| Ref | Part Number | Description |
|---|
| 2 |
532069180 |
Nut, Crownlock #10-24 Price: $2.69 |
| 2 |
99-5610 |
PIN Price: $40.16 |
| 3 |
532127533 |
Screen, Cover Price: $11.99 |
| 3 |
98-1880-03 |
KNUCKLE-PIVOT Price: $350.23 |
| 4 |
105-3366 |
NO. 1 LIFT ARM ASM Price: $1,019.52 |
| 5 |
532139569 |
Chute, Upper Price: $70.99 |
| 5 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 6 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 6 |
818021008 |
Screw, Special Price: $3.99 |
| 7 |
106-9208 |
SHORT CYLINDER PIN ASM Price: $83.12 |
| 7 |
532140572 |
Dump Bag Indicator Price: $4.99 |
| 8 |
874981024 |
SCREW.PAN.HEAD This part replaces 532087175. Price: $5.99 |
| 8 |
94-9998 |
WASHER-THRUST Price: $11.60 |
| 9 |
819061216 |
Washer 3/16x3/4x16 Ga. Price: $2.69 |
| 9 |
94-9974 |
RING-RETAINING Price: $0.70 |
| 10 |
532007206 |
Spacer, Split Price: $3.99 |
| 10 |
75-5350 |
PIN-SLIDE, CYLINDER Price: $41.31 |
| 11 |
140-6431 |
PIVOT PIN ASM This part replaces 95-7158. Price: $37.92 |
| 11 |
539108086 |
NUT.#10-24 ACORN.ZD This part replaces 532060867. Price: $1.99 |
| 12 |
810071000 |
Washer, lock Price: $2.99 |
| 13 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 13 |
532109808 |
Latch, Chute Price: $2.69 |
| 14 |
33114-020 |
SCREW-HH Price: $0.28 |
| 14 |
532002029 |
NUT.WELD.#10-24 This part replaces 532125004. Price: $2.69 |
| 15 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 15 |
874930620 |
Bolt, Hex Head 3/8-16 x 1-1/4 Price: $3.99 |
| 16 |
819131612 |
Washer 13/32 x 1 x 12 Ga. This part replaces 819131616. Price: $3.99 |
| 16 |
99-5621 |
GUIDE-HOSE Price: $34.45 |
| 17 |
2412-96 |
CLAMP-R Price: $3.46 |
| 17 |
873680600 |
Nut This part replaces 873930600. Price: $1.99 |
| 18 |
105-7916 |
HYD HOSE ASM Price: $202.95 |
| 18 |
532132807 |
Chute, Lower Price: $51.99 |
| 19 |
322-4 |
SCREW-HH Price: $0.35 |
| 19 |
532135651 |
Wingnut 3/8-16 Price: $3.99 |
| 20 |
105-9274 |
HYD HOSE ASM Price: $242.86 |
| 20 |
871081010 |
Screw #10-24 x 5/8 Price: $3.49 |
| 21 |
138-6951 |
CYLINDER ASM-HYDRAULIC This part replaces 93-2650. Price: $664.52 |
| 21 |
532132796 |
Spring, Cover L.H. (black) Price: $2.99 |
| 22 |
532133235 |
Spacer, Cover Price: $3.99 |
| 23 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 23 |
532132983 |
Spring, Cover R.H. (gray) Price: $2.99 |
| 24 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 24 |
532127720 |
Post, Support Price: $13.00 |
| 25 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 25 |
873800500 |
Locknut 5/16 x 18 Price: $2.69 |
| 26 |
532085902 |
RETAINER SPRING This part replaces 532124670. Price: $1.99 |
| 26 |
98-7974 |
WASHER-THRUST Price: $37.96 |
| 27 |
872110506 |
Carriage Bolt, 5/16-18 x 3/4 Price: $3.99 |
| 27 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 28 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 28 |
532170053 |
Bracket, Mounting Price: $9.99 |
| 29 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 29 |
532170165 |
Shoulder Bolt Price: $2.99 |
| 30 |
532131137 |
Pin, Support Post Price: $6.99 |
| 30 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 31 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 31 |
532174083 |
Plug, Tubing End Price: $3.99 |
| 32 |
105-0142-03 |
ROD-PIVOT, FRONT Price: $122.57 |
| 32 |
532126919 |
Bagger, Frame Price: $59.99 |
| 33 |
532192786 |
Pin, Hinge This part replaces 532128600. Price: $7.99 |
| 33 |
98-3929 |
SPRING-TORSION Price: $23.85 |
| 34 |
532127534 |
Gasket, Cover Price: $8.99 |
| 34 |
93-6738 |
CHAIN Price: $13.80 |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 35 |
532183286 |
Container, Top Price: $17.99 |
| 36 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 36 |
532129586 |
Container, Bottom Price: $62.99 |
| 38 |
532130895 |
Latch Handle, Cover Price: $3.99 |
| 39 |
532155042 |
Strip, Reinforcement Price: $11.99 |
| 41 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
| 42 |
532137031 |
U-Bolt Price: $2.42 |
| 43 |
532123635 |
Wheel Weight Price: $53.79 |
