| Ref | Part Number | Description |
|---|
| 1 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 1 |
532198563 |
CORD.ELECTRIC.10FT.120V.SNOW Price: $19.99 |
| 2 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 2 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 3 |
532429112 |
WRENCH.SNOWTHROWER.ZINC.YZ This part replaces 532180684. Price: $3.99 |
| 3 |
98-9308 |
GAUGE-TEMPERATURE This part replaces 63-7430. Price: $112.90 |
| 4 |
532184505 |
SPRING.DEFLECTOR.REM.CHUTE Price: $6.99 |
| 4 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 5 |
218-446 |
NUT-HEX Price: $6.09 |
| 5 |
532179829 |
BOLT, SHOULDER Price: $4.99 |
| 6 |
218-447 |
WASHER-LOCK Price: $3.79 |
| 6 |
532179246 |
WASHER, NYLON FRICTION Price: $3.99 |
| 7 |
233-50 |
CONTROL KNOB Price: $2.67 |
| 7 |
532191730 |
NUT.HEX.FLANGE.1/4 Price: $3.99 |
| 8 |
596136401 |
Bolts This part replaces 872250505. Price: $2.99 |
| 8 |
68-5630 |
DISCONTINUED Price: Call Us |
| 9 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 9 |
70-8120 |
DISCONTINUED Price: Call Us |
| 10 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 10 |
6-1659 |
SWITCH & BOOT ASM Price: $78.15 |
| 11 |
218-497 |
DISCONTINUED PLEASE SEE NOTES Price: Call Us |
| 11 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 12 |
218-473 |
BOOT-SWITCH Price: $17.61 |
| 12 |
588077502 |
BOLT SHEAR HX HD 1/4-20 CLEAR This part replaces 532198636. Price: $1.00 |
| 13 |
532198638 |
SPACER.3943.SLEEVE.250X.47 Price: $5.99 |
| 14 |
68-5210 |
DISCONTINUED Price: Call Us |
| 15 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 16 |
3250-28 |
SCREW Price: $0.49 |
| 17 |
32104-76 |
SCREW-HWHTF Price: $2.29 |
| 18 |
68-9931 |
THROTTLE CONTROL Price: $55.16 |
| 19 |
32105-8 |
SCREW-SHH Price: $1.99 |
| 20 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 21 |
27-2360 |
SWITCH Price: $46.56 |
| 22 |
39-9600 |
MTG CLAMP F/W GUAGE Price: $19.63 |
| 23 |
3253-12 |
WASHER-LOCK/SP Price: $0.25 |
| 24 |
3256-49 |
WASHER-PLAIN Price: $0.33 |
| 25 |
218-515 |
BRACKET Price: $12.11 |
| 26 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 27 |
3217-26 |
NUT-HEX Price: $0.25 |
| 28 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 29 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 30 |
69-4780 |
CLAMP-GAUGE Price: $73.28 |
| 31 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 32 |
70-8200 |
DISCONTINUED Price: Call Us |
| 33 |
66-2960 |
WARNING LAMP CLUSTER Price: $210.90 |
