| Ref | Part Number | Description |
|---|
| 1 |
532124415 |
STEERING WHEEL Price: $58.99 |
| 1 |
76-2760 |
HOSE ASSEMBLY Price: $259.75 |
| 2 |
532142033 |
AXLE ASSY Price: $59.99 |
| 2 |
76-2750 |
HOSE ASSEMBLY Price: $277.12 |
| 3 |
237-58 |
O-RING Price: $2.18 |
| 3 |
532135227 |
SPINDLE LH Price: $15.39 |
| 4 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 4 |
532135228 |
SPINDLE RH Price: $12.97 |
| 5 |
237-81 |
O-RING Price: $2.76 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 6 |
76-2770 |
HOSE ASM Price: $271.52 |
| 7 |
237-22 |
O-RING Price: $2.43 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
69-4320 |
FITTING-HYD, 90 DEG Price: $154.75 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
237-42 |
O-RING Price: $2.78 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 10 |
32128-21 |
NUT-HF Price: $0.39 |
| 10 |
532130468 |
LINK.DRAG.SOL.BALL JT.20.064 Price: $64.99 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 11 |
94-4907 |
MOTOR-HYD This part replaces 69-2780. Price: $1,685.80 |
| 12 |
3231-28 |
SCREW-CARR Price: $1.92 |
| 12 |
873610600 |
NUT Price: $2.99 |
| 13 |
19-1470 |
SCREW-SHOULDER Price: $3.49 |
| 13 |
532155134 |
KIT-AXLE This part replaces 532110438. Price: $13.26 |
| 14 |
69-6960 |
SPACER-IDLER Price: $22.57 |
| 14 |
874011056 |
Bolt Hex 5/8-11 Unc X 3-1/2 Price: $4.99 |
| 15 |
140-5848 |
PULLEY-IDLER This part replaces 63-1540. Price: $62.48 |
| 15 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 16 |
325-7 |
SCREW-HH Price: $1.53 |
| 16 |
532132624 |
AXLE PIN Price: $2.42 |
| 17 |
531166901 |
SERVICE KIT SHAFT ASM ST This part replaces 532140176. Price: $42.99 |
| 17 |
69-9290 |
PAD-BUMPER Price: $9.52 |
| 18 |
32108-103 |
SCREW-FH Price: $0.68 |
| 18 |
532057079 |
THRUST WASHER Price: $1.99 |
| 19 |
32128-20 |
NUT-HF Price: $0.99 |
| 19 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $8.99 |
| 20 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 20 |
596582301 |
Washers This part replaces 532126684. Price: $2.99 |
| 21 |
32120-72 |
RING-SNAP Price: $2.09 |
| 21 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 22 |
256-188 |
BUSHING Price: $5.70 |
| 22 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871100410. Price: $3.99 |
| 23 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532127501. Price: $29.99 |
| 23 |
69-6610-01 |
ARM-IDLER This part replaces 69-6610. Price: $84.61 |
| 24 |
325-8 |
SCREW-HH Price: $3.52 |
| 24 |
532109816 |
NYLINER T (7283A) Price: $4.99 |
| 25 |
531152201 |
SERVICE KIT BRACKET BRKT This part replaces 532124036. Price: $12.99 |
| 25 |
69-5430-03 |
PULLEY-IDLER, FLAT This part replaces 69-5430. Price: $63.15 |
| 26 |
69-6970 |
SPACER-IDLER, FLAT Price: $13.54 |
| 27 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 27 |
532136874 |
GEAR.SECTOR Price: $69.99 |
| 28 |
256-117 |
BUSHING Price: $4.07 |
| 29 |
3269-25 |
RIVET-POP Price: $0.27 |
| 29 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 30 |
69-6780 |
DISCONTINUED Price: Call Us |
| 31 |
69-6870 |
PLATE-MAGNET Price: $4.91 |
| 32 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN This part replaces 532130467. Price: $79.99 |
| 32 |
69-6260 |
MAGNET Price: $58.32 |
| 33 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
32128-23 |
NUT-HF Price: $1.51 |
| 35 |
873610500 |
This part replaces 873810500. Price: $2.15 |
| 36 |
532155107 |
STEERING BUSHING KIT This part replaces 532102803. Price: $6.99 |
| 36 |
76-1670-03 |
SPRING-EXTENSION This part replaces 76-1670. Price: $24.92 |
| 37 |
3217-9 |
NUT-HH Price: $0.37 |
| 37 |
817211008 |
Screw Slftp #10-16 x 1/2 Ty-Ab This part replaces 817431008. Price: $3.99 |
| 38 |
532124416 |
INSERT,STR WHEEL Price: $7.89 |
| 38 |
69-6550 |
TENSIONER WA Price: $72.13 |
| 39 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133808. Price: $4.99 |
| 39 |
95-0833 |
DECAL-BELT ROUTING,CENTER This part replaces 82-2560. Price: $20.90 |
| 40 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 40 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 41 |
13-4969 |
FRONT DECK W/DECALS Price: $3,199.64 |
| 41 |
532104820 |
ADAPTER-WHEEL LT Price: $13.99 |
| 42 |
3233-27 |
SCREW-CARR Price: $2.17 |
| 42 |
532150390 |
BOOT, STEERING SHAFT Price: $3.18 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 43 |
98-0755-03 |
PLATE - TENSIONER,ASM This part replaces 69-6490. Price: $74.44 |
| 44 |
532154307 |
KIT.EXTENSION.STEERING.PLM/LR This part replaces 532146690. Price: $34.99 |
| 44 |
77-2830 |
SPRING ROD Price: $85.37 |
| 45 |
3272-7 |
PIN-COTTER Price: $0.25 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 47 |
69-6890 |
DISCONTINUED Price: Call Us |
| 48 |
86-7480 |
COMPRESSION SPRING Price: $35.91 |
| 50 |
23-1640 |
BUSHING-TAPERLOCK Price: $68.50 |
| 50 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE This part replaces 817490412. Price: $3.99 |
| 51 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 51 |
63-0660 |
GEARBOX PULLEY WA Price: $80.31 |
| 52 |
69-6390 |
DISCONTINUED Price: Call Us |
| 53 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 54 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 54 |
69-6790 |
RH CENTER COVER Price: $140.29 |
| 55 |
532140285 |
CLIP Price: $2.99 |
| 55 |
85-6450 |
RETAINER - BELT Price: $33.21 |
| 56 |
95-0845 |
DECAL-HOC This part replaces 71-4260. Price: $11.75 |
| 57 |
532140172 |
SUPPORT STEERING SHAFT Price: $2.42 |
| 57 |
95-0817 |
DECAL-HOC This part replaces 69-0820. Price: $10.90 |
| 58 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 59 |
3233-30 |
SCREW-CARR Price: $3.26 |
