| Ref | Part Number | Description |
|---|
| 1 |
539104190 |
CONTROL LEVER WELDMENT Price: $30.99 |
| 1 |
76-5070 |
OIL PUMP ASM Price: $729.22 |
| 1 |
925-04514 |
BATTERY Not Available This part replaces 725-3174. Price: |
| 2 |
539102592 |
GRIP Price: $7.99 |
| 2 |
725-3220 |
POITIVE BATTERY CABLE Not Available Price: |
| 2 |
94-3176 |
VALVE-RELIEF Price: $5.60 |
| 3 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 3 |
725-3221 |
NEGATIVE BATTERY CABLE Not Available Price: |
| 3 |
76-5090 |
SPRING-PISTON Price: $4.54 |
| 4 |
539102593 |
WASHER, 3/8 DISC SPRING SPEC Price: $2.99 |
| 4 |
710-3083 |
Screw, Hex Cap, 5/16-18 X 1.38 Lg Price: $3.94 |
| 4 |
94-3179 |
WASHER-SPRING Price: $1.50 |
| 5 |
539102809 |
CONTROL ARM Price: $24.99 |
| 5 |
736-0275 |
FLAT WASHER This part replaces 7360275. Price: $5.99 |
| 5 |
76-5100 |
BOLT-SHOULDER Price: $5.63 |
| 6 |
539990655 |
HCS 3/8C X 1 1/2 Price: $3.99 |
| 6 |
703-1823-0716 |
BATTERY HOLD DOWN (CUB YELLOW-99) Not Available This part replaces 703-1823. Price: |
| 7 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 7 |
731-3105 |
TRAY, BATTERY Not Available Price: |
| 7 |
76-5010 |
WASHER-SPRING Price: $0.33 |
| 8 |
539105279 |
PUMP CONTROL LINK Price: $17.99 |
| 8 |
759-3653 |
CAP-BATTERY VENT Not Available Price: |
| 8 |
94-3124 |
SCREW-HH Price: $1.30 |
| 9 |
596040901 |
Hardware This part replaces 539990223. Price: $2.99 |
| 9 |
729-0207 |
FUSE HOLDER Not Available Price: |
| 9 |
94-3178 |
STRAINER Price: $99.33 |
| 10 |
539102590 |
BALL JOINT, RIGHT HANDED Price: $19.99 |
| 10 |
77-3470 |
SCREW Price: $3.37 |
| 10 |
925-1381 |
Fuse, 20 Amp This part replaces 725-1381. Price: $5.38 |
| 11 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 11 |
729-0209 |
CLIP-FUSE HLD MTG Not Available Price: |
| 11 |
77-3490 |
SCREW Price: $4.42 |
| 12 |
539104382 |
PUMP LEVER Price: $39.99 |
| 12 |
710-0473 |
Screw, Truss Mach, #10-24 X .50 Lg Price: $3.90 |
| 12 |
94-3177 |
PLUG Price: $7.38 |
| 13 |
925-1375 |
RELAY Not Available This part replaces 725-1375. Price: |
| 14 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 14 |
929-3080 |
VOLTAGE SENSOR W/ADAPTER HARNESS Not Available This part replaces 725-3165. Price: |
| 15 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 15 |
736-0722 |
Washer, Lock, #10 Price: $5.81 |
| 16 |
539991055 |
TAP BOLT 5/16C X 2 1/4 Price: $2.99 |
| 16 |
712-0121 |
Nut, Hex, #10-24 Price: $3.75 |
| 17 |
539103297 |
SPRING Price: $6.99 |
| 17 |
710-3175 |
SCREW M8-1.25 x 14MM GR8.8 Not Available Price: |
| 18 |
539103547 |
WASHER Price: $0.99 |
| 19 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 19 |
725-3147 |
QUICK CONNECT LUG Not Available Price: |
| 20 |
596584101 |
Nuts This part replaces 539991073. Price: $2.99 |
| 20 |
712-3077 |
HEX NUT M8X1.25 GR8.8 Not Available Price: |
| 21 |
539104995 |
SPACER Price: $11.99 |
| 22 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 23 |
539102720 |
DAMPENER Price: $39.99 |
| 24 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 25 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 26 |
539105023 |
BRACKET "I" Price: $6.99 |
| 27 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 28 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 29 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 30 |
596039001 |
Screws This part replaces 539976952. Price: $2.99 |
| 31 |
539104363 |
CONTROL WELDMENT LT Price: $119.99 |
| 32 |
539102591 |
BALL JOINT, LEFT HANDED Price: $19.99 |
| 33 |
539104364 |
CONTROL WELDMENT RT. Price: $119.99 |
| 34 |
539101080 |
SWITCH, INTERLOCK Price: $14.99 |
| 35 |
539102678 |
TAPPED PLATE Price: $12.99 |
| 36 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 37 |
539990588 |
HCS 3/8C X 2 Price: $3.99 |
