6-1659 |
SWITCH & BOOT ASM Price: $78.15 |
| 14 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 15 |
532420723 |
RP_TANK.ASM.4.GAL.CARB.1.PORT. This part replaces 532414152. Price: $249.99 |
| 15 |
98-9308 |
GAUGE-TEMPERATURE This part replaces 63-7430. Price: $112.90 |
| 16 |
85-7560 |
DISCONTINUED Price: Call Us |
| 17 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 This part replaces 532430213. Price: $37.99 |
| 18 |
69-4780 |
CLAMP-GAUGE Price: $73.28 |
| 19 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 20 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 70 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 This part replaces 532146699. Price: $19.99 |
| 71 |
532466700 |
Tube Exhaust RH Price: Call Us |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $54.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 111 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
| 113 |
597791601 |
VALVES This part replaces 532414127. Price: $9.99 |
